🏷️ Basic Information

Make:

Ford

Model:

Fusion Energy

Year:

2017

👋 Introduction

Market Position:

The 2017 Ford Fusion Energi occupies a niche in the mid-size sedan market as a plug-in hybrid (PHEV), offering a blend of electric-only driving range and gasoline-powered efficiency.

Competitors:

Key competitors for the 2017 Fusion Energi include the Chevrolet Volt, Toyota Prius Prime, and Honda Clarity Electric/Plug-In Hybrid. Its competitive advantage lies in its more conventional sedan styling and comfortable ride compared to some rivals.

Key Features:

The Fusion Energi's defining characteristic is its PHEV powertrain, allowing for electric-only propulsion for a certain range, followed by efficient hybrid operation. It also benefits from the Fusion platform's refined interior, comfortable ride, and available advanced technologies.

Manual Utility:

This manual is designed to empower owners and technicians to perform a wide range of service and repair tasks efficiently, saving time and money on vehicle maintenance and repair.

Diy Benefit:

Enables significant cost savings for owners by facilitating DIY repairs and maintenance, reducing reliance on dealership service centers.

📋 Manual Details

Product Name:

Ford Fusion Energy Complete Workshop Service Repair Manual 2017

Manual Type:

Complete Workshop Service Repair Manual

Format:

Downloadable (PDF)

Language:

English

Delivery Method:

Instant Email Delivery

Estimated Page Count:

Detailed comprehensive coverage suggests a substantial page count, likely exceeding 1500-2000 pages typical for a complete workshop manual. (Exact number not provided in product info, but implied by 'Complete Workshop Service Repair Manual').

Device Compatibility:

Compatible with all PC & MAC computers, tablets, and mobile phones.

📖 Manual Coverage

Systems Covered:

Engine (2.0L I4 Atkinson-cycle, Electric Motor), Powertrain Control Module (PCM), Hybrid System, Battery Management System (BMS), Charging System, Transmission (eCVT), Drivetrain, Suspension (Front & Rear), Steering, Brakes (ABS, EBD, Regenerative Braking), HVAC System, Fuel System, Cooling System, Exhaust System, Electrical System (12V and High Voltage), Lighting, Body Control Module (BCM), Body & Chassis, Interior Components, Exterior Components, Safety Systems (Airbags, Seatbelts), Diagnostic Trouble Codes (DTCs), Wiring Diagrams, Technical Specifications.

Powertrain Control Module PCM Diagnostics:

Detailed procedures for diagnosing and servicing the Powertrain Control Module (PCM) and related sensors.

Procedures Included:

Routine Maintenance, Scheduled Maintenance, Oil Changes, Filter Replacements, Spark Plug Replacement, Brake Service, Suspension Repairs, Steering Alignment, Electrical Diagnostics, Hybrid System Troubleshooting, Battery Pack Service, Electric Motor Service, Powertrain Component Removal/Installation, Body Panel Repair, Interior Trim Replacement, HVAC System Diagnosis and Repair, Cooling System Service, Fuel System Cleaning and Inspection, Exhaust System Repair, Diagnostic Trouble Code (DTC) Resolution, Wiring Harness Repair, Component Testing, Torque Specifications, Special Tool Requirements, Exploded Views, Step-by-Step Instructions with Illustrations.

Technical Depth:

Comprehensive A-Z coverage from basic maintenance to complex diagnostic and repair procedures, including detailed troubleshooting guides and electrical schematics.

Illustrations And Diagrams:

Includes step-by-step instructions with accompanying pictures and detailed diagrams for clarity.

Troubleshooting Guides:

Features dedicated troubleshooting sections and diagnostic procedures for identifying and resolving issues.

Torque Specifications Availability:

Includes detailed torque specifications for all critical fasteners and components.

Wiring Diagrams Completeness:

Comprehensive electrical wiring diagrams for all vehicle systems, essential for electrical diagnostics and repair.

📊 Manual Specifications

File Format:

PDF

Print Quality:

High-quality, printable pages with clear text and illustrations.

Searchability:

Searchable text for quick access to information.

Software Requirement:

Adobe Reader (or compatible PDF reader)

Printability:

User has the option to print specific pages, chapters, or the entire manual for hard copy reference.

⚙️ Engine Specifications

Primary Engine:

2.0L Atkinson-cycle I4 Hybrid Engine paired with an Electric Motor.

Combined Horsepower:

188 hp (combined system output)

Electric Only Range Est Miles:

Approximately 22 miles

Battery Type:

Lithium-ion

Fuel Type:

Unleaded Gasoline

Fuel Tank Capacity Gallons:

14.0

Hybrid System Description:

Combines a 2.0L Atkinson-cycle gasoline engine with a powerful electric motor and a high-voltage lithium-ion battery pack, managed by sophisticated software for optimal efficiency and performance.

Engine Type Hybrid:

2.0L Atkinson-cycle I4 gasoline engine.

Battery Capacity Kwh:

Approximately 7.6 kWh (subject to variation).

🔧 Transmission

Standard Transmission:

eCVT (Electronic Continuously Variable Transmission)

Transmission Features:

Integrated electric motor, seamless power delivery, regenerative braking capabilities.

Hybrid Transmission Features:

Electronically controlled continuously variable transmission (eCVT) integrates the electric motor, engine, and power split device for seamless transitions between electric, hybrid, and engine-only modes. Includes sophisticated regenerative braking.

📐 Dimensions

Overall Length Inches:

191.8

Overall Width Inches Without Mirrors:

72.9

Overall Height Inches:

58.3

Passenger Volume Cubic Feet:

102.0

Cargo Volume Cubic Feet Rear Seats Up:

11.1

Curb Weight Lbs:

3973

Gross Vehicle Weight Rating Gvwr Lbs:

4575 (approximate, refer to vehicle VIN plate)

Wheelbase Inches:

107.7

Standard Wheel Size:

17-inch alloy wheels (typical)

Standard Tire Size:

P215/55R17 (typical, consult Owner's Manual for exact fitment)

🛡️ Safety Features

NHTSA Overall Safety Rating:

5-Star (refer to specific NHTSA reports for detailed breakdown)

Active Safety Features:

Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Traction Control System (TCS), Electronic Stability Control (ESC), Tire Pressure Monitoring System (TPMS), Backup Camera.

Brake System Type:

Four-wheel disc brakes with ABS, Electronic Brake-force Distribution (EBD), and regenerative braking capability.

Passive Safety Features:

Dual front airbags, front side-impact airbags, front and rear side curtain airbags, driver knee airbag, front safety belts with pretensioners, LATCH child seat anchors.

💡 Technology Features

Infotainment System:

Ford SYNC 3 (standard on higher trims, optional on others), featuring an 8-inch touchscreen, voice recognition, Apple CarPlay, and Android Auto compatibility.

Navigation System Availability:

Available as an option or part of upgraded packages, often integrated with SYNC 3.

Driver Assistance Features Available:

Adaptive Cruise Control, Lane Keeping System, Blind Spot Information System (BLIS) with Cross-Traffic Alert, Forward Collision Warning, Rain-Sensing Wipers, Auto High Beams.

Parking Assistance:

Rear parking sensors standard; available front parking sensors and Active Park Assist.

Connectivity Features:

Bluetooth connectivity for phone and audio streaming, USB ports, available Wi-Fi hotspot, FordPass Connect (depending on trim and options).

Charging Options:

Supports Level 1 (120V) and Level 2 (240V) charging. Onboard charger facilitates efficient recharging of the high-voltage battery.

Onboard Charger Capacity:

Typically 3.3 kW (Level 2 charging takes approx. 7 hours from empty).

🔧 Maintenance

Oil Change Interval Miles Or Months:

Refer to Owner's Manual for specific intervals based on driving conditions (e.g., every 7,500-10,000 miles or 12 months, whichever comes first). Always check oil level regularly.

Tire Rotation Interval Miles:

Every 7,500 miles

Engine Air Filter Replacement Interval Miles:

Refer to Owner's Manual; typically every 30,000 miles or as needed based on driving environment.

Brake Pad Inspection Interval Miles:

Inspect at every oil change or as per manufacturer recommendations.

Engine Oil Specification:

SAE 0W-20 Synthetic Motor Oil (Refer to Owner's Manual for exact specification, e.g., WSS-M2C945-A).

Engine Oil Capacity Quarts:

4.4 (for 2.0L Atkinson-cycle engine)

Coolant Specification:

Ford Ultimate Engine Coolant (VC-11) or equivalent meeting WSS-M97B44-D.

Transmission Fluid Specification:

Mercon LV (for transmission, if applicable - consult manual for specific eCVT fluid type if user serviceable).

Brake Fluid Specification:

DOT 3 (Refer to Owner's Manual for specific Ford specification, e.g., WSS-M6C62-A).

Power Steering Fluid Specification:

Electric Power Steering (EPS) - No fluid service required for the steering rack itself.

Common Issues:

Potential issues may include early battery degradation in some cases, HVAC system performance variations, and occasional software glitches. Some owners have reported minor interior trim rattles.

Hybrid System Warnings:

Information on understanding and addressing specific hybrid system warning lights and fault indicators.

📚 Vehicle History

Brand Heritage:

Ford Motor Company, established in 1903, is one of the world's largest automotive manufacturers, known for innovation and a wide range of vehicles, including pioneering efforts in electrified powertrains.

Model Evolution:

The Ford Fusion was introduced for the 2006 model year. The 'Energy' variant, a plug-in hybrid version, debuted for the 2013 model year, coinciding with a major redesign of the Fusion platform. The 2017 model represents a mid-cycle refresh of this generation.

Production Location:

Flat Rock Assembly Plant, Michigan, USA.

Plug In Hybrid Development:

Ford's development of the Fusion Energi was part of its broader strategy to expand its portfolio of electrified vehicles, aiming to compete in the growing segment of environmentally conscious transportation.

🏆 Awards & Recognition

Awards And Recognitions:

The Ford Fusion lineup has received numerous awards over its lifespan, including being named one of Kelley Blue Book's 'Top 10 Most Fuel-Efficient Cars' in certain model years. The Energi variant specifically targets eco-conscious buyers.
