🏷️ Basic Information

Make:

BMW

Model:

G650GS

Model Line:

GS

Body Style:

Dual-sport Motorcycle

Generation Identifier:

G650GS (This generation primarily refers to models produced from 2008 onwards, inheriting from the F650GS Dakar platform and subsequent single-cylinder developments.)

Chassis Code:

R13

👋 Introduction

Model Segment:

Lightweight adventure touring motorcycle, known for its versatility and reliability.

Competitors:

Competed with models like the Kawasaki KLR650, Honda XR650L, and Suzuki DR650SE in its segment.

Design Philosophy:

Combines BMW's engineering prowess with a focus on accessible adventure riding, suitable for both commuting and off-road exploration.

Engine Type:

Single-cylinder, DOHC, 4-valve engine known for its torque and fuel efficiency.

Target Audience:

New riders, commuting riders, and adventure enthusiasts seeking a manageable and cost-effective BMW motorcycle.

📋 Manual Details

Applicable Models:

All BMW G650GS models/engines/trim/transmissions types.

Page Count Estimate:

Estimated 800-1200 pages (based on typical comprehensive factory service manuals for this class of motorcycle and the 7.62 GB file size, which implies extensive detailed content).

Manual Type:

Official Factory Service Repair Workshop Manual

Language:

English (typically, for BMW factory manuals sold in primary markets)

Format Type:

Disc Image File (.ISO) / Application (.exe)

📖 Manual Coverage

Engine:

Complete overhaul, disassembly, assembly, inspection, troubleshooting, performance tuning, and component testing of the single-cylinder engine.

Fuel System:

Fuel injection system, throttle body operation and adjustment, fuel pump, injectors, fuel pressure regulation, and emission control related to fuel delivery.

Cooling System:

Radiator, coolant, water pump, thermostat, cooling fan, and associated plumbing. Pressure testing and leak diagnosis.

Lubrication System:

Oil pump, oil filter, oil passages, oil level checks, oil cooler (if applicable), and lubrication system troubleshooting.

Chassis:

Frame, swingarm, suspension (front forks and rear shock absorber), steering head bearings, wheels, hubs, spokes, and bearing checks.

Electrical System:

Battery, charging system (alternator, voltage regulator), ignition system, lighting, starter motor, switches, fuses, relays, and diagnostic trouble codes (DTCs).

Braking System:

Hydraulic brake system (front and rear calipers, master cylinders, brake lines), brake fluid specifications, bleeding procedures, ABS system (if equipped), and brake pad/rotor replacement.

Drivetrain:

Clutch operation and adjustment, gearbox internal inspection and repair, final drive (chain and sprockets), and lubrication.

Bodywork:

Fairings, seat, fuel tank removal and installation, fenders, and general cosmetic component servicing.

Maintenance:

Scheduled maintenance, oil changes, filter replacements, chain adjustment, brake checks, tire pressure, and general inspection points.

Troubleshooting:

Step-by-step diagnostic procedures for common and uncommon issues, fault finding charts, and symptom-based troubleshooting.

Repair:

Detailed instructions for component disassembly, repair, reassembly, and adjustment covering all major systems.

Installation:

Procedures for installing genuine BMW parts and common aftermarket accessories.

Depth Level:

Comprehensive. Covers everything from basic fluid checks to complete engine rebuilds and advanced electrical system diagnostics.

Diagnostics:

Detailed diagnostic procedures for mechanical, electrical, and fuel injection systems, including the use of diagnostic tools (e.g., BMW Motorrad diagnostic software).

Torque Specifications:

All critical torque specifications for engine components, chassis fasteners, and suspension elements.

Wiring Diagrams:

High-quality, detailed wiring diagrams for all electrical systems, including color coding and component identification.

📊 Manual Specifications

File Format:

.ISO / .EXE

File Size:

7.62 GB

Printability:

Printable without restriction.

Diagram Quality:

Top quality diagrams and exploded views.

Binding Type:

Digital Download (N/A for physical binding)

Paper Type:

Digital (N/A for physical paper type)

Required Software:

DAEMON Tools, PowerISO, UltraISO, or similar disc imaging software for .ISO; standard Windows environment for .EXE.

Delivery:

Instant download link provided on checkout page after payment.

⚙️ Engine Specifications

Engine Type:

Single-cylinder, four-stroke

Displacement:

652 cc

Bore X Stroke:

100 mm x 83 mm

Compression Ratio:

12.0:1

Valve Train:

DOHC, 4 valves per cylinder

Cooling System:

Liquid-cooled

Horsepower Approx:

Approx. 47-50 hp @ 7000 rpm (depending on year and market)

Torque Approx:

Approx. 44-45 lb-ft @ 5250 rpm (depending on year and market)

Fuel Delivery:

Electronic Fuel Injection (EFI) with throttle body

Fuel Type:

Unleaded gasoline (RON 95)

Oil Capacity Approx:

Approx. 2.3 liters (with filter change)

Oil Type Recommendation:

SAE 15W-50 or 20W-50 API SG/SH/SJ, JASO MA certified motorcycle oil (refer to manual for exact specifications)

🔧 Transmission

Transmission Type:

5-speed manual

Clutch Type:

Wet multi-plate clutch

Final Drive:

O-ring sealed chain, 520 pitch

📐 Dimensions

Length Approx:

Approx. 2180 mm (85.8 in)

Width Approx:

Approx. 870 mm (34.3 in) at handlebars

Height Approx:

Approx. 1370 mm (53.9 in) at windscreen

Dry Weight Approx:

Approx. 175 kg (385.8 lbs)

Wet Weight Approx:

Approx. 197 kg (434.3 lbs)

Gross Vehicle Weight Rating Gvwr Approx:

Approx. 375 kg (826.7 lbs)

Payload Capacity Approx:

Approx. 178 kg (392.4 lbs)

Fuel Tank Capacity:

16 liters (4.2 US gal), including 3 liters reserve

Seat Height Approx:

Approx. 800 mm (31.5 in) (standard seat)

Ground Clearance Approx:

Approx. 150 mm (5.9 in)

🛡️ Safety Features

ABS:

Optional Anti-lock Braking System (ABS) available on some models/markets.

Lighting:

Halogen headlamp, LED taillight, turn signals.

Frame Construction:

Steel tube frame for durability and handling.

💡 Technology Features

Instrument Cluster:

Digital and analog display for speed, RPM, fuel level, gear indicator, and basic trip functions. May include ABS indicator.

ABS System:

Optional ABS system, which can be toggled on/off by the rider, provides enhanced braking safety.

Diagnostic Port:

Onboard diagnostics port for connecting diagnostic tools to read fault codes and live data.

🔧 Maintenance

Oil Change Interval:

Every 10,000 km (6,200 miles) or annually, whichever comes first (refer to manual for exact specification).

Air Filter Check:

Inspect every 10,000 km (6,200 miles); clean or replace as needed.

Spark Plug Replacement:

Replace every 20,000 km (12,400 miles).

Valve Clearance Check:

Check every 20,000 km (12,400 miles).

Brake Fluid Change:

Replace every 2 years, regardless of mileage.

Brake Fluid Type:

DOT 4 (refer to manual for specific BMW P/N or equivalent)

Coolant Type:

BMW Motorrad Coolant - Blue (ethylene glycol-based, 50% mixture with distilled water) (refer to manual for specific BMW P/N)

Common Wear Items:

Clutch plates, fork seals, chain and sprockets, wheel bearings due to mileage and riding conditions.

Potential Electrical Issues:

Occasional stator or voltage regulator failures, common in many motorcycle models of this era. The manual will cover diagnosis.

📚 Vehicle History

Bmw Motorcycles:

BMW Motorrad has a long history of producing reliable and capable motorcycles, including pioneering the dual-sport segment with its GS line.

G650Gs Lineage:

The G650GS is an evolution of the successful F650GS single-cylinder platform, with the engine originally developed with Rotax. It represents BMW's commitment to the lightweight adventure segment.

Manufacturing Location:

Typically manufactured in Berlin, Germany by BMW Motorrad.

🏆 Awards & Recognition

Segment Accolades:

While specific awards might be hard to pinpoint without a precise model year, the G650GS has been recognized for its value, versatility, and accessibility in the dual-sport market by various motorcycle publications.

Reliability Reputation:

Generally considered a reliable and robust motorcycle, with the single-cylinder engine proving durable with proper maintenance.
