Market Segment:
Compact sedan, known for fuel efficiency and value.
Key Competitors:
Honda Civic, Toyota Corolla, Ford Focus, Mazda3, Hyundai Elantra.
Vehicle Selling Points:
Affordability, good fuel economy, comfortable ride, modern styling, available advanced safety features.
Diy Savings:
Enables owners to perform maintenance and repairs, saving significant money on labor costs.
Ease Of Use:
Step-by-step instructions and pictures make complex tasks manageable for DIY enthusiasts.
Models Covered:
All Chevrolet Chevy Cruze models, engines, trim levels, and transmission types for the 2016 model year.
Estimated Page Count:
Not specified, but described as 'Complete Workshop Service Repair Manual', implying comprehensive detail.
Manual Type:
Workshop Service Repair Manual
Format:
Downloadable Digital Format (PDF compatible)
Powertrain:
Engine mechanical, engine performance, fuel system, lubrication system, cooling system, exhaust system, ignition system, starting system, charging system, automatic transmission, manual transmission.
Chassis:
Braking system (ABS, EBD, HSA), steering system, suspension system (front and rear), wheels and tires.
Body And Interior:
Body structure, exterior panels, doors, windows, interior trim, seats, HVAC (heating, ventilation, air conditioning), SRS (Supplemental Restraint System - airbags).
Electrical And Electronics:
Wiring diagrams, lighting system, power windows, power locks, mirrors, audio system, instrument cluster, Body Control Module (BCM), Engine Control Module (ECM), Powertrain Control Module (PCM), Diagnostic Trouble Codes (DTCs).
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement, brake pad replacement, tire rotation.
Troubleshooting:
Diagnostic procedures, symptom-based troubleshooting, identification of common problems, diagnostic trouble code (DTC) interpretation.
Repair And Rebuild:
Engine overhaul, transmission overhaul, brake caliper replacement, suspension component replacement, electrical component repair, body panel repair and replacement.
Diagnostics:
On-Board Diagnostics (OBD-II) system, scan tool usage, live data interpretation, component testing.
Depth:
Comprehensive from basic maintenance to advanced diagnostics and complete component overhaul, with step-by-step instructions and illustrations.
File Format:
PDF (Portable Document Format)
Print Quality:
High quality, suitable for printing individual pages or entire sections.
Binding Type:
Not applicable (digital download)
Paper Type:
Not applicable (digital download)
Required Software:
Adobe Reader (or compatible PDF viewer)
Engine Option 1 Name:
1.4L Turbocharged Ecotec
Engine Option 1 Codes:
LUV
Engine Option 1 Displacement:
1399 cc (1.4 L)
Engine Option 1 Horsepower:
153 hp @ 5600 rpm (approximate, depending on market)
Engine Option 1 Torque:
177 lb-ft @ 1700-4000 rpm (approximate, depending on market)
Engine Option 1 Fuel System:
Direct Injection (DI), Turbocharged
Engine Option 2 Name:
1.6L Turbocharged Ecotec (Diesel - not in all markets, check manual for specifics)
Engine Option 2 Codes:
LDA (Diesel)
Engine Option 2 Displacement:
1598 cc (1.6 L)
Engine Option 2 Horsepower:
137 hp @ 3500 rpm (Diesel, approximate)
Engine Option 2 Torque:
236 lb-ft @ 2000 rpm (Diesel, approximate)
Engine Option 2 Fuel System:
Turbocharged Direct Injection Diesel
Fuel Type:
Unleaded gasoline (1.4L Turbo); Diesel (1.6L Turbo Diesel)
Transmission Option 1 Type:
6-speed Manual Transmission
Transmission Option 2 Type:
6-speed Automatic Transmission (GF6-2, Hydra-Matic)
Automatic Transmission Features:
Available with manual mode (Driver Shift Control).
NHTSA Overall Rating:
5-Star (for models equipped with optional safety features)
IIHS Top Safety Pick:
Good (for models with specific equipment)
Available Driver Assistance:
Forward Collision Alert, Lane Departure Warning, Lane Keep Assist, Rear Cross-Traffic Alert, Side Blind Zone Alert.
Airbag System:
Ten standard airbags: front airbags, knee airbags, side-impact airbags, curtain airbags.
Braking System:
Four-wheel disc brakes with ABS, Electronic Brakeforce Distribution (EBD), Brake Assist (BA), Hill Start Assist (HSA).
Infotainment System:
Chevrolet MyLink infotainment system with 7-inch or 8-inch color touchscreen.
Smartphone Integration:
Apple CarPlay and Android Auto compatibility.
Adaptive Cruise Control:
Not typically available on this model year.
Parking Assistance:
Rear vision camera standard, optional rear park assist.
Wi Fi Hotspot:
Optional available 4G LTE Wi-Fi hotspot.
Keyless Entry Start:
Available keyless entry and push-button start.
Oil Change Interval:
Every 7,500 miles (12,000 km) or 12 months, whichever comes first, with synthetic oil. Refer to manual for specific conditions.
Tire Rotation Interval:
Every 7,500 miles (12,000 km).
Cabin Air Filter Replacement:
Every 15,000 - 20,000 miles (24,000 - 32,000 km) or annually.
Engine Oil Spec:
SAE 0W-20 Full Synthetic (API SN or higher).
Engine Oil Capacity:
4.2 quarts (4.0 L) for 1.4L Turbo. Refer to manual for exact capacity.
Coolant Spec:
Dex-Cool (GM 6247M), Orange colored, silicate and borate free, extended life antifreeze/coolant.
Transmission Fluid Spec Auto:
Dexron VI (GM P/N 88861134 or equivalent).
Brake Fluid Spec:
DOT 3 or DOT 4.
Common Problems:
Potential for oil leaks from valve cover or oil pan, turbocharger issues (less common), AC system problems, occasional electrical glitches.
Technical Service Bulletins:
Manual will likely contain references or diagnostic procedures for common TSBs affecting this model year.
Manufacturer:
Chevrolet, a division of General Motors (GM), with a long history of producing reliable and popular vehicles.
Generation Introduction:
The second generation Cruze (J400) was unveiled in 2015 for the 2016 model year, featuring a redesigned platform, more efficient engines, and updated technology.
Manufacturing Locations:
Primarily produced in Lordstown, Ohio, USA, and also at various GM plants globally.
