Vehicle Segment:
Compact Hatchback (C-segment)
Brand Philosophy:
Alfa Romeo is known for its blend of sporty performance, distinctive Italian styling, and driver-focused dynamics.
Competitors:
Volkswagen Golf, Ford Focus, BMW 1 Series, Audi A3, Renault Mégane, Opel Astra.
Design:
Iconic Alfa Romeo 'Scudetto' grille, stylish Italian design, sporty and dynamic proportions.
Driving Dynamics:
Renowned for sharp handling and engaging driving experience, thanks to chassis tuning and suspension design.
Target Audience:
DIY enthusiasts, independent workshops, and professional mechanics working on the Alfa Romeo 147 2.0 TS.
Value Proposition:
Enables significant time and cost savings by providing accurate, step-by-step repair and maintenance information, mirroring workshop procedures.
General Coverage:
Comprehensive service, maintenance, and repair for Alfa Romeo 147 2.0 TS (2000-2010)
Specific Systems:
Engine mechanical, engine management, fuel system, exhaust system, cooling system, lubrication system, transmission (manual and automatic options), clutch, driveline, suspension, steering, brakes, ABS, airbags, electrical systems (lighting, ignition, starting, charging, body electronics), climate control, interior, exterior bodywork.
Estimated Page Count:
Likely over 2000 pages (typical for comprehensive factory-level manuals covering a decade)
Type:
Full Service Repair Manual
Primary Format:
Disc Image File (.ISO) / Application (.exe)
Delivery Method:
Instant Download
Engine Mechanical:
Detailed disassembly, inspection, repair, and reassembly of the Twin Spark engine, including cylinder head, block, crankshaft, connecting rods, pistons, camshafts, timing system (belt and chain components).
Engine Management:
ECU diagnostics, sensor testing (MAP, TPS, Lambda, Knock, Crankshaft Position, Camshaft Position), actuator control, fuel injection system operation, ignition system.
Transmission Manual:
Overhaul, clutch replacement, gearbox internal components, shift mechanism.
Transmission Automatic:
Operation, fluid changes, basic troubleshooting (if applicable to specific models within the range covered by the '2.0 TS' designation).
Brakes:
Brake fluid replacement, caliper service, rotor replacement, brake pad replacement, ABS system diagnosis and repair, parking brake.
Suspension Steering:
Front and rear suspension component replacement (struts, shocks, control arms, bushings, ball joints), power steering system, wheel alignment procedures.
Electrical:
Wiring diagrams for all circuits, component testing, troubleshooting of lighting, power windows, central locking, instrument cluster, audio systems, and body control modules.
Maintenance:
Scheduled maintenance items: oil changes, filter replacements (oil, air, fuel, cabin), spark plug replacement, coolant flushes, brake fluid changes, timing belt replacement (critical for Twin Spark), accessory belt replacement.
Troubleshooting:
Step-by-step diagnostic procedures for common and uncommon issues, fault code interpretation, symptom-based troubleshooting guides.
Repair:
Detailed instructions for component repair and replacement, from minor adjustments to major overhauls, including engine, transmission, suspension, brakes, and electrical systems.
Diagnostic Tools:
Information on using OBD-II scanners, multimeters, and specialized Alfa Romeo diagnostic equipment.
Depth:
Full factory-level technical information, suitable for professional mechanics and advanced DIY enthusiasts. Includes detailed specifications, torque values, diagnostic procedures, and component diagrams.
Engine Type:
Inline 4-cylinder, DOHC, 16-valve Twin Spark
Displacement:
1970 cc (2.0 Liters)
Bore X Stroke:
83.0 mm x 91.0 mm
Compression Ratio:
10.3:1
Power Output:
150 PS (110 kW; 148 hp) at 6300 rpm (for early models, minor variations may exist)
Torque Output:
187 Nm (138 lb-ft) at 3800 rpm (for early models)
0 To 100 Km H:
9.3 seconds (for manual transmission models)
Top Speed:
208 km/h (130 mph)
Fuel Delivery:
Multi-point Fuel Injection (MPI), Bosch Motronic management system
Fuel Type:
Unleaded Petrol (95 RON recommended, 98 RON for optimal performance)
Emission Control:
Catalytic Converter, Euro 3/4 compliant (depending on model year)
Valve Actuation:
Belt-driven camshafts with dual spark plugs per cylinder.
Type Standard:
5-speed Manual
Type Optional:
Q-System 4-speed Automatic (with manual override)
Manual Gear Ratios:
Specific ratios would be detailed in the manual for each gear.
Clutch Type:
Hydraulic, single dry plate
Automatic Transmission Mode:
Comfort, Sport, Winter, and Manual selection modes.
Length:
Approx. 4253 mm (167.4 in)
Width:
Approx. 1764 mm (69.4 in)
Height:
Approx. 1458 mm (57.4 in)
Wheelbase:
Approx. 2600 mm (102.4 in)
Curb Weight:
Approx. 1300-1400 kg (2866-3086 lbs), varies by trim and transmission
Gross Vehicle Weight:
Typically around 1800-1900 kg
Boot Capacity:
Approx. 300 liters (10.6 cu ft)
Euroncap Rating:
5 Stars (achieved for early models, subsequent tests might show slightly different results based on evolving standards)
ABS:
Standard Anti-lock Braking System
Esp:
Optional/Standard (depending on model year and market) Electronic Stability Program (VDC - Vehicle Dynamic Control)
Traction Control:
ASR (Anti-Slip Regulation) often integrated with VDC
Airbags:
Driver, front passenger, side airbags (standard on most models); curtain airbags optional.
Seatbelts:
Pretensioning seatbelts with load limiters.
Body Structure:
Reinforced safety cell with crumple zones.
Audio System:
Factory fitted CD player with radio, optional Bose sound system, steering wheel audio controls.
Navigation:
Optional integrated navigation system (often an early era system).
Cruise Control:
Available on higher trim levels or as an option.
Parking Sensors:
Optional rear parking sensors.
Bluetooth:
Optional hands-free Bluetooth system (Blue&Me) introduced in later models.
HVAC System:
Manual air conditioning, optional dual-zone automatic climate control.
Oil Change:
Every 15,000 km (9,300 miles) or 1 year, whichever comes first (check manual for exact specification).
Timing Belt Replacement:
Critical: Every 105,000 km (65,000 miles) or 5 years, whichever comes first. Failure to replace can cause catastrophic engine damage.
Spark Plug Replacement:
Every 30,000 km (18,600 miles) or 2 years due to the dual-plug design (specific plug types and gaps crucial).
Engine Oil:
API SN/SP, ACEA A3/B4, SAE 10W-40 or 5W-40 (e.g., Selenia Star PE 5W-40 or similar quality).
Coolant:
Paraflu UP (or equivalent Type 11 antifreeze/coolant, blue color), 50% mixture with distilled water.
Transmission Oil Manual:
API GL-4, SAE 75W-90 (e.g., Tutela Car Technyx 75W-90).
Power Steering Fluid:
ATF Dexron III or Tutela PSF.
Twin Spark Ignition:
Wear on the secondary spark plugs, potential coil pack issues, though the dual plug setup generally improves combustion and reduces misfires.
Suspension Bushings:
Wear of front and rear suspension bushings leading to knocking noises and poor handling.
Window Regulators:
Failure of electric window regulators is a common complaint.
Body Control Module:
Electrical gremlins can sometimes be traced back to the BCM, requiring diagnostic attention.
Exhaust Manifold:
Cracking of the exhaust manifold can occur, leading to exhaust leaks and ticking noises.
Alfa Romeo Legacy:
Founded in 1910, Alfa Romeo has a long and storied history in motorsport and producing sporting road cars with a focus on engineering and design.
147 Introduction:
Launched in 2000 as a replacement for the Alfa Romeo 145/146 models, based on the Fiat Group's Tipo 2 platform.
Facelifts:
Received a significant facelift in 2004 (Type 937B) featuring updated styling, interior refinements, and improved technology.
Production Years:
2000-2010
Manufacturing Location:
Pomigliano d'Arco, Italy
Total Production Units:
Over 600,000 units produced across all variants.
