Segment:
Compact Crossover SUV
Key Competitors 2013-2017:
Toyota RAV4, Honda CR-V, Ford Escape, Nissan Rogue, Hyundai Tucson, Kia Sportage.
Platform:
GM Theta platform.
Convenience:
Single, easy-to-use PDF manual, reducing need to flip through multiple books.
Durability:
Protects original manuals from wear and tear; digital backup.
Primary Coverage:
Comprehensive service and repair for all 2013-2017 Chevrolet Equinox models.
Scope:
Vehicle-specific repair and maintenance information, not generic.
Estimated Page Count:
Extensive (specific number not provided, but implied to be very comprehensive)
Type:
Factory Service and Repair Manual
Accessibility:
Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac compatible.
Engine:
Detailed diagnostics, repair, and overhaul of engine components, including timing, lubrication, and cooling systems.
Engine Control:
Engine control system diagnostics, fuel delivery, ignition, emissions, and sensors.
Transmission:
Automatic transmission service, repair, and diagnostic procedures; manual transmission details (if applicable for specific trims).
Drivetrain:
Transfer case, propeller shaft, drive shafts, differentials, axles, and hub maintenance and repair.
Suspension Steering:
Front and rear suspension components, power steering system, steering column, and wheel alignment.
Brakes:
Hydraulic brake systems, ABS, traction control, parking brake, and brake component replacement.
Electrical:
Complete electrical system coverage, including starting and charging systems, lighting, wiring schematics, and multiplex/CAN communication.
Climate Control:
Air conditioning system diagnosis, service, and repair.
Safety Restraint:
Supplemental restraint system (airbags), seat belts, and associated sensors and control modules.
Body Exterior:
Exterior body panels, doors, hood, glass, mirrors, and trim.
Body Interior:
Interior components, instrument panel, seats, door locks, and trim.
Driver Controls:
Cruise control, wipers, washers, horns.
Maintenance:
Routine maintenance tasks, fluid checks, filter replacements, and inspections.
Diagnostics:
Troubleshooting guides and diagnostic procedures for all major systems.
Repair:
Step-by-step repair instructions for component replacement and system overhauls.
Installation:
Procedures for installing new parts and accessories.
Wiring Schematics:
Detailed wiring diagrams for all electrical circuits.
Depth:
Factory-level detail, covering from basic maintenance to complex diagnostics and major component repairs.
Detail Level:
Complete step-by-step instructions, diagrams, illustrations, and specifications.
Engine Code:
LAF (2.4L Ecotec)
Displacement:
2.4 Liters (2393 cc)
Configuration:
Inline-4, DOHC, 16 valves
Horsepower Peak:
Approx. 182 hp @ 6700 rpm (varies slightly by year)
Torque Peak:
Approx. 172 lb-ft @ 4900 rpm (varies slightly by year)
Fuel System:
Port Fuel Injection (PFI)
Engine Code:
LFX (3.6L V6 LGX)
Displacement:
3.6 Liters (3564 cc)
Configuration:
V6, DOHC, 24 valves, Variable Valve Timing (VVT)
Horsepower Peak:
Approx. 301 hp @ 6500 rpm
Torque Peak:
Approx. 272 lb-ft @ 4800 rpm
Fuel System:
Direct Injection (DI)
Overall Length:
Approximately 180.5 inches (4585 mm)
Overall Width:
Approximately 72.5 inches (1842 mm)
Overall Height:
Approximately 65.0 inches (1651 mm)
Wheelbase:
Approximately 106.3 inches (2700 mm)
Curb Weight:
Approx. 3,500 - 4,000 lbs (1588 - 1814 kg), depending on engine and drivetrain.
Cargo Volume Behind 1St Row:
Approx. 63.7 cubic feet (1804 L)
Cargo Volume Behind 2Nd Row:
Approx. 31.5 cubic feet (892 L)
NHTSA Overall Rating:
Generally rated 5-star overall by NHTSA for most configurations (check specific year for exact ratings).
IIHS Top Safety Pick:
Likely received 'Good' ratings in most IIHS tests for this generation, potentially earning Top Safety Pick designations.
Standard Active Safety:
StabiliTrak (Electronic Stability Control), Traction Control System (TCS), Anti-lock Braking System (ABS).
Standard Passive Safety:
Front airbags, front side-impact airbags, curtain side-impact airbags, rear side-impact airbags, active head restraints.
Infotainment System:
Available IntelliLink infotainment system with touchscreen interface, Bluetooth connectivity, and optional navigation.
Available Driver Aids:
Available features include rearview camera, rear parking assist, blind-spot monitoring, and rear cross-traffic alert.
Connectivity Features:
USB ports, auxiliary audio input, Bluetooth for hands-free calling and audio streaming.
Oil Change Interval:
Typically 7,500 miles or 6 months, whichever comes first, using synthetic oil.
Tire Rotation Interval:
Every 7,500 miles (aligned with oil changes).
Engine Air Filter:
Inspect every 22,500 miles, replace as needed. Recommended replacement around 45,000 miles.
Cabin Air Filter:
Replace every 15,000 - 25,000 miles, depending on driving conditions.
Transmission Fluid:
Check fluid level regularly; fluid change typically at 60,000 - 100,000 miles or under severe service conditions.
Engine Oil:
SAE 0W-20 full synthetic engine oil. (API SN, ILSAC GF-5)
Engine Coolant:
DexCool (Orange) OAT coolant. GM part #88862472 or equivalent. A 50/50 mixture with distilled water is standard.
Transmission Fluid Automatic:
Dexron VI Automatic Transmission Fluid (ATF). GM part #88863400 or equivalent.
Brake Fluid:
DOT 3 or DOT 4 brake fluid.
Power Steering Fluid:
GM Power Steering Fluid (GM part #10953753 or equivalent).
Common Problems 2.4L Engine:
Oil consumption, timing chain stretching (especially on earlier Ecotec engines), direct injection carbon buildup.
Common Problems 3.6L Engine:
Timing chain guide issues (on some earlier engines), oil leaks, intake manifold issues.
Common Problems Transmission:
Slipping or hard shifting (especially the 6-speed automatic on higher mileage vehicles).
Common Problems Electrical:
Issues with infotainment system glitches, power liftgate malfunctions, and certain sensor failures.
Brand:
Chevrolet, a division of General Motors (GM), with a long history in American automotive manufacturing.
Second Generation Introduction:
The second generation Equinox was introduced for the 2010 model year and received a significant refresh for 2013, which is covered by this manual.
Manufacturing Locations:
Assembly plants included Oshawa, Ontario, Canada, and Spring Hill, Tennessee, USA.
