Target Audience:
Youth riders, beginner off-road enthusiasts, and home mechanics
Competitors:
Honda CRF series, Kawasaki KLX series, Suzuki DR-Z series
Ease Of Use:
Designed for simplicity and user-friendliness in maintenance and operation
Durability:
Yamaha's reputation for robust and reliable small-displacement engines
Manual Value:
Provides crucial information for maintaining peak performance and longevity
Engine Overhaul:
Complete disassembly, inspection, and reassembly of engine components
Fuel System:
Carburetor adjustment, cleaning, and overhaul; fuel tank and lines
Ignition System:
CDI unit, spark plug, ignition coil testing and replacement
Electrical System:
Wiring diagrams, lighting, battery, charging system diagnostics
Drivetrain:
Clutch operation and adjustment, gearbox inspection and repair
Suspension:
Front fork and rear shock absorber service, adjustment, and replacement
Brakes:
Drum brake servicing, lever and cable adjustments
Wheels And Tires:
Tire pressure, spoke tension, wheel bearing maintenance
Frame And Bodywork:
Chassis inspection, handlebar and control lever replacement, seat and plastic bodywork
Routine Maintenance:
Oil changes, filter cleaning/replacement, chain adjustment, spark plug checks
Troubleshooting Guides:
Systematic diagnosis of common and uncommon operational issues
Repair Procedures:
Step-by-step instructions for component replacement and repair
Diagnostic Techniques:
Methods for identifying the root cause of performance problems
Adjustment Procedures:
Carburetor, clutch, throttle, and brake adjustments
Depth:
Comprehensive (from basic maintenance to full engine rebuild)
Searchability:
Text-searchable content for quick information retrieval
Printability:
High-quality, printable pages
Binding Type:
Digital (N/A)
Paper Type:
Digital (N/A)
Operating Systems:
Windows, macOS, Linux
Software Requirements:
Adobe Acrobat Reader or compatible PDF viewer
Download Method:
Instant High-Speed Download
Engine Type:
Four-stroke, SOHC, air-cooled
Bore X Stroke:
50.0 mm x 55.0 mm
Lubrication System:
Wet sump
Horsepower Estimate:
Approx. 7.4 HP @ 8,000 RPM (Actual may vary slightly)
Torque Estimate:
Approx. 7.1 Nm @ 6,500 RPM (Actual may vary slightly)
Fuel Delivery:
Mikuni VM17 carburetor
Fuel Type:
Unleaded gasoline (87 octane or higher recommended)
Fuel Tank Capacity:
3.0 Liters (0.8 US gal)
Spark Plug Type:
NGK CR7E or similar
Valve Clearance Intake:
0.08 - 0.13 mm (0.003 - 0.005 in)
Valve Clearance Exhaust:
0.08 - 0.13 mm (0.003 - 0.005 in)
Transmission Type:
Automatic (Centrifugal clutch, 4-speed constant mesh)
Optional Transmission:
N/A
Clutch Operation:
Automatic centrifugal clutch, no manual clutch lever
Gear Selection:
Foot shifter (1-N-2-3-4)
Transmission Oil Type:
Yamalube 4 (or SAE 10W-40 API SE, SF, SG, SH, SJ type)
Transmission Oil Capacity:
0.95 Liters (1.0 US qt) for overhaul
Safety Certification:
Not applicable for off-road use (Designed for closed course/off-road)
Braking System:
Front and Rear Drum Brakes
Throttle Limiter:
Potential for governor adjustments, but not a standard feature on this model
Lighting:
Headlight, Taillight/Brake light
Engine Oil Change:
Every 1,000 km (600 miles) or 6 months, whichever comes first; or more frequently under severe use.
Air Filter Cleaning:
Every 100 km (60 miles) or monthly, clean more often in dusty conditions.
Spark Plug Check:
Every 1,000 km (600 miles)
Chain Lubrication Adjustment:
Every 200 km (120 miles) or after washing/riding in wet conditions.
Valve Clearance Check:
Every 4,000 km (2,500 miles)
Engine Oil Spec:
Yamalube 4 (or SAE 10W-40 API SE, SF, SG, SH, SJ type)
Brake Fluid Spec:
DOT 3 or DOT 4 brake fluid (for brake master cylinder and caliper if applicable)
Engine Oil Capacity:
0.80 Liters (0.85 US qt) for oil change without filter replacement
Common Wear Items:
Chain and sprockets, brake pads/shoes, tires, air filter, spark plug.
Carburetor Tuning:
May require periodic adjustments due to environment or fuel variations.
Clutch Engagement:
Centrifugal clutch can wear over time, affecting smooth engagement.
Yamaha Legacy:
Yamaha's extensive history in motorcycle manufacturing, known for innovation and reliability in off-road and performance segments.
Ttr Lineage:
The TTR series represents Yamaha's commitment to entry-level and youth off-road motorcycles, offering accessible performance and durability.
Production Years:
The TTR 110 E has been in production since 2008, with the 2012 model being part of its initial generations.
Manufacturing Location:
Likely manufactured in Japan or Southeast Asia by Yamaha Motor Corporation.
