🏷️ Basic Information

Make:

Holden

Model:

Commodore

Generation:

VF

Model Year:

2016

Platform Code:

GM Epsilon II (Global)

👋 Introduction

Positioning:

The Holden Commodore VF represented the pinnacle of Australian-designed and manufactured large sedans, known for its blend of performance, comfort, and practicality.

Competitors:

Competed with other large sedans like the Ford Falcon, and offered a premium alternative to mid-size sedans. In export markets (e.g., Chevrolet SS, Vauxhall VXR8), it competed in the performance sedan segment.

Chassis Design:

Utilized the global GM Epsilon II platform, providing a rigid and refined chassis with excellent handling characteristics.

Powertrain Options:

Offered a range of potent V6 and V8 engines, including the naturally aspirated 3.6L V6 (LLT, LFX) and the iconic 6.2L V8 (LS3) in performance variants.

Technology Integration:

Featured Holden's MyLink infotainment system, advanced safety features, and improved aerodynamic design compared to previous generations.

📋 Manual Details

Engine Variants Covered:

All (V6, V8, naturally aspirated, supercharged)

Transmission Variants Covered:

All (Automatic, Manual)

Trim Levels Covered:

All (e.g., Evoke, SV6, SS, SS-V, Calais, Caprice-based variants)

Chassis Types Covered:

Sedan, Sportwagon, Ute

Estimated Page Count:

Extensive (likely exceeding 2000 pages for a complete workshop manual)

Type:

Complete Workshop Service and Repair Manual

Language:

English

Format:

Downloadable Digital Format (PDF)

📖 Manual Coverage

Powertrain:

Engine mechanicals (including V6 and V8 variants, disassembly/assembly, timing, cooling), fuel system (injection, pumps, lines), exhaust system, emissions control.

Transmission:

Automatic transmissions (e.g., 6L80, 6L90) and Manual transmissions (e.g., MGH-6, MYD-6) component removal, overhaul, installation, and diagnostics.

Drivetrain:

Front-wheel drive (FWD) and Rear-wheel drive (RWD) components, driveshafts, CV joints, differentials, propshafts (RWD).

Braking System:

Hydraulic systems, ABS, EBD, traction control, brake pad/rotor replacement, caliper service, parking brake.

Steering And Suspension:

Power steering systems (hydraulic/electric), steering rack, suspension components (struts, shocks, control arms, bushings), alignment procedures.

Electrical System:

Battery, charging system (alternator), starting system (starter motor), lighting (headlights, taillights, interior), fuses, relays, wiring diagrams, body control modules (BCM).

HVAC:

Air conditioning system, heater core, climate control modules, refrigerant handling, component replacement.

Body And Chassis:

Body panels, doors, hood, trunk, interior trim, glass, structural components, rust repair, corrosion protection.

Safety Systems:

Airbag system (SRS), seatbelt pre-tensioners, electronic stability control (ESC) diagnostics.

Routine Maintenance:

Oil changes, filter replacements, fluid checks and top-offs, tire rotation, spark plug replacement, air filter replacement.

Component Overhaul:

Engine rebuilds, transmission overhauls, differential rebuilds, brake caliper rebuilds.

Diagnostics:

Troubleshooting guides, diagnostic trouble codes (DTCs) interpretation and clearing, wiring diagram analysis.

Repair And Replacement:

Detailed steps for replacing components such as radiators, water pumps, alternators, starter motors, fuel injectors, suspension arms, steering racks, body panels.

Electrical Troubleshooting:

Fault finding for circuits, sensor testing, module diagnosis, wiring harness repair.

Special Tools:

Identification and usage of specific tools required for various repair procedures.

Depth:

Comprehensive, from basic maintenance to advanced diagnostics and complete mechanical overhauls, suitable for professional technicians and experienced DIYers.

📊 Manual Specifications

File Format:

PDF (Portable Document Format)

Print Quality:

High-resolution, suitable for printing with clear diagrams and text.

Binding Type:

N/A (Digital download, printable)

Paper Type:

N/A (Digital download, printable on standard paper)

Searchability:

Searchable text within the PDF document.

Device Compatibility:

Compatible with PC, Mac, tablets, smartphones with Adobe Reader or compatible PDF viewer.

⚙️ Engine Specifications

V6 Engine Code:

LFX (3.6L SIDI V6)

V6 Displacement:

3642 cc

V6 Horsepower:

210 kW (approx. 281 hp) at 6000 rpm

V6 Torque:

370 Nm (approx. 273 lb-ft) at 3000 rpm

V8 Engine Code:

LS3 (6.2L V8)

V8 Displacement:

6162 cc

V8 Horsepower:

304 kW (approx. 407 hp) at 6000 rpm (SS-V Redline)

V8 Torque:

570 Nm (approx. 420 lb-ft) at 4400 rpm (SS-V Redline)

Fuel Induction:

Sequential Multi-Port Fuel Injection (SIDI) for V6, Port Fuel Injection for V8

Ignition System:

Coil-on-plug electronic ignition

Fuel Type:

Unleaded Petrol (RON 91 minimum recommended, higher octane for performance models)

Fuel Tank Capacity:

70 Litres (approx.)

🔧 Transmission

V6 Transmission:

6-speed Automatic (e.g., 6L80) standard on some V6 trims, manual available

V8 Transmission:

6-speed Manual (e.g., Tremec TR-6060) and 6-speed Automatic (e.g., 6L80/6L90) available for V8 models

Automatic Features:

Paddle shifters, Driver Shift Control (DSC) for manual gear selection

Manual Features:

Short-throw gear selection for sporty feel

Automatic Transmission Fluid:

Dexron VI (or equivalent)

📐 Dimensions

Wheelbase:

2997 mm (approx.)

Length:

4950 mm (Sedan, approx.)

Width:

1898 mm (approx.)

Height:

1465 mm (Sedan, approx.)

Kerb Weight:

Varies by model, e.g., 1730 kg (Evoke) to 1877 kg (SS-V Redline Sedan)

🛡️ Safety Features

Ancap Rating:

5-star ANCAP Safety Rating (for most VF models)

Driver Assistance Systems:

Electronic Stability Control (ESC), Traction Control System (TCS), Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Hill Start Assist (HSA).

Advanced Safety Options:

Forward Collision Alert, Lane Departure Warning, Blind Spot Alert, Reverse Traffic Alert (availability dependent on trim level).

Airbag System:

Driver and front passenger airbags, side curtain airbags, front side airbags, driver knee airbag (depending on model).

Seatbelts:

Pre-tensioned front seatbelts, three-point seatbelts for all seating positions.

💡 Technology Features

Infotainment System:

Holden MyLink infotainment system with touch screen interface.

Connectivity Options:

Bluetooth audio streaming and phone connectivity, USB and AUX inputs, optional satellite navigation.

Parking Assistance:

Reverse parking sensors, optional reverse camera and front parking sensors.

Lighting Technology:

Halogen headlights standard, optional Bi-Xenon HID headlights with LED daytime running lights (DRLs) on higher trims.

Telematics:

OnStar (in some export markets), basic trip computer functions.

🔧 Maintenance

Oil Change Interval:

Typically every 15,000 km or 12 months, whichever comes first (refer to specific model for exact recommendation).

Air Filter Replacement:

Recommended every 45,000 km or as needed based on driving conditions.

Spark Plug Replacement:

V6: 160,000 km (NGK Iridium). V8: 160,000 km (NGK Iridium).

Engine Oil Specification:

GM-LL-A-025 or Dexos 2 (e.g., SAE 5W-30 or 0W-40 depending on climate and model).

Coolant Specification:

GM-specific orange coolant (long-life)

Brake Fluid Specification:

DOT 4

Common Wear Items:

Front control arm bushings, strut mounts, power steering pump (for hydraulic systems), water pump seals.

Infotainment Glitches:

Occasional touchscreen responsiveness issues or Bluetooth connectivity problems, often resolvable with software updates.

V6 Timing Chain:

While generally robust, the timing chains on some V6 engines (particularly earlier LLT) have been noted for potential wear over high mileage, leading to noise. The manual would detail inspection procedures.

📚 Vehicle History

Holden Legacy:

Holden has a long and storied history in Australian automotive manufacturing, with the Commodore being its flagship model for decades.

Vf Generation Significance:

The VF Commodore represented a significant evolution, incorporating the global Epsilon II platform and a substantial redesign, marking a shift towards more advanced technology and refined driving dynamics.

Manufacturing Location:

Elizabeth, South Australia, Australia

Production Period:

2013-2017 (VF series)

🏆 Awards & Recognition

Australian Car Of The Year:

While not specifically the 2016 model, the Commodore platform has historically won numerous 'Car of the Year' awards from Australian motoring publications.

Safety Ratings:

Consistent high safety ratings from ANCAP, reflecting the robust chassis and comprehensive safety features.
