Segment:
Premium compact sports car / compact executive car.
Competitors 2007:
BMW Z4, Porsche Cayman, Mercedes-Benz SLK-Class, Nissan 350Z, Ford Mustang (depending on market and specific variant).
Design Philosophy:
Iconic Bauhaus-inspired design, blending sporty aesthetics with everyday usability and premium quality.
Manual Value Proposition:
Provides professional-level repair and maintenance information, enabling cost savings for owners and ensuring proper upkeep.
Coverage Summary:
Comprehensive service, maintenance, and troubleshooting for all aspects of the Audi TT Mk2 Typ 8J 2007.
Estimated Page Count:
Varies by specific edition, but typically extensive for a full service manual (often 1000+ pages).
Type:
Full Service Repair Manual
Engine Systems:
Engine mechanicals, lubrication, cooling, fuel delivery, ignition, exhaust, emissions control, turbocharging systems (if applicable).
Drivetrain Systems:
Manual transmission (6-speed), S tronic (DSG) transmission (if applicable), clutch, differential, axles, driveshafts, quattro all-wheel-drive system.
Chassis Systems:
Suspension (front and rear), steering, brakes (front and rear, ABS, ESP), wheel and tire specifications.
Electrical Systems:
Battery, charging system, starter, lighting (headlights, taillights, interior), power windows, mirrors, central locking, climate control, infotainment, instrument cluster, fuse and relay locations, wiring diagrams.
Body And Interior:
Body construction, exterior panels, doors, hood, trunk, convertible top mechanism (if applicable), interior trim, seats, airbags, safety restraint systems.
Maintenance Procedures:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, brake pad/rotor replacement, spark plug replacement, belt inspection/replacement, battery maintenance.
Repair Procedures:
Engine component replacement (e.g., water pump, alternator), transmission service/rebuild, brake system repair, suspension component replacement, electrical component diagnosis and repair, body panel repair.
Troubleshooting Diagnostics:
Step-by-step diagnostic procedures for common and complex issues, symptom-based troubleshooting charts, diagnostic trouble code (DTC) interpretation and resolution.
Depth:
Extensive, covering basic DIY maintenance to complex professional-level repairs and diagnostics. Includes exploded views, torque specifications, and detailed component removal/installation sequences.
Engine Code Examples:
BWA (2.0 TFSI), BPY (2.0 TFSI), CDLA (2.0 TFSI - S model).
2.0 Tfsi:
1984 cc (2.0 Liters)
Horsepower 2.0 Tfsi:
200 PS (147 kW; 197 hp) for standard models; 265 PS (195 kW; 261 hp) for TTS models.
Torque 2.0 Tfsi:
280 Nm (207 lb-ft) for standard models; 350 Nm (258 lb-ft) for TTS models.
Fuel Delivery:
Direct injection (FSI), turbocharged.
Layout:
Inline 4-cylinder
ECU Examples:
Bosch Motronic
Type:
6-speed S tronic (DSG) dual-clutch automatic
Drivetrain Options:
Front-wheel drive (FWD) or quattro all-wheel drive (AWD).
Manual Transmission Fluid:
G 052 171 A2 (or equivalent specification manual transmission fluid)
Dsg Transmission Fluid:
G 052 182 A2 (or equivalent dual-clutch transmission fluid)
NHTSA Rating:
Typically 4 or 5 stars for frontal and side impact (specific year and testing body dependent).
Euro Ncap Rating:
Typically 4 or 5 stars.
Electronic Stability Control:
Standard (ESP / ESC)
Anti-Lock Braking System:
Standard (ABS)
Electronic Brakeforce Distribution:
Standard (EBD)
Traction Control:
Standard (ASR/TCS)
Airbags:
Frontal, side, and curtain airbags (depending on configuration).
Seatbelts:
Pretensioner, force limiter seatbelts, often with height adjustment.
Rollover Protection:
Pop-up rollover hoops behind headrests (standard on Roadster).
Audio System:
Audi Concert or Audi Symphony systems, with CD player, AM/FM radio. Optional Bang & Olufsen sound system available.
Navigation:
Optional Audi Navigation Plus system with SD card slot.
Parking Sensors:
Optional front and rear parking sensors (Audi parking system).
Cruise Control:
Standard or optional, depending on trim level.
Auxiliary Input:
Standard auxiliary audio input jack.
Bluetooth:
Optional Bluetooth hands-free interface.
Longlife Service:
Up to 2 years or 30,000 km (18,600 miles), depending on driving conditions. Requires specific VW 504 00 / 507 00 oil.
Fixed Interval Service:
1 year or 15,000 km (9,300 miles). Requires specific VW 502 00 oil.
Service Intervals Spark Plugs
2.0 Tfsi:
Approximately 60,000 km (37,000 miles) for iridium spark plugs. Consult manual for exact type and interval.
Service Intervals Timing Belt Chain
2.0 Tfsi:
Timing chain driven, generally requires inspection but not regular replacement like a belt. Refer to manual for specific inspection intervals.
Coolant:
G 12 Plus Plus (G12++) or G 13 (pink/purple colored, ethylene glycol based).
Power Steering Fluid:
Pentosin CHF 11S or G 004 000 M2 (green colored hydraulic fluid).
Engine Oil 2.0 Tfsi:
Approximately 4.7 liters (5.0 US quarts) with filter change. Always verify with dipstick.
Piston Ring Wear:
Some early 2.0 TFSI engines (including those in the Mk2 TT) could experience increased oil consumption due to piston ring wear. The manual will cover diagnosis and potential solutions.
Dsg Mechatronics Issues:
Some DSG transmissions may develop issues with their mechatronic units, particularly if maintenance is neglected. Manual provides troubleshooting.
Coil Pack Failures:
Ignition coil packs can fail, leading to misfires. Manual will detail diagnosis and replacement.
Brand Focus:
Audi AG, a German premium automobile manufacturer, known for its 'Vorsprung durch Technik' (Advancement through Technology).
Mk2 Introduction Year:
2006
Mk2 Platform:
Volkswagen Group A5 (PQ35) platform, shared with Golf Mk5, A3 (8P), etc.
Manufacturing Location:
Győr, Hungary
