Target Audience:
Enthusiasts, DIY mechanics, and professional service technicians working on 2007 Arctic Cat ATVs.
Cost Savings:
Provides dealership-level repair information at a fraction of the cost, enabling significant savings on maintenance and repairs.
Digital Format:
Instant download in PDF format, eliminating shipping delays and allowing immediate use.
Completeness:
Includes all relevant supplement manuals if applicable, ensuring comprehensive coverage.
Covered Models:
Arctic Cat 400 Automatic/Manual, 400 TRV 4x4, 500 Automatic/Manual, 650 H1 4x4, 700 EFI
Estimated Page Count:
Varies by model, typically 500-1000+ pages
Type:
Comprehensive Service and Repair Manual
Engine:
Detailed repair and overhaul procedures for engine components, including top-end, bottom-end, cooling system, lubrication, and fuel delivery.
Transmission:
Coverage for both automatic and manual transmission systems, including disassembly, assembly, and common repair procedures.
Drivetrain:
In-depth information on front and rear differentials, drive shafts, CV joints, and axle repair.
Chassis:
Procedures for suspension, steering, and frame maintenance and repair.
Brakes:
Complete coverage of hydraulic brake systems, including caliper, master cylinder, and brake line service.
Electrical System:
Detailed troubleshooting, component testing, and repair of the electrical system, including ignition, charging, lighting, and accessories.
Fuel System:
Service procedures for fuel tanks, fuel pumps, carburetors (on applicable models) and EFI systems.
Maintenance:
Routine maintenance tasks, fluid changes, filter replacements, and lubrication schedules.
Adjustments:
Step-by-step guidance for adjustments to carburetor, throttle, brakes, and clutch systems.
Repair:
Comprehensive repair instructions for all major mechanical and electrical components, from minor fixes to complete overhauls.
Troubleshooting:
Systematic diagnostic procedures and troubleshooting guides for common and complex issues.
Depth:
Full tear-down and rebuild procedures, suitable for both basic maintenance and advanced repairs.
Illustrations:
Extensive use of detailed illustrations, diagrams, and schematics to aid in understanding procedures.
Compatibility:
Compatible with Windows, macOS, Linux, and other PDF-readable devices.
Quality:
High-resolution, non-scanned PDF for clear text and images.
Searchability:
Fully keyword searchable for quick access to specific information.
Navigation:
Completely bookmarked for easy navigation and access to different sections and topics.
Viewing Options:
Enables easy viewing, navigation, printing, and zooming.
Type:
Four-stroke, liquid-cooled (specific configurations vary by model)
400 Series:
Approximately 375cc - 400cc
500 Series:
Approximately 471cc
650 H1:
Approximately 650cc
700 Efi:
Approximately 700cc
Carburetor:
Keihin (specific models, e.g., 400 Automatic/Manual, 500 Automatic/Manual)
Efi:
Electronic Fuel Injection (e.g., 700 EFI)
Horsepower:
Varies by model and engine size, generally in the range of 25-50+ HP
Torque:
Varies by model and engine size, detailed in manual
Length:
Varies by model, typically 75-85 inches
Width:
Varies by model, typically 45-50 inches
Height:
Varies by model, typically 45-50 inches
Dry Weight:
Varies by model, typically 550-700+ lbs
Towing Capacity:
Typically 1000-1500 lbs (check specific model specs)
Features:
Basic instrumentation cluster including speedometer, odometer, fuel gauge, and indicator lights.
Efi Technology:
Electronic Fuel Injection on 700 EFI model provides improved throttle response, fuel efficiency, and cold-weather starting.
Not Applicable:
This era of ATVs did not feature advanced digital connectivity or infotainment systems.
Oil Change:
Typically every 50-100 operating hours or annually, refer to manual for exact specifications.
Filter Replacement:
Air filter and oil filter replacement intervals as per manual recommendations.
Engine Oil Type:
SAE 5W-50 or 10W-40 synthetic oil, API SG or higher (verify exact specification in manual).
Transmission Fluid:
Arctic Cat XT Premium Synthetic Gearcase Lube (or equivalent high-quality gear oil).
Coolant:
50/50 mixture of antifreeze and distilled water.
Common Wear Items:
CV boots, brake pads, tires, and suspension components are common wear items requiring regular inspection and replacement.
Efi Systems:
EFI system sensors and injectors may require cleaning or replacement over time, detailed diagnosis in manual.
