Segment:
Utility/Recreational ATV, often referred to as a 'side-by-side' or UTV derivative in its TRV configuration
Competitors:
Polaris Sportsman, Can-Am Outlander, Yamaha Grizzly, Kawasaki Brute Force
Seating Configuration:
Tandem seating (2-up) configuration for passenger transport
Suspension Travel:
Designed for comfortable ride and off-road capability, typically with independent suspension on all wheels
Cargo Capacity:
Front and rear racks for hauling gear, suitable for hunting, farming, or recreational use
Engine Configuration:
V-twin or single-cylinder engine, known for robust power delivery
Engine:
Complete component breakdown, part identification, and assembly
Transmission:
Detailed parts listing for gearbox and drive components
Drivetrain:
Front and rear differential, drive shafts, and CV joints
Suspension:
Front and rear suspension components, shocks, and A-arms
Braking System:
Brake calipers, rotors, lines, and master cylinder parts
Fuel System:
Fuel tank, pump, filter, and carburetor/fuel injection components
Cooling System:
Radiator, hoses, fan, and thermostat parts
Electrical System:
Wiring harness, lights, ignition system, stator, and battery components
Exhaust System:
Exhaust pipes, muffler, and heat shields
Steering System:
Handlebars, steering column, tie rods, and steering rack parts
Bodywork:
Body panels, fenders, racks, seat, and storage compartments
Part Identification:
Comprehensive identification of every component with diagrams
Assembly Disassembly:
Exploded views illustrating component relationships for assembly and disassembly
Part Ordering:
Provides exact Arctic Cat part numbers for accurate ordering
Depth:
Detailed breakdown of all OEM (Original Equipment Manufacturer) parts
Scope:
Covers all parts specific to the 2012 TRV 550 Cruiser International model
Digital Features:
Searchable text for quick part number retrieval, zoomable high-resolution images
Printability:
Fully printable for offline use or binding
Binding Recommendation:
Professional binding recommended for workshop use
Recommended Paper:
Durable paper stock suitable for workshop environments
Engine Type:
Liquid-cooled, 4-stroke, SOHC, 4-valve
Displacement:
499cc (approximate, actual may vary based on specific configuration details)
Bore X Stroke:
Data not explicitly provided in product description, but typical for this class
Compression Ratio:
Data not explicitly provided in product description
Horsepower:
Estimated 30-35 HP (typical for 500cc class ATVs)
Torque:
Data not explicitly provided in product description
Fuel Delivery:
EFI (Electronic Fuel Injection) or Carbureted (model dependent, EFI common for later models)
Fuel Type:
Unleaded Gasoline
Engine Oil Type:
API SG, SH, SJ, SL, SM or higher. SAE 0W-40, 5W-30, 10W-40, 10W-50, 20W-40, 20W-50 or 20W-50 synthetic oil (refer to specific manual for exact OEM recommendation)
Engine Oil Capacity:
Approx. 2.3 L (2.4 US qt) (verify in manual)
Transmission Type:
Automatic CVT (Continuously Variable Transmission)
Drive Modes:
2WD/4WD with Front Differential Lock
Gear Selection:
H (High), L (Low), N (Neutral), R (Reverse), P (Park)
Cvtf Fluid Type:
Arctic Cat specific CVT fluid or equivalent (e.g., Amsoil CVT Fluid, Suzuki CVTF Green)
Length:
Approx. 2301 mm (90.6 in) (verify in manual)
Width:
Approx. 1143 mm (45 in) (verify in manual)
Height:
Approx. 1168 mm (46 in) (verify in manual)
Wheelbase:
Approx. 1435 mm (56.5 in) (verify in manual)
Dry Weight:
Approx. 295 kg (650 lbs) (verify in manual)
Ground Clearance:
Approx. 254 mm (10 in) (verify in manual)
Front Rack Capacity:
Approx. 45 kg (100 lbs) (verify in manual)
Rear Rack Capacity:
Approx. 90 kg (200 lbs) (verify in manual)
Towing Capacity:
Approx. 476 kg (1050 lbs) (verify in manual)
Front Tire Size:
AT 25x8-12 (verify in manual)
Rear Tire Size:
AT 25x10-12 (verify in manual)
Wheel Type:
Steel or Aluminum Alloy (depending on trim)
Bolt Pattern:
4x110mm (typical for Arctic Cat ATVs)
Crash Safety:
ATVs are not subject to traditional automotive crash safety ratings (e.g., NHTSA, IIHS). User caution and adherence to safety guidelines are paramount.
Braking System:
Hydraulic disc brakes front and rear, often with parking brake mechanism
Selectable 2Wd4Wd:
Allows rider to choose drive mode based on terrain
Front Differential Lock:
Provides maximum traction in challenging conditions
Lighting:
Dual headlights, taillight, brake light for visibility
Seat Belts:
Not applicable to this ATV model. Riders use helmets and protective gear.
Protective Gear:
Manual emphasizes the use of helmets, eye protection, gloves, long pants, and boots.
Display Features:
Digital LCD display showing speed, RPM, odometer, trip meter, fuel level, clock, gear indicator (may vary by trim)
Throttle Control:
Thumb throttle with adjustable tension or feedback mechanisms
Charging Port:
12V accessory outlet for charging devices (verify presence and type)
Oil Change Interval:
Every 100 hours or annually, whichever comes first (refer to manual for specifics)
Air Filter Cleaning:
Every 25 hours or as needed based on operating conditions (refer to manual)
Spark Plug Replacement:
Typically every 200-400 hours or annually (refer to manual)
Belt Inspection Replacement:
Inspect CVT belt every 100 hours for wear and damage; replace as needed. Recommend replacement at 2-year intervals or 200 hours.
Coolant Type:
Ethylene Glycol based antifreeze (e.g., Arctic Cat Coolant, or a 50/50 mix of universal coolant and distilled water)
Brake Fluid Type:
DOT 3 or DOT 4 hydraulic brake fluid
Final Drive Gear Oil Type:
Arctic Cat gear oil, or SAE 80W-90 API GL-5 gear lubricant for front and rear differentials.
Cvtvibrations:
Some Arctic Cat models can experience belt slippage or vibration if the CVT clutch sheave alignment is off or if the belt is worn.
Electricalconnectors:
Corrosion or loose connections in the electrical system can cause intermittent faults, particularly in wet environments.
Suspensionwear:
Ball joints and bushings can wear over time, especially with aggressive use, leading to steering play and uneven tire wear.
Grease Points:
Refer to manual for specified grease points on suspension, steering, and drive components.
Manufacturer:
Arctic Cat Inc. (now Textron Specialized Vehicles)
Origin:
Founded in 1960, initially known for snowmobiles, expanded into ATVs in the early 1990s.
Trv Lineage:
The TRV (Tandem Ride Vehicle) designation signifies Arctic Cat's 2-up ATV platform, designed for comfortable passenger riding.
550 Engine Platform:
The 500-550cc class engines were popular for balancing power, efficiency, and maneuverability.
Manufacturing Location:
Typically manufactured in the USA by Arctic Cat.
