Positioning:
The Chevrolet Sonic was positioned as a subcompact car, competing in a highly contested segment against models like the Ford Fiesta, Honda Fit, and Toyota Yaris. This manual targets owners and technicians needing in-depth information for maintenance and repair.
Value Proposition:
This comprehensive manual provides the same level of detail as official dealership workshop manuals, offering significant cost savings for repairs and maintenance compared to dealership labor rates. The inclusion of detailed wiring diagrams is a key differentiator.
Features:
Extensive system coverage, detailed illustrations and diagrams, troubleshooting guides, wiring schematics, multiple engine and transmission options covered, printable format, cross-platform compatibility.
General:
Comprehensive service, repair, and wiring for Chevrolet Sonic (2012-2016).
Body:
Air/Wind Noise, Bolted Exterior Body Panels, Bumpers/Fascias, Collision Repair, Exterior Trim, Fixed/Moveable Windows, Floor Coverings/Headlinings, Frame/Underbody, Instrument Panel/Console Trim, Interior Trim/Paneling, Lighting, Mirrors, Paint/Coatings, Plastic Panel Info/Repair, Seat Hardware/Trim/Upholstery, Sunroof, Water Leaks, Wipers/Washers, Squeaks/Rattles.
Electrical:
Cellular/Entertainment/Navigation, Cruise Control, Data Communications, Displays/Gauges, Horns, Immobilizer, Object Detection/Pedestrian Protection, Programming/Setup, Remote Functions, Seat Heating/Cooling, Secondary/Configurable Controls, Theft Deterrent, Vehicle Access, 12V Starting/Charging, Power Outlets, Wiring Systems (Component Connector End Views, Component Locators, Door/Electrical Center/Engine Compartment/Ground/Inline Harness/Instrument Panel/Luggage Compartment/Passenger Compartment/Powertrain/Splice Pack/Wheels Component Views, Master Electrical List, Wiring Schematics/Harness Routing).
Chassis:
Antilock Brake System, Disc Brakes, Drum Brakes, Hydraulic Brakes, Park Brake, Wheel Drive Shafts, Front Suspension, Rear Suspension, Suspension General Diagnosis, Tires/Wheels, Wheel Alignment, Steering Wheel/Column, Power Steering.
Powertrain:
Cabin Air Filter, Engine Cooling, Engine Exhaust, Engine Mechanical (1.4L LUV, 1.8L LUW/LWE), Engine Controls/Fuel (1.4L LUV, 1.8L LUW/LWE) with DTC diagnostics, Firing Order/Cylinder Identification, Clutch, Manual Transmission (F17-5, M20-M32), Automatic Transmission (6T30/6T40), Transmission Cooling, Shift Lock Control.
Diagnostics:
Troubleshooting (Basic Procedures, Symptom Check Lists, Vibration Diagnosis), Engine Performance Diagnostics, Parasitic Load Testing, Drive Axle Noise Diagnosis, Electrostatic Discharge (ESD) Warning.
Maintenance:
Maintenance and Lubrication, General Cooling System Service, Reminder Indicator Reset Procedures.
Safety Systems:
Seat Belts, Supplemental Inflatable Restraints (Airbags), Traction Control.
Emissions:
Emission Control Abbreviations (Gasoline & Diesel).
Body Repair Bonus:
Includes a Body Repair Manuals (Bonus) section.
Estimated Pages:
Varies based on specific model/engine combinations, but extensive given the detailed coverage listed.
Type:
Factory Service Manual / Workshop Manual
Compatibility:
Compatible with all Windows & Mac computers (Windows 10, 8, 7, Vista 32/64, XP, ME, 98, NT, 2000), Tablets, and Phones. Supports 32/64 bit.
All Major Systems:
Engine, Transmission, Drivetrain, Brakes, Suspension, Steering, Electrical, HVAC, Body, Chassis, Emissions, Safety Systems.
Repair And Maintenance:
Detailed step-by-step instructions for servicing and repairing all covered systems. Includes diagnostics, component replacement, adjustments, and rebuild procedures.
Wiring Diagrams:
Extensive wiring diagrams, schematics, and harness routing diagrams for all electrical systems.
Troubleshooting:
Systematic diagnostic procedures for identifying and resolving common and complex issues, including DTC interpretation.
Specifications:
Torque specifications, fluid types and capacities, alignment data, diagnostic specifications, and fastener tightening specifications.
Depth:
Complete workshop-level detail, suitable for professional technicians and experienced DIY enthusiasts. Covers everything from basic maintenance to complex diagnostics and repairs.
Engine 1.4L Turbocharged:
1.4L (LUV) Ecotec Turbocharged I4. Power output typically around 138 hp and 148 lb-ft torque (exact figures vary by specific model year and calibration). Features include direct injection and turbocharging.
Engine 1.8L Naturally Aspirated:
1.8L (LUW, LWE) Ecotec Naturally Aspirated I4. Power output typically around 138 hp and 125 lb-ft torque (exact figures vary by specific model year and calibration). Features include variable valve timing.
Horsepower Range:
Approximately 138 hp for both engine variants, with torque figures differing due to turbocharging.
Torque Range:
Approx. 125 lb-ft for 1.8L, and 148 lb-ft for 1.4L Turbo.
Fuel Delivery:
Port Fuel Injection (PFI) for 1.8L, Gasoline Direct Injection (GDI) for 1.4L Turbo.
Fuel Type:
Unleaded gasoline.
Emission Controls:
Includes detailed information on emission control systems specific to each engine.
Length:
Approximately 160.1 inches (4067 mm) for sedan, 157.3 inches (3995 mm) for hatchback. (Specific dimensions may vary slightly by year/trim.)
Width:
Approximately 66.3 inches (1684 mm).
Height:
Approximately 57.1 inches (1450 mm) for sedan, 57.7 inches (1465 mm) for hatchback.
Curb Weight:
Ranges from approximately 2,600 to 2,800 lbs (1180 to 1270 kg) depending on engine and transmission.
Gross Vehicle Weight Rating:
Typically around 3,800 to 3,900 lbs (1725 to 1770 kg).
Cargo Volume Sedan:
Approximately 13.7 cubic feet.
Cargo Volume Hatchback:
Approximately 19.7 cubic feet (rear seats up), 34.6 cubic feet (rear seats folded).
NHTSA Overall Rating:
Varies by year; generally achieved 4 or 5 stars in various NHTSA crash tests for frontal, side, and rollover protection.
IIHS Ratings:
Generally received 'Good' ratings in IIHS crashworthiness tests for frontal offset and side impact.
Active Safety:
Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC) on most models.
Passive Safety:
Frontal airbags, side-impact airbags, curtain airbags (standard on many trims), active head restraints.
Seat Belts:
Three-point seat belts with pretensioners and load limiters.
Supplemental Restraints:
Detailed coverage of the Supplemental Inflatable Restraint (SIR) system (airbags).
Infotainment System:
Available with Chevrolet MyLink infotainment system, featuring touchscreen displays, Bluetooth connectivity, USB ports, and optional navigation.
Driver Assistance Features:
Optional features include rear parking assist sensors and a rearview camera on some trims.
Connectivity Features:
Bluetooth for hands-free calling and audio streaming, USB and auxiliary audio inputs.
Keyless Entry Remote:
Remote keyless entry and ignition, with optional passive entry and push-button start on higher trims.
Oil Change Interval:
Typically every 5,000 to 7,500 miles or 6-12 months, depending on driving conditions and oil type (consult manual for specific recommendation).
Air Filter Replacement:
Recommended every 15,000 to 30,000 miles or as needed based on driving environment.
Cabin Air Filter Replacement:
Recommended annually or every 15,000 miles.
Spark Plug Replacement:
1.4L Turbo: Approximately 60,000 miles. 1.8L: Approximately 100,000 miles (refer to manual for specific type and interval).
Engine Oil:
1.4L Turbo: SAE 5W-30 synthetic oil. 1.8L: SAE 5W-30 synthetic oil. (Always confirm with manual and API certified oil).
Coolant:
Dex-Cool (GM P/N 12346560 or equivalent) - orange silicate-free silicate-free OAT coolant.
Brake Fluid:
DOT 3 or DOT 4 brake fluid.
Transmission Fluid Automatic:
Dexron VI (GM P/N 88863400 or equivalent).
Transmission Fluid Manual:
Refer to manual for specific manual transmission fluid type (often GL-4 rated gear oil).
Common Issues 1.4T:
Turbocharger issues (oil leaks, wastegate problems), oil cooler line leaks, coolant leaks, PCV system issues.
Common Issues 1.8:
Oil leaks from the valve cover gasket, coolant leaks, occasional ignition coil failures.
General:
Front suspension noise/clunks, HVAC system issues (blower motor, AC leaks), water leaks into the cabin, starter motor issues.
