🏷️ Basic Information

Make:

Aston Martin

Model:

Vanquish

Model Variant:

V12 Vanquish

Model Years Covered:

2001, 2002, 2003, 2004, 2005, 2006, 2007

Engine Variant Covered:

V12

👋 Introduction

Market Position:

High-performance luxury grand tourer, positioned as a flagship model for Aston Martin.

Competitive Analysis:

Competed against other ultra-luxury and high-performance GTs such as Ferrari 575M Maranello, Bentley Continental GT, and Mercedes-Benz SLR McLaren during its production run.

Key Features:

Naturally aspirated V12 engine, bespoke hand-built construction, luxurious interior appointments, advanced bonded aluminum structure, evocative styling.

Manual Purpose:

To provide comprehensive service, repair, and maintenance information for authorized technicians and knowledgeable owners of the Aston Martin V12 Vanquish, enabling accurate and efficient upkeep of the vehicle.

📋 Manual Details

Coverage Areas:

Comprehensive: Engine, Transmission, Fuel System, Ignition, Lubrication, Exhaust, Electrical System, Bodywork, Routine Maintenance, Troubleshooting, Diagnostics, Repair, Overhaul, Component-Specific Procedures (including proprietary components)

Page Count:

Not specified, but described as 'complete Service Manual' and containing 'all necessary instructions'.

Manual Type:

Workshop Service Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Systems Covered:

Engine (including disassembly and assembly), Transmission (including disassembly and assembly), Fuel System, Ignition System, Lubrication System, Exhaust System, Electrical System, Bodywork, Cooling System, Braking System, Steering System, Suspension System, HVAC System, Chassis Components, Drivetrain

Procedures Included:

Routine Maintenance, Scheduled Servicing, Tune-ups, Removal and Installation of components, Assemblies and Disassemblies, Diagnostic procedures, Troubleshooting, Repair procedures, Overhaul of major components, Adjustment procedures, Calibration, Electrical system diagnosis, Wiring diagrams, Torque specifications

Technical Depth:

Advanced. Designed for mechanical technicians familiar with general automobile practices and emphasizes special aspects of the product, including proprietary component instructions. Covers full engine and transmission disassembly.

📊 Manual Specifications

File Format:

PDF (Portable Document Format)

Print Quality:

Printable. Designed to be printed for workshop use. Assumes high-quality output suitable for technical diagrams and text.

Delivery Method:

Electronic Delivery via Email (Fast and Free)

Binding Type:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Type:

Naturally Aspirated V12

Engine Displacement:

5935 cc (5.9 Liters)

Horsepower:

460 bhp (343 kW; 466 PS) @ 6000 rpm

Torque:

540 Nm (398 lb-ft) @ 5000 rpm

Fuel System:

Multi-point fuel injection (MPI)

Bore X Stroke:

89.0 mm x 79.5 mm

Compression Ratio:

10.3:1

Valve Train:

Double Overhead Camshafts (DOHC), 4 valves per cylinder

🔧 Transmission

Transmission Type:

6-speed 'Race-Tune'` Manual (Touchtronic)

Optional Transmission:

N/A (Only Touchtronic offered)

Transmission Features:

Hydraulically actuated clutch, paddle shifters behind the steering wheel for manual gear selection.

📐 Dimensions

Length:

4752 mm (187.1 in)

Width:

1975 mm (77.8 in)

Height:

1287 mm (50.7 in)

Wheelbase:

2730 mm (107.5 in)

Curb Weight:

Approximately 1730 kg (3814 lbs)

Gross Vehicle Weight Rating:

Not readily available, but estimated.

🛡️ Safety Features

Crash Test Ratings:

No official NCAP or IIHS ratings available for this specific model, as it was a low-volume, hand-built exotic.

Active Safety Features:

Anti-lock Braking System (ABS), Electronic Brakeforce Distribution (EBD), Traction Control System (TCS), Electronic Stability Program (ESP)

Passive Safety Features:

Driver and passenger airbags, front side airbags, reinforced passenger cell, energy-absorbing crumple zones.

💡 Technology Features

Infotainment System:

Early 2000s Aston Martin infotainment system, typically featuring a premium audio system (e.g., Linn), CD player, and navigation system options. May include rudimentary climate control displays.

Driver Assistance Features:

Primary driver assistance is through advanced chassis electronics: ABS, EBD, TCS, and ESP. No modern ADAS features like adaptive cruise control or lane keeping assist.

Connectivity Options:

Limited by modern standards. Primarily focused on audio and navigation. May have provisions for older mobile phone integration.

🔧 Maintenance

Scheduled Maintenance:

Annual servicing recommended, with major services typically at 10,000 mile or 2-year intervals. Specific intervals for fluid changes (oil, coolant, brake fluid) and component checks are detailed in the manual.

Engine Oil Specification:

Typically a high-performance synthetic oil meeting specific Aston Martin approvals (e.g., API SN, ACEA A3/B3/B4). Specific viscosity grade (e.g., 10W-40 or 5W-30) will be detailed in the manual. Oil capacity: Approx. 11.5 liters.

Coolant Specification:

Ethylene glycol-based coolant with corrosion inhibitors. Specific mixture ratio and type (e.g., Aston Martin approved) would be specified. Coolant capacity: Approx. 13.5 liters.

Brake Fluid Specification:

DOT 4 or DOT 5.1 high-performance brake fluid. Regular flushing and replacement recommended.

Transmission Fluid Specification:

Specific automatic transmission fluid (ATF) for the Touchtronic gearbox, meeting Aston Martin specifications. Capacity for transmission: Approx. 10.0 liters.

Common Issues:

Potential issues include minor electrical gremlins common in complex high-end vehicles, wear on interior materials due to age, potential for exhaust system corrosion on older examples, and proper functioning of the active aerodynamic spoiler. The manual will provide detailed diagnostic procedures for these and other potential problems.

Special Tools Requirement:

The manual references specific Aston Martin special tool numbers for certain adjustments and repairs, essential for maintaining factory specifications.

📚 Vehicle History

Brand Heritage:

Aston Martin has a long and storied history in motorsport and luxury automotive manufacturing, known for its distinctive styling, performance, and association with cinema (James Bond).

Model Evolution:

The V12 Vanquish was introduced in 2001 as the successor to the Virage line, representing a significant leap in design and technology for Aston Martin. It featured an advanced bonded aluminum chassis and a potent V12 engine. A revised model, the Vanquish S, was released in 2004 with increased power and styling updates. The V12 Vanquish was replaced by the Aston Martin DBS V12 in 2007.

Production Years:

2001-2007

Manufacturing Location:

Newport Pagnell, Buckinghamshire, England

🏆 Awards & Recognition
