Target Audience:
Dodge Dart owners seeking to perform maintenance and repairs, independent repair shops, and DIY enthusiasts.
Value Proposition:
Provides factory-authorized information for accurate and efficient vehicle servicing, reducing reliance on costly dealership labor.
Differentiation:
Vehicle-specific, not generic; replicates the exact information used by dealership technicians.
Features Summary:
Step-by-step instructions, diagrams, illustrations, wiring schematics, torque specifications, diagnostic procedures.
Ease Of Use:
Single, searchable PDF format eliminates the need to consult multiple physical books.
General Coverage:
Comprehensive A-Z repair, maintenance, diagnosis, and service
Specific Systems Covered:
Engine, transmission (automatic and manual), chassis, electrical, body, HVAC, safety systems, emissions, fuel, suspension, steering, brakes, interior, exterior.
Estimated Page Count:
Extensive (precise number not provided, but described as comprehensive)
Type:
Factory Service and Repair Manual
File Compatibility:
Windows (Vista32/64, XP, ME, 98, NT, 2000) and Mac OS
Engine Mechanical:
Detailed repair, overhaul, and diagnosis for all engine variants.
Engine Control System:
ECU diagnosis, sensor testing, actuator control, and troubleshooting.
Transmission Automatic:
Service, repair, and overhaul procedures for automatic transmissions.
Transmission Manual:
Service, repair, and overhaul procedures for manual transmissions.
Suspension Steering:
Diagnosis, repair, and alignment procedures for suspension and steering components, including power steering.
Brake Control:
ABS, ESC, EBD system diagnosis, repair, and bleeding procedures.
Electrical Systems:
Comprehensive wiring schematics, component testing, and troubleshooting for all electrical circuits.
Multiplex Can Communication:
Diagnosis and troubleshooting of CAN bus networks and multiplexed systems.
Safety Systems:
SRS (Supplemental Restraint System) diagnosis and component replacement, seat belt service.
HVAC:
Air conditioning system service, refrigerant handling, and diagnosis.
Fuel Service:
Fuel pump testing, injector service, fuel filter replacement, and fuel system diagnosis.
Body Interior Exterior:
Repair and replacement of body panels, doors, windows, mirrors, seats, and interior trim components.
Routine Maintenance:
Oil changes, filter replacements, fluid checks, tire rotations, spark plug replacement, and general inspections.
Diagnostic Procedures:
Step-by-step diagnostic flowcharts for various symptoms and system failures.
Repair Procedures:
Detailed, illustrated instructions for component removal, installation, and repair for all major systems.
Troubleshooting:
Specific troubleshooting guides for common and uncommon issues.
Specifications Data:
Torque specifications, fluid capacities, diagnostic trouble codes (DTCs), alignment specs, electrical values.
Emission Control Service:
Diagnosis and repair of emission control systems, including EVAP, catalytic converters, and oxygen sensors.
Depth:
Factory level detail, suitable for professional technicians and advanced DIY enthusiasts.
Wiring Schematics Detail:
Detailed and comprehensive wiring diagrams for all electrical systems, including component location and wire color codes.
Engine Options Covered:
1.4L MultiAir Turbo I4, 2.0L Tigershark I4, 2.4L Tigershark I4.
1.4L Multiair Turbo Horsepower:
160 hp @ 5,500 rpm
1.4L Multiair Turbo Torque:
184 lb-ft @ 2,500-4,000 rpm
2.0L Tigershark Horsepower:
160 hp @ 6,400 rpm
2.0L Tigershark Torque:
148 lb-ft @ 4,600 rpm
2.4L Tigershark Horsepower:
184 hp @ 6,400 rpm
2.4L Tigershark Torque:
171 lb-ft @ 4,800 rpm
Fuel Delivery:
Multi-point fuel injection (MPI) or Direct Injection (DI) depending on engine
Fuel Type:
Unleaded gasoline (87 octane recommended, 91 octane recommended for 1.4L Turbo for optimal performance)
Standard Transmission Type:
6-speed manual transmission (e.g., BPS61, C630) for 1.4L Turbo and some 2.0L engines.
Optional Transmission Type:
6-speed Dual Dry Clutch Transmission (DDCT, e.g., T4) for 1.4L Turbo; 6-speed automatic transmission (e.g., 6T40 variant) for 2.0L and 2.4L engines.
Transmission Features:
Includes detailed procedures for clutch service, torque converter inspection, valve body diagnosis, and transmission fluid service.
NHTSA Overall Rating:
Not consistently rated across all configurations due to testing changes; generally good frontal and side impact ratings.
Active Safety Features:
Anti-lock Braking System (ABS), Electronic Stability Control (ESC), Traction Control System (TCS), Brake Assist.
Passive Safety Features:
Front airbags, front side airbags, side curtain airbags, driver's knee airbag.
Infotainment Options:
Uconnect multimedia system, touchscreen displays (e.g., 8.4-inch), Bluetooth connectivity, USB ports, navigation system options.
Driver Assistance Systems:
Parking assist systems, rearview camera (on some trims).
Connectivity Features:
Voice command, satellite radio (SiriusXM), remote start (optional).
Oil Change Interval:
Refer to specific engine: typically 8,000 miles or 6 months, or as indicated by the oil change indicator system.
Tire Rotation Interval:
Every 7,500-10,000 miles or as per manual recommendation.
Spark Plug Replacement:
100,000 miles for iridium-tipped spark plugs (typical for the engines used).
Engine Oil Specification:
SAE 0W-20 synthetic blend or full synthetic (e.g., MS-6395 specification). Refer to manual for exact viscosity and spec for each engine.
Coolant Specification:
OAT (Organic Acid Technology) type, pink/red color, Chrysler specification MS-9812. (e.g., Mopar Antifreeze/Coolant HOAT)
Transmission Fluid Automatic:
Refer to specific transmission type; generally ATF+4 or equivalent for 6-speed automatic, or specific fluid for DDCT.
Brake Fluid Specification:
DOT 3 or DOT 4 brake fluid.
Common Issues Covered:
The manual would detail common concerns such as potential issues with the PowerShift transmission clutch packs, turbocharger issues on the 1.4L engine, power steering system components, and various electrical gremlins typical of modern vehicles.
Dodge Brand Legacy:
Dodge has a long history of producing a diverse range of vehicles, from muscle cars to practical sedans and minivans.
Dart Legacy:
The Dart nameplate was previously used by Chrysler/Dodge from 1960-1976, known for its robust construction and affordability. The 2013 model marked a revival of the nameplate on a modern global platform.
Production Location:
Belvidere, Illinois, USA (Belvidere Assembly Plant)
Production Years For Generation:
2013-2016
