Positioning:
Targeted at owners and independent repair shops seeking dealership-level repair information for the 2016 Ford Fusion Energi. Positions itself as the definitive resource for this specific model.
Competitor Manuals:
Directly competes with other factory service manuals and advanced aftermarket repair guides. Differentiates by emphasizing its specificity to the Fusion Energi model and dealership technician origins.
Advantages:
Specific to model, comprehensive A-Z coverage, step-by-step instructions, diagrams, illustrations, wiring schematics, printable, digital format for ease of use and preservation.
Powertrain:
Engine (Internal Combustion & Electric), Hybrid System, High Voltage Battery, Transmission (eCVT), Fuel System, Emission Control System, Cooling System, Lubrication System, Intake/Exhaust Systems.
Chassis:
Suspension (Front & Rear), Steering System (Power Steering), Brake System (Hydraulic, ABS, Electronic Parking Brake), Wheel & Tire Assembly, Drive Axles.
Electrical:
Ignition System, Starting & Charging System, Lighting (Exterior/Interior), Instrument Panel & Gauges, Wiper & Washer System, Horn, Audio/Visual Systems, Meter/Information Displays, Cruise Control System, Engine Immobilizer System.
Body And Interior:
Body Panels (Hood, Doors), Exterior Trim, Interior Trim, Seats, Seat Belts, Supplemental Restraint System (Airbags), Door Locks, Windows, Mirrors, Glass.
HVAC:
Air Conditioning System, Heating System, Climate Control.
Electronics And Communication:
Multiplex/CAN Communication Systems, Body Control Modules (BCM), Powertrain Control Modules (PCM), Infotainment Systems.
Maintenance:
Scheduled Maintenance Procedures, Fluid Checks and Replacements, Filter Replacements, Belt Inspections.
Diagnostics:
Troubleshooting Flowcharts, Diagnostic Trouble Codes (DTCs), Symptom-based Diagnostics, Component Testing.
Repair:
Step-by-step repair procedures for all major and minor components, including disassembly, assembly, and adjustment.
Specifications:
Torque specifications, clearances, alignment data, fluid capacities, and other critical technical data.
Wiring:
Complete Wiring Schematics and Diagrams for all vehicle systems.
Depth:
Factory-level detail, suitable for professional technicians and advanced DIYers. Covers everything from basic maintenance to complex diagnostic and repair procedures.
Compatibility:
All Versions of Windows and macOS
Printability:
Yes, all pages are printable.
Binding:
Digital (PDF format, printable)
Paper Type For Printing:
Standard printer paper
Searchability:
Likely searchable due to PDF format, allowing for quick information retrieval.
Internal Combustion Engine:
2.5L Duratec I-4 (Atkinson Cycle for Hybrid operation)
Hybrid System Component:
High-Voltage Lithium-Ion Battery Pack, Electric Motor/Generator
Combined Horsepower:
Approximately 188 hp (Combined system output)
Engine Torque Approximate:
129 lb-ft @ 4000 RPM (2.5L I-4)
Electric Motor Torque Approximate:
150-200 lb-ft (Motor dependent)
Fuel Type:
Unleaded Gasoline
Injection Type:
Electronic Port Fuel Injection (PFI)
Coolant Type:
Ford Super Premium Engine Coolant (Green) or equivalent meeting specification WSS-M97B57-A1/A2/A3.
Engine Oil Type:
SAE 0W-20, API SN/SP Resource Conserving or ILSAC GF-5/GF-6A. Meeting Ford specification WSS-M2C945-B1/B2.
Engine Oil Capacity:
Approximately 4.7 US quarts (4.4 liters) with filter change for 2.5L Duratec.
NHTSA Overall Rating:
5-Star (for comparable Fusion models, Energi specific may vary slightly, consult NHTSA for exact 2016 Fusion Energi)
IIHS Top Safety Pick:
Yes (for comparable Fusion models, check IIHS for specific Energi ratings)
ABS:
Standard Anti-lock Braking System
Traction Control:
Standard Traction Control System (TCS)
Electronic Stability Control:
Standard Electronic Stability Control (ESC), Ford's AdvanceTrac
Airbags:
Frontal airbags, front side-impact airbags, curtain side-impact airbags, driver knee airbag.
Seat Belts:
3-point height adjustable front seat belts with pretensioners and load-limiting retractors, 3-point rear seat belts.
Child Seat Anchors:
LATCH (Lower Anchors and Tethers for CHildren) system.
System:
SYNC with MyFord Touch (or subsequent SYNC 3 depending on trim/options for 2016), featuring touchscreen interface, voice commands, Bluetooth connectivity, and navigation (optional).
Adaptive Cruise Control:
Optional, allows the vehicle to maintain a set speed and distance from the vehicle ahead.
Lane Keeping System:
Optional, provides alerts and steering assistance to keep the vehicle within its lane.
Parking Assist:
Optional, features like rearview camera and parking sensors.
Usb Ports:
Standard or optional, for charging devices and connecting media players.
Ford Applink:
Allows integration with smartphone apps for enhanced functionality.
Oil Change Interval:
Every 10,000 miles (16,000 km) or 12 months, whichever comes first, under normal driving conditions (refer to manual for severe conditions).
Tire Rotation:
Every 5,000-7,500 miles (8,000-12,000 km) or as needed based on wear.
Cabin Air Filter:
Every 15,000-20,000 miles (24,000-32,000 km) or annually.
Engine Coolant Flush:
Initial flush at 100,000 miles (160,000 km), then every 50,000 miles (80,000 km) thereafter.
Brake Fluid:
DOT 4 LV (Low Viscosity) Motorcraft Ultra DOT 4 or equivalent meeting Ford specification WSS-M6C65-A1.
Common Complaints:
Potential for issues with the Power Inverter Module (PIM), charging system faults, battery cooling system leaks, and occasional infotainment system glitches. Refer to manual for detailed troubleshooting of these and other potential issues.
Ford Heritage:
Ford Motor Company, a global automotive manufacturer with a history of innovation and mass production dating back to 1903.
Fusion Lineage:
The Ford Fusion is a mid-size sedan that debuted for the 2006 model year. The Fusion Energi is a plug-in hybrid (PHEV) variant introduced in 2013, building on the second generation Fusion platform (CD391).
Manufacturing Location:
Hermosillo Stamping and Assembly, Hermosillo, Sonora, Mexico
Green Car Of The Year:
The Ford Fusion (including hybrid variants) has received accolades for its fuel efficiency and environmental performance, though specific 'Green Car of the Year' awards for the 2016 Energi model would need verification.
Fuel Economy Estimations:
EPA estimated MPGe for electric-only operation, and MPG for combined hybrid operation (e.g., 101 MPGe combined electric/gas, 36 MPG combined gas/electric for 2016 Fusion Energi - consult EPA for official ratings).
