🏷️ Basic Information

Make:

Nissan

Model:

Cube

Year:

2012

Chassis Code:

Z12

Engine Code:

HR15DE

👋 Introduction

Positioning:

A comprehensive digital service and repair solution for owners and independent mechanics seeking factory-level data.

Comparison To Print:

Offers superior convenience, searchability, and instant access compared to traditional printed manuals.

Accessibility:

Accessible on any device with an internet connection and web browser (PC, laptop, smartphone, tablet).

Cost Effectiveness:

Provides significant cost savings over dealership labor rates.

📋 Manual Details

Coverage Scope:

Comprehensive service and repair information for the 2012 Nissan Cube.

Estimated Pages:

Thousands (digital format, equivalent to extensive printed manuals)

Type:

Service and Repair Manual Software (Online Access)

Language:

English

Format:

Online software accessible via web browser

Duration:

1 Year (with discounts for extension)

📖 Manual Coverage

Engine:

Detailed diagnostics, repair procedures, specifications, and overhaul for the HR15DE engine.

Transmission:

CVT (Continuously Variable Transmission) service, repair, diagnostics, and fluid specifications.

Brakes:

Hydraulic system, ABS (Anti-lock Braking System), EBD (Electronic Brakeforce Distribution), parking brake, repair procedures, bleeding, and component replacement.

Suspension:

Front and rear suspension components, alignment specifications, shock absorbers, springs, bushings, and repair.

Steering:

Power steering system (electric), steering column, rack and pinion, tie rod ends, and diagnostics.

Electrical System:

Comprehensive wiring diagrams, component location, diagnostic procedures for ECUs, sensors, actuators, lighting, and accessories.

Body And Chassis:

Body panel removal/installation, door mechanisms, glass, seals, structural components, and rust prevention.

HVAC:

Air conditioning, heating, ventilation system diagnosis, refrigerant handling, component replacement, and performance testing.

Fuel System:

Fuel pump, injectors, fuel filter, evaporative emission control system (EVAP), and pressure testing.

Cooling System:

Radiator, water pump, thermostat, hoses, coolant specifications, and pressure testing.

Exhaust System:

Catalytic converter, mufflers, pipes, and mounting components.

Maintenance:

Scheduled maintenance tasks, fluid changes, filter replacements, inspections, and lubrication.

Troubleshooting:

Diagnostic flowcharts and symptom-based troubleshooting for common and complex issues.

Repair:

Step-by-step instructions for component removal, disassembly, repair, assembly, and installation.

Diagnostics:

OBD-II diagnostics, reading trouble codes (DTCs), live data interpretation, and advanced electronic diagnostics.

Specifications:

Torque specifications, clearances, fluid capacities, electrical values, and diagnostic parameters.

Depth:

Factory-level technical information, suitable for professional technicians and advanced DIY enthusiasts.

📊 Manual Specifications

Digital Format:

Proprietary RepairSurge online platform, web-based.

Print Quality Expectation:

High-resolution digital content, optimized for screen viewing and potential printing of individual sections.

Binding Type:

Not applicable (digital format)

Paper Type:

Not applicable (digital format)

Text Search:

Yes, full text search capabilities within the platform.

User Interface:

Intuitive interface with categorized sections, hyperlinked cross-references, and clear navigation menus.

Licensing:

Officially licensed, derived from OE (Original Equipment) materials.

⚙️ Engine Specifications

Engine Name:

HR15DE

Engine Type:

Inline 4-cylinder, DOHC, 16-valve

Displacement:

1.5 Liters (1498 cc)

Horsepower:

Approx. 109 hp @ 6000 rpm (JDM specification, may vary slightly by market)

Torque:

Approx. 104 lb-ft @ 4400 rpm (JDM specification, may vary slightly by market)

Induction:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded Gasoline

ECU:

Nissan EGI (Electronic Gasoline Injection) control unit, with comprehensive diagnostic capabilities.

Timing System:

Timing Chain Driven (Dual Overhead Camshafts)

🔧 Transmission

Transmission Type:

CVT (Continuously Variable Transmission)

Optional Transmissions:

N/A for the 2012 US Market model.

Cvt Features:

Includes modes like 'D' (Drive), 'L' (Low gear simulation), and potentially an 'S' (Sport) mode depending on trim.

Transmission Fluid Type:

Nissan NS-2 (or equivalent as specified by Nissan for CVT applications).

Fluid Capacity Approx:

Approx. 3.5 - 4.0 Liters (for initial fill, check manual for exact capacity and procedure).

📐 Dimensions

Length:

Approx. 4115 mm (162.0 in)

Width:

Approx. 1680 mm (66.1 in)

Height:

Approx. 1645 mm (64.8 in)

Wheelbase:

Approx. 2530 mm (99.6 in)

Curb Weight:

Approx. 1140 - 1200 kg (2513 - 2646 lbs) depending on trim and options.

Gross Vehicle Weight Rating:

Varies by market and trim, consult vehicle placard.

🛡️ Safety Features

NHTSA Ratings:

Generally good for its class, consult NHTSA for specific year ratings.

ABS:

Standard Anti-lock Braking System.

Ebd:

Standard Electronic Brakeforce Distribution.

Traction Control:

Typically included as part of Vehicle Dynamic Control (VDC).

Vehicle Dynamic Control:

Standard VDC system for enhanced stability.

Airbags:

Front airbags, front side-impact airbags, and roof-mounted side-impact airbags.

Seatbelts:

Three-point seatbelts with pretensioners and load limiters for front seats.

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for Children) system.

💡 Technology Features

Infotainment System:

Features could include a standard AM/FM/CD audio system, with optional navigation and Bluetooth connectivity depending on trim level.

Parking Assistance:

Optional rear parking sensors or a rearview camera system might be available on higher trims.

Bluetooth Connectivity:

Optional Bluetooth hands-free calling and audio streaming.

🔧 Maintenance

Oil Change Interval:

Typically every 5,000 to 7,500 miles (8,000 to 12,000 km) or 6 months, whichever comes first, depending on driving conditions (consult manual for specific recommendation).

Engine Air Filter Interval:

Inspect every 15,000 miles (24,000 km), replace as needed or at approx. 30,000 miles (48,000 km).

Cabin Air Filter Interval:

Inspect every 15,000 miles (24,000 km), replace as needed or at approx. 20,000 miles (32,000 km).

Transmission Fluid Interval:

CVT fluid is often considered 'lifetime' by some manufacturers, but it is highly recommended to change at intervals like 60,000 miles (96,000 km) or as per severe service schedule to prolong CVT life. Consult the manual for specific recommendations.

Engine Oil Type:

0W-20 Synthetic (API SN or ILSAC GF-5 certified).

Engine Oil Capacity:

Approx. 4.0 US Quarts (3.8 Liters) with filter change.

Coolant Type:

Nissan Genuine Long Life Coolant (Blue) or equivalent silicate-free, ethylene glycol-based coolant.

Brake Fluid Type:

DOT 3 or DOT 4.

Cvtf Deterioration:

Like many CVTs, premature deterioration of the CVT fluid can lead to transmission issues; regular fluid changes are key.

Idling Instability:

Can sometimes be related to dirty throttle bodies or faulty sensors (e.g., MAF sensor, O2 sensors).

Suspension Wear:

Front suspension components like ball joints and control arm bushings can experience wear over time, especially in areas with poor road conditions.

📚 Vehicle History

Nissan Heritage:

Nissan boasts a long history of producing reliable and innovative vehicles, particularly known for its compact and practical offerings.

Cube Generations:

The 2012 model represents the third generation of the Nissan Cube, which debuted globally in 2008. It evolved from its quirky, compact Japanese origins into a more widely appealing, though still distinctive, vehicle.

Production Location:

Primarily produced in Japan (e.g., Oppama Plant).

🏆 Awards & Recognition

General Perception:

While not a major award winner, the Cube is recognized for its unique styling, practicality, and fuel efficiency within its segment.
