Production Years Covered:
2011, 2012, 2013, 2014, 2015
Vehicle Type:
All-Electric Compact Hatchback
Generation:
First Generation (ZE0)
Positioning:
Targeted at DIY enthusiasts and professional mechanics for cost-effective vehicle upkeep.
Value Proposition:
Provides factory-level information to save on dealership service costs.
Features:
Detailed illustrations, wiring schematics, step-by-step instructions, comprehensive system coverage.
Usability:
Designed for ease of use with clear instructions and visual aids, making complex repairs accessible.
Coverage:
Complete Service and Repair
Page Count:
Not Specified (Comprehensive, typically 1000+ pages for full service manuals)
Type:
Service and Repair Manual
Content Type:
Factory Service Manual (FSM) Equivalent
Delivery Method:
Instant Download
Completeness Guarantee:
100% complete and intact, no missing/corrupt pages/sections.
Powertrain:
EV Control System, Traction Motor System, EV Battery System, Transaxle & Transmission
Electrical:
Vehicle Charging System, High Voltage Cooling System, Accelerator Control System, SRS Airbag, SRS Airbag Control System, Security Control System, Body Control System, LAN System, Power Control System, Charging System, Power Supply, Ground & Circuit Elements, Meter, Warning Lamp & Indicator, Warning Chime System, Audio, Visual & Navigation System, Cruise Control System
Chassis:
Front Axle, Rear Axle, Front Suspension, Rear Suspension, Road Wheels & Tires, Brake System, Parking Brake System, Brake Control System, Steering System, Steering Control System
Body Interior:
Ventilation System, Heater & Air Conditioning System, Heater & Air Conditioning Control System, Interior, Instrument Panel, Seat, Door & Lock, Glass & Window System, Power Window Control System, Exterior, Mirrors, Exterior Lighting System, Interior Lighting System, Wiper & Washer, Defogger, Horn, Approaching Vehicle Sound for Pedestrians (VSP), Power Outlet
Repair Procedures:
Complete diagnostic and repair procedures, step-by-step instructions for disassembly and reassembly
Maintenance Procedures:
Regular maintenance, fluid checks and changes, component inspection
Diagnostic Procedures:
Troubleshooting guides, diagnostic trouble codes (DTCs), fault finding
Depth:
Comprehensive (from basic maintenance to complete rebuilds and advanced diagnostics)
Diagrams And Schematics:
Includes detailed wiring schematics for all electrical systems, mechanical diagrams for component repair.
Illustrations:
Hundreds of photos and illustrations to visually guide users through service procedures.
PDF Features:
Searchable text, bookmarked sections, printable pages, zoomable
Quality:
High-quality (implied by detailed illustrations and diagrams)
Binding:
Digital Download (PDF)
Paper Type:
N/A (Digital)
Os Compatibility:
All versions of Windows & Mac, Linux OS, iPhone, iPad, Android
Software Requirements:
Adobe PDF Reader, WinZip
Search Functionality:
Yes, fully searchable PDF content.
Motor Type:
Nissan EM57 (AC Synchronous Electric Motor)
Horsepower:
107 hp (approx. 80 kW)
Torque:
187 lb-ft (approx. 254 Nm)
Battery Type:
Lithium-ion Polymer Battery Pack
Battery Capacity Kwh:
24 kWh (standard for this generation)
Charging Ports:
J1772 (Level 1 & 2), CHAdeMO (DC Fast Charge)
Length:
Approx. 170.1 inches (4320 mm)
Width:
Approx. 69.7 inches (1770 mm)
Height:
Approx. 63.6 inches (1615 mm)
Curb Weight Lbs:
Approx. 3350 - 3450 lbs (1520 - 1565 kg)
Gross Vehicle Weight Rating Gvw:
Not specified in product info, typically around 4300 lbs
NHTSA Rating:
Overall 5-Star Safety Rating (from NHTSA for specific model years, check manual for details)
IIHS Rating:
Top Safety Pick (for specific model years, check manual for details)
Active Safety:
ABS, EBD, Brake Assist, Traction Control, Stability Control
Passive Safety:
Front, Side, and Curtain Airbags, Seatbelt Pretensioners
Infotainment System:
Nissan's Carwings telematics system (later renamed NissanConnect EV), navigation, audio systems covered.
Driver Assistance:
Features like regenerative braking, one-pedal driving (e-Pedal on later models, but manual covers system components).
Connectivity:
Remote monitoring and control via smartphone app (Carwings/NissanConnect EV).
Ev Systems:
Detailed coverage of high-voltage battery management, charging infrastructure, traction motor control.
Battery Health Checks:
Regular checks for battery capacity degradation and performance (detailed in manual).
Tire Rotation:
Recommended every 7,500-10,000 miles (12,000-16,000 km) or as per manual guidance.
Cabin Air Filter:
Replace annually or every 15,000 miles (24,000 km).
Brake Fluid Change:
Recommended every 2 years or 30,000 miles (48,000 km) to maintain ABS and regenerative braking performance.
Coolant Type:
Nissan Genuine Super Long Life Coolant (Blue) or equivalent (for high voltage battery cooling system and HVAC).
Brake Fluid Type:
DOT 3 or DOT 4 brake fluid.
Transmission Fluid:
Nissan Genuine Transaxle Fluid (NS2) or equivalent (for reduction gear).
Battery Degradation:
Common issue in early EVs, manual provides diagnostic procedures for battery health.
HVAC System:
Potential issues with the HVAC system due to its electric operation; manual covers detailed diagnostics.
Brand Focus:
Nissan has a long history of innovation in automotive technology, including early leadership in electric vehicles.
First Generation Launch:
Launched globally in late 2010 as one of the first mass-market all-electric vehicles.
Manufacturing Locations:
Global production including Japan, US (Smyrna, TN), and UK (Sunderland).
