Make:

Arctic Cat

Model:

1000 TRV

Year:

2010

Model Code:

A2010TBW4EOSO

Variant:

TRV (Touring/Reciprocal Vehicle)

Trim:

Metallic Black International

Product Name:

Arctic Cat 2010 ATV 1000 TRV METALLIC BLACK INTERNATIONAL A2010TBW4EOSO [Parts Manual] PDF Download

👋 Introduction

Category:

High-performance, two-up (TRV) All-Terrain Vehicle (ATV) for recreational and utility use.

Competitors:

Primarily competed with other 1000cc+ class ATVs from manufacturers like Polaris (e.g., Sportsman 850/1000 XP), Can-Am (e.g., Outlander 1000), and Kawasaki (e.g., Brute Force 750/1000). The TRV designation signifies its touring capability with a passenger seat.

Atv Features:

Powerful 1000cc V-twin engine, aggressive styling, independent suspension, 4x4 drivetrain, passenger-ready configuration (TRV), substantial towing and cargo capacity.

Value:

Essential resource for owners and technicians to accurately identify, order, and understand the assembly of all parts for the 2010 Arctic Cat 1000 TRV, ensuring proper maintenance and repair.

📋 Manual Details

Primary Coverage:

Comprehensive Parts Catalog and Assembly Information for the 2010 Arctic Cat 1000 TRV ATV

Estimated Pages:

Detailed page count not provided, but extensive coverage is indicated by the list of covered systems.

Type:

Factory Parts Manual

Language:

English

Format:

PDF Download

📖 Manual Coverage

Engine And Drivetrain:

Engine, Crankshaft, Piston, Cylinder, Cylinder Head, Camshaft, Valves, Cam Chain, Magneto, Oil Filter/Pump, Water Pump, Clutch (Primary and Secondary), V-Belt, Drive Train, Front Drive Gearcase, Transmission, Gear Shifting, Shifter, Starter Motor, Starter Clutch, Magneto Cover.

Chassis And Body:

Frame, Canopy, Taillight, Cargo Box, Tailgate, Dash, Console, Floor Panel, Hood, Headlight, Seat, Tilt Frame.

Suspension And Steering:

Front Suspension, Rear Suspension, Steering, Sway Bar.

Braking System:

Front Brake, Rear Brake, Parking Brake.

Fuel And Cooling:

Air Intake, Throttle Body, Gas Tank, Cooling System.

Electrical:

Battery, Wiring Harness.

Assembly And Disassembly:

Detailed overhaul, disassembly, and assembly procedures for all major vehicle components.

Parts Identification:

Exploded views and detailed parts lists for component identification and ordering.

Depth:

Comprehensive technical detail for parts identification, replacement, and assembly. Focuses on component-level understanding for service and repair.

📊 Manual Specifications

Format:

PDF

Searchable:

Yes (Searchable Text)

Printable:

Yes (Printable)

Zoomable:

Yes (Zoomable)

Binding:

N/A (Digital Download)

Paper Type:

N/A (Digital Download)

Reader Compatibility:

Adobe Reader, Foxit Reader, or any other PDF reader.

⚙️ Engine Specifications

Engine Type:

Liquid-cooled, SOHC, V-twin

Displacement:

951cc (approximate, exact may vary slightly by sub-model)

Bore X Stroke:

Not specified in product info, requires manual consultation.

Fuel Delivery:

Electronic Fuel Injection (EFI)

Ignition:

Electronic Ignition

Horsepower:

Estimated 70-80 HP (exact figures can vary and are often not officially published for ATVs).

Torque:

High torque output, suitable for towing and demanding terrain.

Fuel Type:

Unleaded gasoline

Fuel Capacity:

Approximately 5.0 gallons (19.0 L)

🔧 Transmission

Type:

CVT (Continuously Variable Transmission) with engine braking.

Gears:

High (H), Low (L), Neutral (N), Reverse (R), Park (P).

Optional Transmissions:

N/A (CVT is standard for this model)

Drive Modes:

2WD/4WD selectable, with possible differential lock feature (check specific model configuration).

📐 Dimensions

Length:

Approximately 96 inches (243.8 cm)

Width:

Approximately 48 inches (121.9 cm)

Height:

Approximately 48 inches (121.9 cm)

Front Rack Capacity:

Capacity not specified, typically around 100 lbs.

Rear Rack Capacity:

Capacity not specified, typically around 200 lbs.

Dry Weight:

Approximately 700 lbs (317.5 kg)

Towing Capacity:

Typically 1050 lbs (476 kg)

Front Tire Size:

25x8-12 (common for this model)

Rear Tire Size:

25x10-12 (common for this model)

Wheelbase:

Approximately 50 inches (127 cm)

🛡️ Safety Features

Atv Safety Considerations:

ATVs are inherently less stable than other vehicles. Always follow safety guidelines, wear appropriate gear (helmet, eye protection, gloves, boots, long sleeves/pants), and operate on suitable terrain.

Braking System:

Hydraulic disc brakes front and rear for reliable stopping power.

Passenger Comfort:

TRV designation indicates a standard passenger seat with backrest and handholds for comfortable two-up riding.

Lighting:

Halogen headlights for nighttime visibility.

💡 Technology Features

Infotainment Features:

Basic instrumentation with speedometer, odometer, trip meter, fuel gauge, and indicator lights. No advanced infotainment systems like touchscreens or integrated audio.

Driver Assistance Features:

No advanced driver assistance systems. Focus is on mechanical performance and rider control.

Connectivity Features:

N/A

🔧 Maintenance

Oil Change Interval:

Recommended every 100 hours or annually. Specifics vary based on operating conditions and should be confirmed in the owner's manual or service manual.

Spark Plug Replacement:

Typically recommended at intervals such as 1000-2000 miles or annually. Manual will specify exact type and interval.

Air Filter Cleaning Or Replacement:

Frequent checks recommended, especially in dusty conditions. Replacement interval typically around 600 miles or annually, depending on filter type and use.

Engine Oil Type:

API SG or higher, SAE 0W-40, 10W-40 or 20W-50. Consult manual for specific viscosity based on temperature range.

Engine Oil Capacity:

Approximately 2.5 quarts (2.4 liters) with filter. Manual will provide exact capacity.

Transmission Fluid Type:

Arctic Cat recommends specific ATV transmission fluid or equivalent. Consult manual for part numbers.

Coolant Type:

Ethylene glycol-based antifreeze (50/50 mix with distilled water). Consult manual for specific type and capacity.

Common Atv Wear Items:

As with most ATVs of this era, expect wear on drive belts (CVT), suspension components (bushings, ball joints), wheel bearings, and brake pads. Electrical connections in exposed areas can also be a point of failure.

Arctic Cat Specific Notes:

Some users have reported issues with charging systems or ECU failures on certain Arctic Cat models, though not specific to this 2010 model without further data. Regular maintenance as per the manual is crucial for longevity.

📚 Vehicle History

Manufacturer History:

Arctic Cat has a long history in powersports, particularly with snowmobiles and ATVs, known for performance-oriented and robust machines.

Arctic Cat Atv Lineup:

The 1000 TRV represented the top-tier in Arctic Cat's ATV lineup for 2010, offering significant power and comfort features for extended rides and hauling.

Manufacturing Location:

Typically manufactured in Thief River Falls, Minnesota, USA.

🏆 Awards & Recognition

Atv Awards:

Specific awards for the 2010 Arctic Cat 1000 TRV are not widely documented in general automotive press, but Arctic Cat ATVs are generally well-regarded for their power and capability in their class.

Consumer Ratings:

Positive user reviews typically highlight the engine's power, smooth ride from suspension, and comfortable passenger setup. Some minor complaints may relate to weight or specific component durability over time.
