Vehicle Segment:
Mid-size luxury sedan
Brand Positioning:
Cadillac's entry into the competitive luxury sedan market, aiming to rival German and other premium brands.
Key Competitors:
BMW 5 Series, Mercedes-Benz E-Class, Audi A6, Lexus GS, Acura TLX.
Manual Advantage:
Vehicle-specific, factory-level detail identical to dealership technician manuals, comprehensive A-Z coverage, digital format for ease of use and portability.
Vehicle Highlight:
The 3rd Gen CTS represented a significant step forward in design, technology, and performance for Cadillac.
Primary Coverage:
2014 Cadillac CTS (3rd Generation)
Specific Trims Covered:
All trim levels (Standard, Luxury, Performance, Premium)
Estimated Page Count:
Varies significantly based on specific engine/options, but described as comprehensive.
Type:
Service and Repair Manual
Compatibility:
Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac
Software Requirements:
Adobe PDF Reader, Winzip (free online)
Engine:
Complete service, diagnosis, and repair of all available engine variants.
Engine Control System:
ECU, sensors, actuators, emissions control systems.
Transmission:
Automatic transmission service, diagnosis, and repair.
Manual Transmission:
Coverage for manual transmission variants if applicable.
Drivetrain:
Transfer case, propeller shaft, drive shafts, differential, axles.
Suspension Steering:
Front and rear suspension, steering column, power steering system.
Brakes:
Hydraulic brake system, ABS, traction control, parking brake.
Climate Control:
Air conditioning system, heating, ventilation.
Restraint Systems:
Supplemental Restraint System (SRS), airbags, seat belts.
Electrical System:
Complete vehicle electrical systems, including wiring schematics.
Body And Interior:
Doors, hood, exterior trim, interior components, seats, instrument panel, glass.
Multiplex Communication:
CAN communication, multiplex systems.
Cruise Control:
Adaptive cruise control and standard cruise control system.
Security Systems:
Engine immobilizer, door locks.
Wiper Washer:
Wiper and washer system operation and repair.
Audio Visual:
Meter, audio, and visual system diagnostics and repair.
Horns:
Horn system functionality and repair.
Maintenance:
Scheduled maintenance procedures, fluid changes, filter replacements.
Diagnostics:
Troubleshooting guides, diagnostic fault codes (DTCs), symptom-based diagnostics.
Repair:
Step-by-step repair instructions for virtually all vehicle components.
Rebuilds:
Engine and transmission rebuild procedures.
Installation:
Component replacement and installation procedures.
Depth:
Factory-level detail, suitable for professional technicians and advanced DIYers.
Detail Level:
Complete step-by-step instructions, diagrams, illustrations, wiring schematics, and specifications.
Engine Options:
2.0L Turbocharged Inline-4 (RPO LHU/LTG), 3.6L Naturally Aspirated V6 (RPO LGX/LF3 - Twin-Turbo in V-Sport)
2.0L Turbo Horsepower:
272 hp @ 5500 rpm
2.0L Turbo Torque:
295 lb-ft @ 1700-5500 rpm
3.6L V6 Horsepower:
321 hp @ 6800 rpm
3.6L V6 Torque:
275 lb-ft @ 4800 rpm
3.6L Twin-Turbo V6 (V-Sport) Horsepower:
420 hp @ 6000 rpm
3.6L Twin-Turbo V6 (V-Sport) Torque:
406 lb-ft @ 3500-4500 rpm
Fuel Type:
Premium Unleaded Gasoline recommended
Induction:
Port Fuel Injection (PFI) or Direct Injection (DI) depending on engine
Cooling Type:
Liquid-cooled
Transmission Type Std:
8-speed automatic (RPO MYD)
Transmission Type Opt:
All-wheel drive (AWD) available with automatic transmission.
Transmission Features:
Driver Shift Control, paddle shifters (on select trims).
Automatic Transmission Fluid:
Dexron-VI (Refer to manual for exact part number and capacity)
NHTSA Rating:
5-Star Overall Safety Rating (refer to NHTSA for specific year/crash test details)
IIHS Top Safety Pick:
Likely a Top Safety Pick designation (verify with IIHS for the specific year).
Active Safety Features:
ABS, Traction Control (TCS), StabiliTrak Electronic Stability Control, available Adaptive Cruise Control, Forward Collision Alert, Front and Rear Park Assist, Lane Departure Warning, Side Blind Zone Alert, Rear Cross-Traffic Alert, Intellibeam Headlights.
Passive Safety Features:
Driver and front passenger airbags, front and rear side-impact airbags, head curtain airbags, front knee airbags, active head restraints.
Infotainment System:
Cadillac CUE (Cadillac User Experience) system with an 8-inch touchscreen interface.
Infotainment Features:
Bluetooth connectivity, USB ports, SD card reader, AM/FM/SiriusXM satellite radio, voice recognition, Apple CarPlay/Android Auto (via software updates).
Driver Assistance Tech:
Available adaptive cruise control, forward collision alert, lane departure warning, blind-spot monitoring, rear cross-traffic alert.
Connectivity Features:
OnStar telematics system, Wi-Fi hotspot capability (subscription required).
Lighting:
Available LED headlights, LED daytime running lights.
Keyless Entry Start:
Keyless Access with Push Button Start.
Oil Change Interval:
Every 7,500 miles or 12 months, or as indicated by the Oil Life Monitor system.
Tire Rotation Interval:
Every 7,500 miles.
Cabin Air Filter:
Every 22,500 miles or 24 months.
Engine Coolant:
Initial change at 5 years or 150,000 miles, then every 30,000 miles or 24 months thereafter.
Engine Oil Specification:
SAE 0W-30 Synthetic (API SN, Dexos1 Gen2 or later specification required). Refer to manual for exact Dexos generation.
Power Steering Fluid:
Dexron-VI or equivalent GM Power Steering Fluid.
Common Issues Indicators:
Potential for some electronic glitches, particularly with infotainment and sensor systems. Some reports of turbocharger issues on early 2.0T models. Refer to manual for detailed diagnostic procedures.
Cadillac Legacy:
Long-standing American luxury automotive brand with a history of innovation and comfort.
Cts Generations:
This 3rd generation (2014-2019) was a significant redesign, moving to the new GM Alpha platform, offering improved dynamics and technology.
Manufacturing Location:
Lansing Grand River Assembly Plant, Lansing, Michigan, USA.
