Target Audience:
DIY Enthusiasts, Independent Repair Shops, Land Rover Owners
Uniqueness:
Factory-specific information, not generic; exact same manual used by dealership technicians
Information Source:
Official Land Rover Factory Data
Ease Of Use:
Easy-to-use PDF, no flipping through multiple books
Learning Resource:
Enables owners to perform repairs and gain knowledge
Primary Coverage:
Full Service and Repair
Diagnostic Coverage:
Advanced Diagnostics and Troubleshooting
Maintenance Coverage:
Scheduled Maintenance, Preventative Maintenance
Repair Coverage:
All Mechanical, Electrical, and Body Repairs A-Z
Estimated Pages:
Detailed page count not specified, but described as comprehensive
Type:
Factory Service and Repair Manual
Source:
Dealership Technician Manual
Digital Delivery:
Speed Download
Compatibility:
Compatible with all versions of Windows and Mac operating systems.
Powertrain:
Engine, Control System, Fuel Service, Emission Control, Intake Exhaust Cooling, Lube, Ignition Starting Charging, Auto Transmission, Manual Transmission, Transfer Propeller Shaft, Differential, Axle
Chassis:
Suspension, Tire & Wheel, Brake Control, Brake, Parking Brake, Steering Column, Power Steering
Electrical And Body:
Air Condition, Suppl Restraint System, Seat Belt, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Lock, Meter Audio/Visual, Horn, Windshield/Glass Mirror, Instrument Panel, Seat, Engine Hood/ Door, Exterior & Interior, Electrical, Multiplex/ Can Communication
General Repair:
Complete Step-by-Step Instructions for all repairs
Diagnostics:
Diagnosis of common and complex issues
Maintenance:
Routine maintenance procedures and schedules
Electrical Diagrams:
Detailed Wiring Schematics
Depth:
Factory High Level Detail, Specific to Model
Visual Aids:
Diagrams and Illustrations for clarity
Component Level:
Covers all components from major systems to minor details
Quality:
High Resolution, Zoomable Images
Printability:
All Pages Printable
Customization:
Print only required pages and diagrams
Digital Binding:
Single PDF File for Easy Navigation
Digital Representation:
No greasy or torn paper manuals
Software Requirements:
Adobe PDF Reader and Winzip (or equivalent unzipping software) required.
Engine Options 2016:
Primarily 2.0L Ingenium Diesel (Td4) and 2.0L Ingenium Petrol (Si4), depending on market. Specific engine codes (e.g., AJ200D, PT204) are detailed within the manual.
Horsepower Range:
Typically 150-180 hp for diesel variants and 240-290 hp for petrol variants (exact figures vary by engine and tuning).
Torque Range:
Torque figures vary significantly by engine, with diesel variants offering higher low-end torque for off-road capability.
Injection Type:
Common Rail Direct Injection (Diesel), Direct Injection (Petrol)
Emission Control:
Euro 6 compliant, includes Diesel Particulate Filter (DPF) for diesel engines, Selective Catalytic Reduction (SCR) may be present on some variants.
Transmission Type:
9-speed ZF 9HP45 Automatic Transmission (standard on most 2016 models).
Optional Transmission:
No manual transmission offered for the 2016 Discovery Sport L550.
Transmission Features:
Adaptive shift logic, sport mode, paddle shifters (on some trims), CommandShift function.
Atf Type:
Specific ZF Lifeguard fluid (e.g., Lifeguard 8) required. Manual will specify exact part numbers and change intervals.
Length:
Approx. 4,589 mm (180.7 in)
Width:
Approx. 1,894 mm (74.6 in) without mirrors
Height:
Approx. 1,695 mm (66.7 in)
Wheelbase:
Approx. 2,741 mm (107.9 in)
Curb Weight:
Varies by engine and configuration, typically starting around 1,700 kg (3,748 lbs).
Towing Capacity:
Up to 2,000 kg (4,409 lbs) for braked trailers (check specific market regulations and vehicle configuration).
Euro Ncap Rating:
5-star safety rating for the 2016 model year.
Active Safety Systems:
Electronic Stability Control (ESC), Traction Control System (TCS), Hill Start Assist, Roll Stability Control (RSC), Trailer Stability Assist (TSA), Autonomous Emergency Braking (AEB) on some trims/packages.
Passive Safety Features:
Multiple airbags (front, side, curtain), anti-whiplash head restraints, seat belt pretensioners.
Infotainment System:
InControl Touch infotainment system with 8-inch touchscreen, Bluetooth connectivity, optional navigation, and Meridian audio systems.
Driver Assistance Features:
Lane Departure Warning, Parking Sensors (front/rear), Rear View Camera, optional Traffic Sign Recognition, Blind Spot Monitoring, Reverse Traffic Detection.
Connectivity Options:
USB, Aux-in, Bluetooth audio streaming, optional InControl Apps and Wi-Fi hotspot.
Oil Change Interval:
Typically 15,000 miles (24,000 km) or 12 months, whichever comes first. The manual will provide precise intervals based on driving conditions.
Major Service Interval:
Key services like spark plug replacement (petrol), fuel filter, and brake fluid flush will have specific mileages/timeframes outlined in the manual.
Engine Oil Specification:
Specific synthetic engine oil meeting Land Rover STJLR.03.5004 (e.g., 0W-20) is typically required. Manual will confirm exact spec and capacity.
Coolant Specification:
OAT (Organic Acid Technology) long-life coolant, often a pink or orange hue. Manual will specify type and mixture ratio.
Common Diesel Issues 2016:
DPF regeneration issues due to short trips, potential AdBlue (if fitted) system issues, EGR valve problems (typical of modern diesels).
Common Petrol Issues 2016:
Spark plug fouling, potential timing chain concerns (though less common in early Ingenium), occasional turbocharger issues.
General Issues:
Infotainment system glitches, battery drain issues, minor electrical gremlins, DPF related faults are frequently addressed.
Brand Legacy:
Land Rover is renowned for its off-road capability and luxury SUVs, dating back to 1948.
Discovery Lineage:
The Discovery Sport is positioned below the larger Discovery and Evoque, designed as a compact premium SUV with practical seating for up to seven occupants (optional third row).
Manufacturing Location:
Halewood, Liverpool, United Kingdom
Introduction Year:
The L550 generation was introduced in 2014 as a 2015 model year vehicle, making the 2016 model part of its initial production run.
