🏷️ Basic Information

Make:

Dodge

Model:

Ram 1500, 2500, 3500, 4500, 5500 HD

Product Name:

Dodge Ram 2012-2015 1500 2500 3500 4500 5500 HD Factory Workshop Service Repair Manual

Product Description:

Factory Workshop Service Repair Manual for Dodge Ram 1500, 2500, 3500, 4500, and 5500 HD models from 2012 to 2015. Loaded with Hi Resolution illustrations, instructions, photos, and diagrams for complete service and repair. Pages can be read and printed directly from CD or copied to hard drive.

Generation Identifier:

DS/DJ (Fourth Generation Ram Pickup)

Vin Code Start:

Vehicle Identification Number (VIN) structure varies by model year and truck configuration. Refer to the manual for specific VIN decoding.

Drivetrain Options:

2WD, 4WD

Body Styles:

Regular Cab, Crew Cab, Mega Cab (depending on model and year)

👋 Introduction

Positioning:

Comprehensive factory service manual for a wide range of heavy-duty Dodge Ram trucks, catering to both professional mechanics and dedicated owners seeking in-depth repair knowledge.

Competitors:

Other aftermarket repair manuals (Haynes, Chilton) and potentially OEM service information subscriptions. This manual offers factory-level detail and breadth.

Feature 1:

Encompasses a broad spectrum of Ram HD models and years (2012-2015).

Feature 2:

Vast page count (14,000+) indicates thorough coverage of all vehicle systems.

Feature 3:

Factory-level detail with high-resolution illustrations and diagrams.

Feature 4:

Covers a wide array of electrical and electronic systems, a common area of complexity.

Feature 5:

Supports multiple operating systems and devices for accessibility.

📋 Manual Details

Model Years Covered:

2012, 2013, 2014, 2015

Models Covered:

Dodge Ram 1500, 2500, 3500, 4500, 5500 HD

Specific 2012 Model Coverage:

3500 HD Version Compatible with 1500, 2500, 3500, 4500, 5500 HD

Total Pages:

14000+

Type:

Factory Workshop Service Repair Manual

Language:

English

Format:

PDF

Distribution Medium:

CD-ROM (implied download link)

Operating Systems:

All Windows (10, 8, 7, Vista 32/64, XP, ME, 98, NT, 2000) & Mac

Device Compatibility:

Windows/Mac/Tablet/Phone Friendly

Bit Architecture:

32 / 64 bit

📖 Manual Coverage

General Information:

Circuit Testing Procedures, Mopar Accessories, Scan Tool usage, Special Tools, Vehicle Data

Common Specs And Procedures:

Comprehensive Common Specifications and Procedures

Diagnostic Trouble Codes:

DTC Index

Accessories And Equipment:

Amplifier, Audio and Video Systems, Audio Radio, Audio Video, Chime Buzzer, Communication Systems, Driver Door Module, Electronic Control Modules (ECMs), Hands Free Module, Heated and Cooled Accessories, Heated Glass, Heated Mirrors, Heated Seat Module, Heated Seats, Heated System, Horn and Horn System, Instrument Cluster, Memory Seat Module, Message Center, Mirror Systems, Navigation and Telecommunication, Park Assist Module, Passenger Door Module, Power Doors, Power Locks, Power Mirrors, Power Seats, Power Windows, Seats, Speed Control (Cruise Control), Telecommunication Systems, Universal Transmitter, Vehicle Theft and Security, Video Entertainment System, Wiper and Washer Systems, Wireless Ignition Node

Body And Frame:

Body Interior and Exterior, Frame and Bumpers, Power Top Sunroof

Brakes:

Antilock Brake System (ABS), Base Brake Systems, Integrated Trailer Brake Module

Driveline And Axles:

Final Drive Control Module, Front Axle, Propeller Shaft, Rear Axle

Electrical:

Battery System, Charging System, Power Distribution, Special Tools (for electrical systems)

Engine:

Cooling System, 5.7L Engine, 6.7L Engine, Exhaust System, Fuel System, Ignition System, Starting System

Engine Performance:

Driveability (Diesel and Gas), Emission Applications, Emission Control Systems, Firing Order and Cylinder Identification, Mode 6 Diagnostics, Powertrain Control Module (PCM)

HVAC:

Heating and Air Conditioning (ATC - Automatic Temperature Control and MTC - Manual Temperature Control)

Lighting:

Cabin Compartment Node, Exterior Lighting, Interior Lighting, Lamps Lighting

Maintenance:

Maintenance Reminder Light Procedures, Vehicle Quick Reference for maintenance

Restraints:

Occupant Restraint Controller (ORC), Service Information for restraints

Steering:

Steering System

Suspension:

Front Suspension and Wheel Alignment, Rear Suspension, Tire Pressure Module, Tires and Wheels

Transmission:

Automatic Transmission, Clutch System, Manual Transmission, Powertrain Control Module (related to transmission), Transfer Case, Transmission Control Module (TCM)

Wiring:

Comprehensive wiring diagrams for Air Conditioning, Antilock Brakes, Anti-Theft, Body Control Modules, Computer Data Lines, Cooling Fan, Cruise Control, Defoggers, Engine Performance, Exterior Lights, Ground Distribution, Headlights, Horn, Instrument Cluster, Interior Lights, Memory System, Navigation, Power Distribution, Power Door Locks, Power Mirrors, Power Seats, Power Top Sunroof, Power Windows, Radio, Shift Interlock, Starting/Charging, Supplemental Restraints (SRS), Transmission, Warning System, Wiper/Washer

Repair Instructions:

Detailed step-by-step instructions for all workshop procedures

Diagnostics:

Troubleshooting procedures for various systems, DTC interpretation and resolution

Maintenance:

Routine maintenance procedures, service interval guidance

Component Replacement:

Instructions for removing, installing, and adjusting vehicle components

Depth:

Complete workshop-level service and repair coverage, suitable for professional technicians and advanced DIYers.

Illustrations:

High resolution illustrations, photos, and diagrams included for clarity.

📊 Manual Specifications

File Type:

PDF

Searchability:

Likely searchable text within PDF for efficient information retrieval.

Resolution:

High Resolution illustrations and images.

Readability:

Designed for clear reading and printing of pages.

Type:

Digital (PDF format for download/CD)

Type:

N/A (Digital format)

⚙️ Engine Specifications

Available Engines:

5.7L HEMI V8, 6.7L Cummins Turbo Diesel (specific availability varies by model and configuration, e.g., 6.7L primarily in 2500/3500/4500/5500 HD models).

Engine Codes 5.7L:

EPE, EPE (refer to manual for precise codes specific to year/configuration)

Engine Codes 6.7L:

CDB (refer to manual for precise codes specific to year/configuration)

5.7L Hemi Hp Approx:

Approx. 383 hp @ 5600 rpm (varies slightly by year)

5.7L Hemi Torque Approx:

Approx. 400 lb-ft @ 4000 rpm (varies slightly by year)

6.7L Cummins Hp Approx:

Approx. 350-380 hp @ 2800-3000 rpm (varies by year and configuration)

6.7L Cummins Torque Approx:

Approx. 660-800 lb-ft @ 1400-1800 rpm (varies by year and configuration)

Fuel Delivery 5.7L:

Multi-port Fuel Injection (MPFI)

Fuel Delivery 6.7L:

High-pressure Common Rail Fuel Injection (HPCR)

Fuel Type:

Unleaded Gasoline (5.7L), Diesel Fuel (6.7L)

🔧 Transmission

Transmission Type:

Manual and Automatic transmissions available, with specific types varying by model (e.g., 6-speed manual, 6-speed automatic, 6-speed heavy-duty automatic).

Transfer Case:

Part-time 4WD (NV273), Full-time 4WD (NV271D), and specific transfer case models depending on heavy-duty classification.

Transmission Control:

Electronic control modules (TCM/PCM) manage transmission operation for optimal performance and fuel economy.

📐 Dimensions

Wheelbase Options:

Multiple wheelbase options available for 1500, 2500, 3500, 4500, 5500 models, ranging from standard to long bed configurations. Specific dimensions require manual lookup.

Overall Length Approx:

Varies significantly based on cab and bed configuration, ranging from approximately 230 inches to over 260 inches.

Curb Weight Approx:

Varies widely by model and configuration, from approximately 4,800 lbs for a 1500 to over 8,000 lbs for a 5500 HD.

Gross Vehicle Weight Rating Gvwr:

Starts around 6,500 lbs for 1500 models and extends to over 20,000 lbs for 5500 HD models.

Payload Capacity:

Ranges from approximately 1,500 lbs to over 7,000 lbs depending on model and configuration.

Towing Capacity:

Ranges from approximately 7,000 lbs for a 1500 to over 20,000 lbs for 3500/4500/5500 HD models (with proper hitch and configuration).

🛡️ Safety Features

Crash Test Ratings:

NHTSA and IIHS ratings vary by model year and specific configuration. Refer to the manual or official safety databases for detailed results. Early 4th Gen Rams generally received good ratings for their time.

ABS:

Standard Antilock Braking System (ABS) on all models.

Traction Control:

Electronic Stability Control (ESC) and Traction Control systems are typically standard.

Trailer Brake Control:

Integrated Trailer Brake Controller available on higher trims and HD models.

Airbags:

Front airbags, available side curtain airbags and front seat-mounted side airbags.

Seatbelts:

Three-point seat belts with pretensioners and load limiters.

Vehicle Theft System:

Factory-installed vehicle anti-theft system and immobilizer.

💡 Technology Features

Infotainment Systems:

Uconnect infotainment systems were available, offering features like touchscreen displays, navigation, Bluetooth connectivity, and SiriusXM satellite radio. System variants include Uconnect 3.0, 5.0, and 8.4A/AN.

Driver Assistance Features:

Features like ParkSense parking assist (front and rear), rearview cameras, and trailer-sway control were available options.

Connectivity Options:

Bluetooth streaming audio and hands-free calling, USB ports for media playback and device charging.

🔧 Maintenance

Oil Change Interval:

Typically 6,000 to 10,000 miles or 6 to 12 months, depending on engine, driving conditions, and oil type. Refer to the manual for specific intervals.

Diesel Oil Change Interval:

Around 7,500 miles or 6 months for the 6.7L Cummins, with specific recommendations for synthetic diesel oil.

Engine Oil 5.7L:

SAE 5W-20, meeting Chrysler Material Standard MS-6395.

Engine Oil 6.7L:

SAE 15W-40 (or 5W-40 synthetic for colder climates), meeting API CK-4 or CJ-4 specifications.

Transmission Fluid Automatic:

ATF+4 (Chrysler Material Standard MS-9602) for most automatic transmissions. Some heavy-duty transmissions may have specific fluids.

Transmission Fluid Manual:

Specific gear oil (e.g., SAE 75W-90) for manual transmissions. Refer to manual for exact specification.

Coolant:

OAT (Organic Additive Technology) Coolant, typically Mopar Antifreeze/Coolant (MS-9070) or equivalent, 50/50 mix with distilled water.

Brake Fluid:

DOT 3 or DOT 4 Brake Fluid.

Common Issues:

Potential issues can include EGR valve problems on diesel engines, transfer case actuator failures, HVAC system issues (blend doors, blower motor), electrical gremlins in complex systems, and exhaust gas recirculation (EGR) cooler leaks on the 6.7L Cummins. The manual will provide troubleshooting for these and more.

📚 Vehicle History

Brand:

Dodge has a long-standing heritage in the truck market, with the Ram line being a prominent and successful part of that history since its introduction in 1981.

Fourth Generation:

The 2012-2015 models represent the fourth generation of the Ram Pickup (DS platform), which debuted for the 2009 model year. Significant updates and powertrain refinements occurred within this generation, leading up to the split from Dodge to Ram Trucks in 2009.

Manufacturing Locations:

Primary manufacturing plants include Warren Truck Assembly Plant in Warren, Michigan, and Saltillo Truck Assembly Plant in Saltillo, Mexico.

🏆 Awards & Recognition

Truck Of The Year Awards:

While specific awards for these exact model years might be diverse, the Ram Truck brand consistently received accolades for its performance, towing capabilities, and interior refinement during this period, often competing for and winning 'Truck of the Year' titles from various automotive publications.

Powertrain Recognition:

The 6.7L Cummins Turbo Diesel engine is widely recognized for its durability and torque.
