2013 Lincoln MKT Workshop Repair Service Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Lincoln Model: MKT Year: 2013 Codes Vin Prefix Codes: 1LNK Chassis Code: U539 Platform: Ford D4 👋 Introduction Market Position Segment: Full-size Luxury Crossover SUV...

29 people are viewing this right now

类型: Car

斯库: 359229

标签: 2013 Car Cars Featured Lincoln MKT

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Lincoln

Model:

Year:

Codes

Vin Prefix Codes:

Chassis Code:

Platform:

Ford D4

👋 Introduction

Market Position

Segment:

Full-size Luxury Crossover SUV

Target Audience:

Families and individuals seeking a spacious, comfortable, and technologically advanced luxury SUV with a focus on practicality and refined styling.

Competitive Analysis

Key Competitors:

• Cadillac SRX

• BMW X5

• Mercedes-Benz M-Class

• Audi Q7

• Acura MDX

• Infiniti JX35/QX60

• Volvo XC90

Key Features

Design Philosophy:

The MKT aimed to blend the traditional luxury of a sedan with the utility of an SUV, featuring a distinctive three-bar grille, a sleek profile, and a spacious interior.

Interior Comfort:

Known for its comfortable and quiet cabin, often featuring premium materials, advanced climate control, and optional features like second-row captain's chairs and a panoramic sunroof.

Powertrain Options:

Offered with a range of potent V6 engines, including turbocharged EcoBoost variants, providing a balance of power and efficiency. Available with front-wheel drive or intelligent all-wheel drive.

Technology Integration:

Equipped with Lincoln's SYNC infotainment system, offering features like voice recognition, Bluetooth connectivity, and navigation. Driver assistance technologies were also available.

📋 Manual Details

Coverage Areas

Systems Covered:

• Engine Overhaul and Rebuilding

• Brakes

• Sunroof

• Timing Belt Replacement

• Trouble Codes

• Wiring Diagrams

• Troubleshooting and Diagnostics

• Computer Diagnostic Trouble Tree Charts

• Engine Performance

• Front End and Alignment Procedures and Specifications

• Suspension

• Transmission Removal and Installation

• Air Conditioning Service and Capacities

• Transmission In-Car Servicing

• Computer Diagnostic Codes

• Firing Orders

• Factory Maintenance Schedules and Charts

• Serpentine Belt Routings with Diagrams

• Timing Belt Service Procedures

• Brake Servicing Procedures

• Driving Concerns

• U-Joint and CV-Joint Service Procedures

• Repair Procedures

• Vacuum Diagrams

• Electrical System

• Fuel System

• Exhaust System

• Cooling System

• Steering System

• Body and Chassis

• Interior Components

• Exterior Components

• Climate Control

• Audio System

• Navigation System

• Security System

Procedures Included:

• Engine disassembly and assembly

• Fuel injection system diagnosis and repair

• Ignition system diagnosis and repair

• Cooling system maintenance and repair

• Brake system inspection, service, and repair

• Suspension component replacement and alignment

• Steering component replacement and alignment

• Drivetrain component service

• Transmission fluid service and filter replacement

• Air conditioning system charging and leak detection

• Electrical system troubleshooting using wiring diagrams

• Body panel removal and installation

• Interior trim removal and installation

• Scheduled maintenance procedures

• Diagnostic trouble code interpretation and resolution

• Torque specifications for all major components

• Exploded diagrams for parts identification and service

Page Count

Estimated Page Count:

Approximately 2000+ pages (typical for comprehensive workshop manuals of this era)

Manual Type

Type:

Workshop Repair Service Manual

Language

Language:

English

Format

Format:

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Comprehensive coverage including engine overhaul, rebuild procedures, cylinder head service, piston and ring replacement, crankshaft and bearing service, camshaft and valve train maintenance, timing belt/chain replacement, and lubrication system service.

Engine Performance:

Detailed diagnosis and repair of engine performance issues, including fuel delivery, ignition timing, air intake, exhaust emissions, and engine control module (ECM) diagnostics.

Transmission:

Covers both automatic and potentially available manual transmissions (though primarily automatic for MKT). Includes removal, installation, in-car servicing, fluid changes, filter replacement, and internal component repair. Specifications for transmission fluid types and capacities are provided.

Brakes:

In-depth coverage of the braking system, including disc brake service (pads, rotors), drum brake service (if applicable), hydraulic system diagnosis, ABS system troubleshooting, parking brake service, and brake fluid specifications.

Suspension:

Detailed procedures for suspension component replacement, including struts, shock absorbers, control arms, ball joints, tie rod ends, bushings, and coil springs. Alignment specifications and procedures are included.

Steering:

Covers power steering system diagnosis and repair, steering column service, rack and pinion replacement, and related components. Wheel alignment specifications are integral.

Electrical System:

Extensive coverage of the vehicle's electrical system, including battery, starting system, charging system, lighting systems, infotainment systems, power accessories, and body control modules. Comprehensive wiring diagrams are a key component.

Climate Control:

Service and repair procedures for the heating, ventilation, and air conditioning (HVAC) system, including refrigerant charging, leak detection, component replacement (compressor, condenser, evaporator), and control module diagnostics.

Body And Chassis:

Procedures for body panel repair, door and latch service, interior trim removal and installation, glass replacement, and underbody component maintenance.

Diagnostics:

Detailed diagnostic procedures for a wide range of issues, including the use of diagnostic scan tools, interpretation of diagnostic trouble codes (DTCs), and troubleshooting flowcharts for specific symptoms.

Procedures Included

Maintenance:

Factory-recommended maintenance schedules, fluid change intervals, filter replacement procedures, and general upkeep guidelines.

Troubleshooting:

Step-by-step troubleshooting guides for common and uncommon vehicle problems, utilizing diagnostic charts, symptom analysis, and component testing.

Repair:

Detailed repair procedures for virtually all mechanical, electrical, and body components, with clear instructions, torque specifications, and diagrams.

Overhaul:

Complete engine and transmission overhaul procedures, guiding the user through complete disassembly, inspection, component replacement, and reassembly.

Diagnostics Trouble Codes:

Extensive list of diagnostic trouble codes (DTCs), their meanings, and specific troubleshooting trees to identify the root cause of illuminated warning lights and system malfunctions.

Wiring Diagrams:

High-quality, comprehensive wiring diagrams for all major vehicle systems, allowing for accurate diagnosis and repair of electrical circuits.

Alignment:

Detailed front and rear wheel alignment procedures and specifications, including caster, camber, and toe angles.

Component Replacement:

Step-by-step instructions for replacing all major and minor components, from spark plugs and filters to complex engine and transmission parts.

Technical Depth

Depth:

Comprehensive (A-Z coverage), suitable for both novice DIYers and experienced technicians. Includes detailed technical data, exploded diagrams, and step-by-step instructions.

Illustrations:

Hundreds of detailed illustrations, exploded diagrams, and photos to guide users through repair procedures.

Torque Specifications:

Complete torque specifications for all critical fasteners and components, ensuring proper assembly and preventing damage.

Fluid Capacities:

Accurate fluid capacities for engine oil, transmission fluid, coolant, brake fluid, power steering fluid, and windshield washer fluid.

Schematics:

Vacuum diagrams and detailed electrical schematics are provided for comprehensive system understanding and troubleshooting.

📊 Manual Specifications

File Format

Format:

Compatibility:

All Versions of Windows, Mac, iOS, BB, Android, etc.

Requirements:

PDF Reader

Print Quality

Printable:

Print Features:

Printable pages for use in workshop/garage environments.

Binding Type

Binding:

Digital (Instant Download)

Paper Type

Paper Type:

N/A (Digital Format)

Completeness

Completeness Guarantee:

100% Complete and Intact, no missing/corrupt pages/sections.

⚙️ Engine Specifications

Primary Engine

Engine Code And Type:

Duratec 3.7L V6 (typically)

Displacement:

3.7 Liters (3700 cc)

Configuration:

Naturally Aspirated V6

Bore X Stroke:

95.5 mm x 86.1 mm (approximate)

Compression Ratio:

10.7:1 (approximate)

Horsepower:

305 hp @ 6500 rpm (approximate)

Torque:

280 lb-ft @ 4000 rpm (approximate)

Performance

Optional Engine:

EcoBoost 3.5L V6 Twin-Turbocharged

Optional Engine Hp:

355 hp @ 5700 rpm (approximate)

Optional Engine Torque:

380 lb-ft @ 1500-5250 rpm (approximate)

Fuel System

Fuel Delivery:

Sequential Multi-Port Fuel Injection (PFI) for 3.7L; Direct Injection (DI) for 3.5L EcoBoost.

Fuel Type:

Regular Unleaded 87 Octane (minimum recommended for 3.7L); Premium Unleaded 91 Octane or higher recommended for 3.5L EcoBoost.

Fuel Tank Capacity:

18.6 gallons (approximate)

Engine Management

Engine Control Module:

Powertrain Control Module (PCM) or Engine Control Module (ECM) with integrated diagnostics.

Firing Order:

1-4-2-5-3-6 (for V6 engines)

🔧 Transmission

Standard

Transmission Type:

6-Speed SelectShift Automatic Transmission

Transmission Code:

6F50 (likely)

Optional

Optional Transmission Type:

N/A (6-speed auto was standard across most configurations)

Features

Drive Configuration:

Available with Front-Wheel Drive (FWD) or Intelligent All-Wheel Drive (AWD).

Selectshift Functionality:

Manual shifting capability via paddle shifters on the steering wheel or gear selector.

Fluid Specifications

Transmission Fluid Type:

Mercon LV Automatic Transmission Fluid (ATF)

Fluid Capacities

Transmission Fluid Capacity:

Approximately 8.3 quarts (8.8 liters) for refill after filter change, higher for complete overhaul. Refer to manual for exact specifications.

📐 Dimensions

Exterior

Length:

207.0 inches (525.8 cm)

Width:

78.0 inches (198.1 cm)

Height:

65.1 inches (165.4 cm)

Wheelbase:

117.7 inches (299.0 cm)

Front Track:

64.8 inches (164.6 cm)

Rear Track:

64.0 inches (162.6 cm)

Interior

Passenger Volume:

110.5 cubic feet (3.13 m³)

Front Headroom:

40.4 inches (102.6 cm)

Front Legroom:

42.9 inches (109.0 cm)

Second Row Headroom:

40.0 inches (101.6 cm)

Second Row Legroom:

39.1 inches (99.3 cm)

Third Row Headroom:

37.7 inches (95.8 cm)

Third Row Legroom:

33.4 inches (84.8 cm)

Cargo

Cargo Volume Behind 3Rd Row:

23.7 cubic feet (0.67 m³)

Cargo Volume Behind 2Nd Row:

45.8 cubic feet (1.29 m³)

Cargo Volume Behind 1St Row:

88.3 cubic feet (2.50 m³)

Weights

Curb Weight:

Approximately 4,500 - 4,800 lbs (2041 - 2177 kg), depending on drivetrain and options.

Gross Vehicle Weight Rating:

Typically around 6,000 - 6,300 lbs (2722 - 2858 kg).

Towing Capacity:

2,000 lbs (907 kg) without trailer tow package; 3,500 lbs (1588 kg) with trailer tow package.

Wheels And Tires

Standard Wheel Size:

19-inch or 20-inch alloy wheels

Standard Tire Size:

255/55R19 or 255/50R20

Bolt Pattern:

5 x 114.3 mm (5 x 4.5 inches)

Center Bore:

70.6 mm

🛡️ Safety Features

Ratings

NHTSA Overall Rating:

Likely 5-Star (based on typical Lincoln performance in this era, though specific 2013 MKT ratings should be verified).

IIHS Top Safety Pick:

The MKT has historically achieved good ratings from IIHS, often earning Top Safety Pick designations in various years. Specific 2013 status needs verification.

Active Features

Standard Anti-lock Braking System (ABS)

Traction Control:

Standard Traction Control (TCS)

Electronic Stability Control:

Standard Electronic Stability Control (ESC), marketed as AdvanceTrac with Roll Stability Control.

Driver Assistance Options:

• Blind Spot Information System (BLIS)

• Cross-Traffic Alert

• Adaptive Cruise Control

• Collision Warning with Brake Support

• Lane Departure Warning

• Lane Keeping Assist

Passive Features

Airbags:

• Dual-stage front airbags

• Front-seat side-impact airbags

• Side curtain airbags (covering all three rows)

• Driver's knee airbag

Seat Belts:

3-point height-adjustable front seat belts with pretensioners and load limiters; 3-point seat belts for second and third row seating positions.

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for CHildren) system in second-row seating positions.

Rearview Camera:

Standard rearview camera.

💡 Technology Features

Infotainment

Infotainment System:

MyLincoln Touch infotainment system featuring an 8-inch touchscreen display, voice-activated commands, climate control integration, and multimedia management.

Connectivity Options:

• Bluetooth hands-free phone and audio streaming

• USB ports

• SD card reader

• Auxiliary audio input

• Available Navigation System

• Available HD Radio

• Available SiriusXM Satellite Radio

Audio System:

Standard premium audio system; optional upgrades include branded systems like Sony.

Driver Assistance

Adaptive Cruise Control:

Available adaptive cruise control system that can maintain a set speed and following distance from the vehicle ahead.

Blind Spot Monitoring:

Available Blind Spot Information System (BLIS) with cross-traffic alert.

Lane Departure Warning:

Available Lane Departure Warning system to alert the driver when unintentional lane drifting occurs.

Collision Warning:

Available Collision Warning with Brake Support, which alerts the driver to an impending collision and can pre-charge the brakes.

Parking Assistance:

Standard rearview camera; available active park assist for semi-automated parallel parking.

Connectivity

Sync System:

Ford's SYNC system with voice recognition for controlling audio, climate, and phone functions.

Smart Device Integration:

Integration with smartphones via Bluetooth for calls and audio streaming; USB for media playback and device charging.

🔧 Maintenance

Service Intervals

Oil Change Interval:

Every 7,500 miles or 6 months, whichever comes first, for synthetic blend oil. Consult manual for specific oil type and severe driving conditions.

Engine Air Filter:

Replace every 30,000 miles or as needed based on inspection.

Cabin Air Filter:

Replace every 15,000 miles or annually.

Transmission Fluid Change:

Recommended at 100,000 miles or if fluid appears discolored or burnt. Check manual for specific recommendations and severe duty cycles.

Coolant Change:

First change at 100,000 miles, then every 50,000 miles thereafter for the original coolant (typically a long-life orange coolant).

Spark Plugs:

Replace approximately every 100,000 miles (iridium-tipped spark plugs).

Fluid Specifications

Engine Oil:

SAE 5W-20 Synthetic Blend or Full Synthetic Oil. API Certified. Refer to manual for exact specification and capacity.

Coolant:

Ford Premium Engine Coolant - Orange (or equivalent meeting WSS-M97B44-D specification). A 50/50 mix with distilled water.

Brake Fluid:

DOT 3 High-Performance Brake Fluid.

Power Steering Fluid:

MERCON V or equivalent power steering fluid.

Known Issues

Transmission Performance:

Some owners have reported occasional rough shifting or hesitation from the 6-speed automatic transmission, particularly during initial model years. Software updates or transmission fluid service can sometimes mitigate these issues.

Infotainment System:

Early versions of the MyLincoln Touch system could be prone to lag or occasional glitches. Software updates are crucial for optimal performance. Calibration of touch-sensitive controls might be necessary.

Powertrain Issues Ecoboost:

While generally robust, some EcoBoost engines can be sensitive to fuel quality and maintenance. Issues like carbon buildup or turbocharger concerns can arise if not properly maintained, though less common on the 3.5L EcoBoost in the MKT compared to some other Ford applications.

Suspension Wear:

As with many vehicles in this class, suspension components like bushings, ball joints, and tie rod ends can experience wear over time, potentially leading to steering looseness or noises.

Fuel Pump Failures:

Reports of fuel pump failures have been noted in some vehicles of this generation, requiring replacement of the fuel pump module.

📚 Vehicle History

Brand Heritage

Lincoln Legacy:

Lincoln, Ford's luxury division, has a long history of producing premium vehicles known for comfort, quietness, and elegant styling, dating back to 1917.

Model Evolution

Mkt Introduction:

The Lincoln MKT was introduced for the 2010 model year as a 2011 model, representing Lincoln's entry into the luxury crossover segment with a distinctive design.

2013 Model Year Changes:

For the 2013 model year, the MKT received a refresh. Key updates included revised exterior styling (particularly the grille and rear fascia), interior enhancements, and the introduction of the 'MyLincoln Touch' infotainment system as standard on many trims. The EcoBoost engine became more widely available and refined.

Platform Sharing:

The MKT is built on Ford's D4 platform, which it shares with other Ford and Lincoln vehicles such as the Ford Edge and Lincoln MKX, contributing to development efficiency.

Production

Manufacturing Location:

Ford's Oakville Assembly Plant in Oakville, Ontario, Canada.

Production Run:

The Lincoln MKT was produced from the 2010 model year (as a 2011 model) through the 2019 model year. The 2013 model year represents the mid-cycle refresh.

🏆 Awards & Recognition

Recognitions

Design Awards:

While specific awards for the 2013 model year might be limited, the MKT's design has been noted for its distinctive styling in the luxury crossover segment.

Ratings

Consumer Satisfaction Index:

Lincoln's overall scores in consumer satisfaction surveys (like those from J.D. Power) generally place it in the upper half of the luxury segment, reflecting a focus on comfort and quietness, though sometimes trailing European luxury competitors in perceived performance and driving dynamics.

Certifications

Safety Certifications:

Vehicles are manufactured to meet all applicable U.S. Federal Motor Vehicle Safety Standards (FMVSS). As noted in the safety section, it typically achieves high ratings from NHTSA and IIHS.
