🏷️ Basic Information

Make:

Arctic Cat

Model:

TRV 550 CRUISER

Year:

2012

Color Variant:

METALLIC GREEN

Product Code:

A2012TCO1PUSA

Product Type:

Parts Manual

👋 Introduction

Vehicle Segment:

All-Terrain Vehicle (ATV) - 2-Up Sports Utility Vehicle (SUV)

Key Competitors:

Polaris Sportsman Touring, Can-Am Outlander MAX, Yamaha Grizzly 550/700.

Intended Use:

Designed for two-up riding, touring, utility work, and recreational trail riding.

Cruiser Variant:

Indicates a focus on comfort and touring features, often including enhanced seating and storage.

📋 Manual Details

Coverage Scope:

Comprehensive parts listing and illustration for the 2012 Arctic Cat TRV 550 CRUISER.

Estimated Page Count:

High (Detailed Parts Catalog - typical range 300-600 pages for this type of vehicle)

Manual Type:

Factory Parts Manual

Language:

English

File Format:

PDF Download

📖 Manual Coverage

Engine Components:

Cylinder block, cylinder head, pistons, connecting rods, crankshaft, camshafts, valves, timing system, lubrication system, cooling system, intake system, exhaust system.

Drivetrain Components:

Transmission (CVT), drive shafts, differentials, axles, clutch components (primary and secondary).

Chassis And Suspension:

Frame, front suspension (A-arms, shocks, steering components), rear suspension (trailing arms, shocks, sway bar), swingarm, hubs, bearings.

Braking System:

Front and rear brake calipers, brake discs, brake lines, master cylinders, parking brake mechanism.

Electrical System:

Wiring harness, battery, starter motor, alternator, ignition system, lighting (headlights, taillights, indicators), switches, sensors, ECU.

Bodywork And Trim:

Body panels (fenders, plastics, racks), seat, handlebars, controls, headlights, taillights, mirrors, storage compartments.

Fuel System:

Fuel tank, fuel pump, fuel lines, fuel filter, carburetor/fuel injection components.

Cooling System:

Radiator, coolant hoses, water pump, thermostat, fan.

Part Identification:

Identification of all OEM part numbers for every component and sub-assembly.

Assembly Disassembly:

Detailed exploded views illustrating the order of assembly and disassembly for various systems.

Part Relationships:

Visual representation of how different parts fit together, crucial for correct installation.

Component Breakdown:

Systematic breakdown of complex assemblies into individual replaceable parts.

Depth Of Coverage:

Highly detailed for parts sourcing and replacement. Focuses on component identification and assembly, not repair procedures or diagnostics.

📊 Manual Specifications

File Type:

PDF

Printability:

Printable pages

Image Quality:

Zoomable, clear illustrations and text

Binding:

Digital Download (No physical binding)

Paper Type:

N/A (Digital File)

Required Software:

Adobe Reader, Foxit Reader, or compatible PDF reader

Search Functionality:

Searchable text for quick part number or component lookup

⚙️ Engine Specifications

Engine Type:

4-stroke, liquid-cooled, SOHC, V-Twin

Displacement:

545cc

Bore X Stroke:

Undisclosed in product info, but typically around 70mm x 71.3mm for this engine family.

Compression Ratio:

Undisclosed in product info.

Ignition System:

Electronic CDI

Horsepower:

Approx. 30-35 HP (Manufacturer claims vary, actual output can differ).

Torque:

Undisclosed in product info.

Fuel Delivery:

Fuel Injection (EFI) - Specific model details may vary, but EFI is common for this class/year.

Fuel Type:

Unleaded gasoline

Fuel Tank Capacity:

Approx. 5.25 gallons (20 liters)

🔧 Transmission

Transmission Type:

Automatic Continuously Variable Transmission (CVT)

Gear Selection:

High, Low, Reverse, Neutral, Park

Drive Modes:

2WD / 4WD with front differential lock

Engine Braking:

Integrated engine braking via CVT system

📐 Dimensions

Length:

Approx. 97.1 inches (2466 mm)

Width:

Approx. 48 inches (1219 mm)

Height:

Approx. 50 inches (1270 mm)

Wheelbase:

Approx. 56 inches (1422 mm)

Dry Weight:

Approx. 678 lbs (307.5 kg)

Gvw:

Undisclosed in product info.

Front Rack Capacity:

Approx. 100 lbs (45 kg)

Rear Rack Capacity:

Approx. 200 lbs (90 kg)

Ground Clearance:

Approx. 10.5 inches (267 mm)

🛡️ Safety Features

Crash Test Ratings:

N/A (ATVs are not subject to the same crash testing as passenger vehicles).

Braking System:

Hydraulic disc brakes front and rear.

Stability:

Independent front and rear suspension, 4WD with differential lock.

Seating:

Two-up seating with passenger handholds and backrest (typical for Cruiser models).

Lighting:

Dual 35W headlights, 8W brake light.

💡 Technology Features

Display:

Digital instrument cluster with speedometer, odometer, trip meter, tachometer, fuel gauge, clock, service indicator.

Traction Control:

Limited, primarily through 4WD system with differential lock.

Charging Port:

12V accessory outlet (for charging devices).

🔧 Maintenance

Oil Change Interval:

Typically every 50-100 hours or annually (refer to specific service manual for exact recommendations).

Air Filter Maintenance:

Inspect every 25 hours, clean/replace as needed, especially in dusty conditions.

Spark Plug Replacement:

Typically every 200-300 hours or annually.

Engine Oil Type:

SAE 0W-40 or 10W-40 Synthetic Motorcycle Oil (API SG or higher) - Specific Arctic Cat recommendations should be verified.

Engine Oil Capacity:

Approx. 2.5 quarts (2.4 liters) with filter change.

Coolant Type:

Ethylene glycol-based coolant (50/50 mix with distilled water).

Brake Fluid Type:

DOT 4 hydraulic brake fluid.

Gear Case Oil Type:

SAE 80W-90 API GL-4 hypoid gear oil.

Common Wear Items:

CVT belt, suspension bushings, wheel bearings, brake pads.

Electrical Connectors:

Occasional corrosion or loose connections in harsh environments.

Cooling System:

Overheating can occur if coolant levels are low or radiator fins are blocked.

📚 Vehicle History

Manufacturer:

Arctic Cat Inc. (Now owned by Textron Specialized Vehicles).

Platform:

The TRV platform is Arctic Cat's dedicated 2-up ATV line, evolving from earlier utility ATV designs.

550 Model:

The 550 engine displacement became a popular mid-range offering in the Arctic Cat ATV lineup for utility and sport-utility purposes.

Production Location:

Typically manufactured by Arctic Cat in Thief River Falls, Minnesota, USA.

🏆 Awards & Recognition

Atv Awards:

While specific awards for the 2012 TRV 550 CRUISER are not readily available, Arctic Cat ATVs generally received positive reviews for their utility and ride comfort in the utility ATV segment during this period.
