2020 Chrysler Pacifica Service and Repair Manual
- 常规价格
- $17.99
- 促销价
- $17.99
- 常规价格
-
- 单价
- / 单价
🏷️ Basic Information Identification Make: Chrysler Model: Pacifica Year: 2020 Generation Generation Name: Second Generation (2017-Present) Codes Platform: Chrysler RT (Minivan platform, updated for Pacifica) 👋 Introduction Market Position Market...
15 people are viewing this right now
类型: Car
厂商:
斯库: 525383
无法加载取货服务可用情况
共享
🏷️ Basic Information
Identification
Make:
Chrysler
Model:
Pacifica
Year:
2020
Generation
Generation Name:
Second Generation (2017-Present)
Codes
Platform:
Chrysler RT (Minivan platform, updated for Pacifica)
👋 Introduction
Market Position
Market Position:
The 2020 Chrysler Pacifica is a premium minivan segment offering, known for its family-friendly features, comfortable ride, and available hybrid powertrain. This service manual positions itself as the authoritative resource for maintaining and repairing this sophisticated vehicle.
Competitive Analysis
Competitive Analysis:
Competes in a segment with strong players like the Honda Odyssey, Toyota Sienna, and Kia Carnival. The Pacifica's strengths lie in its upscale interior, Stow 'n Go seating (on non-hybrid models), and the efficiency of its plug-in hybrid variant. This manual provides the necessary technical details to service these unique and advanced features.
Key Features
Key Features:
The manual is highlighted as being specific to the exact machine, not generic, and mirrors the documentation used by dealership technicians. Its digital format offers convenience with print-on-demand capabilities, zoomable images, and the elimination of physical wear and tear.
📋 Manual Details
Coverage Areas
Coverage Areas List:
• Maintenance
• Engine
• Control System
• Mechanical
• Fuel Service Specifications
• Emission Control
• Intake Exhaust Cooling
• Lube
• Ignition Starting Charging
• Automatic Transmission
• Manual Transmission (if applicable to specific models/trims, though Pacifica is primarily automatic)
• Transfer Propeller Shaft (if applicable)
• Drive Shaft
• Differential
• Axle Suspension
• Tire & Wheel
• Brake Control
• Brake Systems
• Parking Brake
• Steering Column
• Power Steering
• Air Conditioning
• Supplemental Restraint System (SRS)
• Seat Belt Systems
• Engine Immobilizer
• Cruise Control
• Wiper & Washer Systems
• Door Lock Systems
• Meter Audio/Visual Systems
• Horn
• Windshield/Glass/Mirror Systems
• Instrument Panel
• Seats
• Engine Hood/Doors
• Exterior & Interior Trim
• Electrical Systems
• Multiplex/CAN Communication Systems
• Diagnostics
• Troubleshooting
• Component Removal/Installation
• Torque Specifications
• Wiring Schematics
• Diagrams
• Illustrations
• Technical Specifications
Page Count
Page Count:
Extensive (specific number not provided, but implied to be comprehensive for A-Z repairs)
Manual Type
Manual Type:
Factory Service and Repair Manual
Additional Manual Types Covered By Content:
Includes elements of electrical diagnostics, troubleshooting, and component replacement guides that are often separate in other manufacturer offerings.
Language
Language:
English
Format
Format:
Digital (PDF)
📖 Manual Coverage
Systems Covered
Systems Covered List:
• Powertrain (Engine, Transmission, Drivetrain)
• Chassis (Suspension, Steering, Brakes)
• Electrical (Power distribution, Lighting, Control Modules, Audio/Visual)
• Body (Exterior, Interior, HVAC)
• Safety (SRS, Seatbelts, Immobilizer)
• Emissions Control Systems
• Diagnostics and Troubleshooting
Procedures Included
Procedures Included List:
• Scheduled Maintenance
• Component Diagnosis
• Disassembly and Reassembly
• Repair and Replacement Procedures
• Adjustment Procedures
• Troubleshooting Fault Codes
• Wiring Diagram Interpretation
• Fluid Level Checks and Changes
• Torque Wrench Application
• System Calibration
Technical Depth
Technical Depth:
Comprehensive: From basic maintenance tasks to advanced diagnostic and repair procedures, suitable for dealership technicians and experienced DIYers.
Wiring Schematics
Wiring Schematics Availability:
Yes, complete wiring schematics and diagrams are included for all major systems.
Diagnostics
Diagnostic Procedures:
Detailed diagnostic trees, troubleshooting guides for fault codes (DTCs), and component testing procedures.
📊 Manual Specifications
File Format
File Format:
PDF (Adobe Acrobat compatible)
Print Quality
Print Quality:
High Resolution, suitable for printing detailed diagrams and schematics.
Binding Type
Binding Type:
N/A (Digital format, user printable)
Paper Type
Paper Type:
N/A (Digital format, printable on user-specified paper)
File Compatibility
Operating Systems Compatibility:
Windows and Mac compatible.
Software Requirements
Required Software:
Adobe PDF Reader and Winzip (free downloads).
⚙️ Engine Specifications
Primary Engine
Primary Engine 2020 Petrol:
3.6L Pentastar V6
Performance
Horsepower 3.6L Pentastar:
287 hp @ 6400 rpm
Torque 3.6L Pentastar:
262 lb-ft @ 4000 rpm
Fuel System
Fuel System Type:
Multi-port Fuel Injection (MPI)
Engine Variants
Engine Variants Covered:
Includes 3.6L Pentastar V6 gasoline engine. (Manual also likely covers 3.6L Plug-in Hybrid powertrain components if applicable to the year/model covered).
Engine Codes
Engine Codes:
Refer to manual for specific engine codes (e.g., for Pentastar V6).
Engine Construction
Engine Block Material:
Aluminum Alloy
Cylinder Head Material:
Aluminum Alloy
Engine Features
Engine Features:
Dual overhead camshafts (DOHC), 24 valves, Variable Valve Timing (VVT).
🔧 Transmission
Standard
Standard Transmission Type:
8-speed automatic transmission (845RE or equivalent)
Optional
Optional Transmission Type:
eCVT (Electronic Continuously Variable Transmission) for Plug-in Hybrid models
Features
Transmission Features:
Includes electronic range select, driver-adaptive learning, and specific diagnostic procedures for both standard automatic and hybrid electric powertrains.
Fluid Specifications
Transmission Fluid Type:
Specific Mopar ATF+4 or equivalent (refer to manual for exact specification and part number for 2020 Pacifica models).
📐 Dimensions
Exterior
Length:
Approx. 201.2 inches
Width:
Approx. 78.4 inches (excluding mirrors)
Height:
Approx. 68.9 inches
Wheelbase:
Approx. 121.6 inches
Cargo
Cargo Volume Behind 3Rd Row:
Approx. 32.3 cu ft
Cargo Volume Behind 2Nd Row:
Approx. 87.5 cu ft
Cargo Volume All Seats Folded:
Approx. 140.5 cu ft
Weights
Curb Weight Gasoline:
Approx. 4,460 - 4,700 lbs (depending on trim/configuration)
Gross Vehicle Weight Rating:
Refer to manual for specific GVWR by model/trim
Towing Capacity:
Typically rated at 3,600 lbs with optional towing package.
🛡️ Safety Features
Ratings
NHTSA Overall Safety Rating:
Generally high, typically 5-star overall rating (refer to specific model year NHTSA report for definitive ratings).
Active Features
Active Safety Features:
Available: Forward Collision Warning with Active Braking, Adaptive Cruise Control, Lane Departure Warning with Lane Keep Assist, Blind Spot Monitoring, Rear Cross Path Detection, ParkSense® Parking Assist.
Passive Features
Passive Safety Features:
Multiple airbags (front, side curtain, front knee), Anti-lock Braking System (ABS), Electronic Stability Control (ESC), Traction Control System (TCS).
💡 Technology Features
Infotainment
Infotainment System:
Uconnect® system with touchscreen display (e.g., 7-inch or 8.4-inch options). Supports Apple CarPlay, Android Auto, Bluetooth connectivity.
Driver Assistance
Driver Assistance Features:
Available advanced driver-assistance systems (ADAS) as listed in safety features, managed by various sensors and control modules. Manual covers their operation, calibration, and diagnosis.
Connectivity
Connectivity Features:
SiriusXM® Satellite Radio, Wi-Fi Hotspot capability (subscription required), USB and auxiliary input ports.
Powertrain Technology
Hybrid Powertrain Technology:
Plug-in Hybrid variant features an electric motor, a generator, and a 16-kWh battery pack, providing electric-only driving range. The manual details the integration of these components.
🔧 Maintenance
Service Intervals
Oil Change Interval Gasoline:
Typically every 10,000 miles or 12 months, whichever comes first, with synthetic oil. Consult manual for exact mileage/time or Severe Duty schedule.
Tire Rotation Interval:
Every 6,000 - 8,000 miles
Cabin Air Filter Replacement Interval:
Typically every 15,000 - 20,000 miles or annually.
Engine Air Filter Replacement Interval:
Typically every 30,000 miles or as needed based on driving conditions.
Coolant Flush Interval:
Refer to manual for specific interval, often around 5 years or 100,000 miles for long-life coolant.
Fluid Specifications
Engine Oil Type Gasoline:
SAE 0W-20 Synthetic (refer to manual for specific Mopar specification, e.g., MS-6395).
Engine Oil Capacity Gasoline:
Approx. 6.0 quarts (with filter) for 3.6L Pentastar V6.
Coolant Type:
Mopar OAT (Organic Additive Technology) Antifreeze/Coolant, HOAT, or equivalent meeting Chrysler MS-9769 or MS-12106.
Brake Fluid Type:
DOT 3 or DOT 4 (refer to manual for specific recommendation).
Power Steering Fluid Type:
Refer to manual; typically uses ATF+4 or specific Mopar power steering fluid.
Known Issues
Common Issues Potential:
Early models in this generation experienced some reports of transmission issues, minor electrical glitches, and potential water pump leaks. The manual would detail specific troubleshooting and repair procedures for these.
Specifications
Spark Plug Gap:
Refer to manual for exact specification (typically around 0.040-0.045 inches for 3.6L Pentastar, but manual is the definitive source).
📚 Vehicle History
Brand Heritage
Brand Heritage:
Chrysler has a long history in the minivan segment, dating back to the original Dodge Caravan and Plymouth Voyager, pioneering the segment's popularity.
Model Evolution
Model Evolution:
The Pacifica replaced the Chrysler Town & Country and Dodge Grand Caravan. The second generation (introduced for 2017) brought a significant redesign, offering a more car-like driving experience and the introduction of a Plug-in Hybrid variant, a segment first.
Production
Production Location:
Windsor Assembly Plant, Windsor, Ontario, Canada
🏆 Awards & Recognition
Recognitions
Car And Driver Best Family Car:
The Pacifica has frequently been named to Car and Driver's '10Best' list for SUVs and minivans.
Motor Trend SUV Of The Year:
The Pacifica was a contender for MotorTrend's SUV of the Year awards in its segment.
