🏷️ Basic Information

Make:

Cadillac

Model:

ATS

Year:

2017

Generation:

First Generation (Second Generation Debut Year)

👋 Introduction

Positioning:

The Cadillac ATS is positioned as a compact luxury sedan and coupe, competing in a segment dominated by German and Japanese brands. It emphasizes performance, design, and a premium driving experience.

Key Competitors:

BMW 3 Series, Mercedes-Benz C-Class, Audi A4, Lexus IS, Infiniti Q50.

Chassis Design:

Built on GM's Alpha platform, known for its lightweight construction and excellent handling dynamics. This platform contributes significantly to the ATS's sporty character.

Manual Advantage:

Provides direct access to OEM repair procedures, ensuring accuracy and efficiency for DIY mechanics and professionals alike. Eliminates reliance on generic or outdated information.

Utility For Owners:

Empowers owners to confidently perform routine maintenance, diagnose issues, and undertake repairs, potentially saving significant costs compared to dealership labor.

📋 Manual Details

Covered Models:

All 2017 Cadillac ATS models (including Sedan and Coupe variants)

Coverage Scope:

Comprehensive A-Z repairs and maintenance

Estimated Pages:

Varies by specific vehicle configuration, but presented as a complete digital resource.

Type:

Factory Service and Repair Manual

Language:

English

Format:

Digital (PDF)

Digital Convenience:

Single, easy-to-use PDF manual format eliminates the need to manage multiple physical books, allowing for quick searching and printing of specific sections.

📖 Manual Coverage

Engine:

Detailed coverage of engine systems, including mechanical, control, fuel, emissions, intake, exhaust, cooling, lubrication, ignition, starting, and charging.

Transmission:

Coverage for both automatic and manual transmissions, including operation, diagnostics, and repair.

Drivetrain:

Includes detailed information on transfer cases, propeller shafts, drive shafts, differentials, axles, and suspension systems.

Brakes:

Comprehensive coverage of brake control systems, including parking brake, and detailed brake system diagnostics and repair.

Steering:

Includes steering column and power steering system diagnosis and repair.

HVAC:

Detailed coverage of air conditioning systems.

Safety Systems:

Coverage of Supplemental Restraint System (SRS), seat belts, and engine immobilizer systems.

Electrical Systems:

Extensive coverage of electrical systems, including wiring schematics, multiplex/CAN communication, cruise control, wipers/washers, door locks, meters, audio/visual, horn, and instrument panel.

Body And Interior:

Includes sections on windshields, glass, mirrors, instrument panels, seats, engine hoods, doors, exterior, and interior components.

Maintenance Procedures:

Detailed scheduled maintenance, fluid changes, filter replacements, and general upkeep procedures.

Diagnostic Procedures:

In-depth diagnostic trees, symptom-based troubleshooting, and diagnostic trouble code (DTC) explanations and repair strategies.

Repair Procedures:

Complete step-by-step repair instructions for virtually all mechanical and electrical components.

Wiring Schematics:

Comprehensive and detailed wiring diagrams for all vehicle electrical systems.

Specifications And Data:

Inclusion of all necessary technical specifications, torque values, fluid types, capacities, and tolerances.

Component Replacement:

Detailed instructions for replacing components such as engine parts, transmission assemblies, suspension parts, brake components, body panels, interior trim, and electrical modules.

Depth:

Factory-level detail, equivalent to what dealership technicians use for diagnosis and repair. Covers everything from routine maintenance to complex component overhauls and system diagnostics.

Diagnostic Tools:

Information often implies the use of GM's Global Diagnostic System (GDS2) or similar tools for advanced diagnostics, providing context for error codes and module programming.

📊 Manual Specifications

File Type:

PDF

Searchability:

Searchable text within the PDF document.

Printability:

Fully printable, allowing users to print specific pages or entire sections.

Image Resolution:

High-resolution images, diagrams, and illustrations that can be enlarged for detailed viewing.

Binding:

Digital (no physical binding)

Paper Type:

N/A (Digital format)

Operating Systems:

Compatible with all versions of Windows (Vista32/64, XP, ME, 98, NT, 2000) and macOS.

Software Requirements:

Adobe PDF Reader and Winzip (free online).

⚙️ Engine Specifications

Engine Options 2017:

2.0L Turbocharged Inline-4 (LTG), 3.6L V6 (LGX).

2.0L Turbo Horsepower:

272 hp @ 5500 rpm

2.0L Turbo Torque:

295 lb-ft @ 1700-4700 rpm

3.6L V6 Horsepower:

335 hp @ 6750 rpm

3.6L V6 Torque:

285 lb-ft @ 5300 rpm

Fuel Delivery:

Direct Injection (DI) for both engines.

Covered Engine Codes:

LTG, LGX

🔧 Transmission

Standard Transmission:

8-speed automatic (8L45 or 8L90 depending on engine/drivetrain).

Optional Transmission:

6-speed manual (M34) available on select models with the 2.0L Turbo engine.

Drivetrain Options:

Rear-Wheel Drive (RWD) and All-Wheel Drive (AWD) configurations are covered.

📐 Dimensions

Wheelbase:

109.4 inches (Sedan), 109.9 inches (Coupe)

Length:

Approx. 182.8 inches (Sedan), 183.0 inches (Coupe)

Width:

Approx. 71.5 inches

Height:

Approx. 56.2 inches (Sedan), 54.1 inches (Coupe)

Curb Weight Range:

Approx. 3,500 - 3,800 lbs, depending on configuration.

Trunk Volume:

Approx. 13.1 cu ft (Sedan), 10.4 cu ft (Coupe)

🛡️ Safety Features

NHTSA Rating 2017:

Generally received high safety ratings, including 5-star overall from NHTSA for many configurations, though specific ratings can vary by year and exact configuration.

Active Safety Features Covered:

Covers systems like Anti-lock Braking System (ABS), Traction Control System (TCS), StabiliTrak Electronic Stability Control, optional Forward Collision Alert, Lane Departure Warning, Lane Keep Assist, Side Blind Zone Alert, Rear Cross-Traffic Alert, and Adaptive Cruise Control.

Passive Safety Features Covered:

Includes coverage for airbags (front, side, curtain), seat belt pretensioners, and body structure integrity relevant to crash performance.

💡 Technology Features

Infotainment System:

CUE (Cadillac User Experience) system with touch screen interface, Bluetooth connectivity, and optional navigation.

Driver Assistance Systems:

Availability of advanced driver-assistance systems (ADAS) such as adaptive cruise control, automatic emergency braking, lane keeping assist, and more, all covered for diagnosis and calibration.

Connectivity Features Covered:

Covers Bluetooth pairing, USB ports, and the vehicle's internal network (CAN bus) for diagnostic communication.

🔧 Maintenance

Oil Change Interval:

Typically every 7,500 miles or 12 months, with oil life monitoring system; consult manual for specific engine and driving conditions.

Tire Rotation Interval:

Every 7,500 miles.

Cabin Air Filter Replacement:

Every 24,000 miles or 2 years.

Engine Oil Type 2.0T:

SAE 0W-20, API SN, Dexos1 Gen 2.

Engine Oil Type 3.6L:

SAE 0W-30, API SN, Dexos1 Gen 2.

Coolant Type:

GM P/N 12346290 (or equivalent) - Dex-Cool Extended Life 50/50 Prediluted.

Brake Fluid Type:

DOT 3 or DOT 4 compatible.

Transmission Fluid Type 8-Spd Auto:

Dexron-VI (GM P/N 88863455 or equivalent).

Common Wear Items:

Brake pads and rotors, tires, suspension components (e.g., control arms, bushings) due to performance-oriented tuning.

Potential Electrical Issues:

Some owners have reported intermittent issues with certain sensors or control modules, often resolvable with software updates or component replacement as detailed in the manual.

Turbo System Care:

Proper maintenance of the turbocharger system, including oil quality and cooling, is crucial for longevity; the manual provides specific guidance.

📚 Vehicle History

Cadillac Legacy:

Cadillac, as the longest-standing American luxury car brand, has a history of innovation and performance. The ATS was designed to directly challenge established European luxury sedans.

Ats Introduction:

The Cadillac ATS was first introduced for the 2013 model year, representing Cadillac's serious effort to compete in the highly contested compact luxury sedan segment. The 2017 model year represents a refinement of the initial generation.

Manufacturing Location:

Lansing Grand River Assembly Plant, Lansing, Michigan, USA.

🏆 Awards & Recognition

Awards And Accolades:

The ATS has historically received numerous awards and positive reviews for its driving dynamics, chassis tuning, and design, often praised for its ability to compete with European benchmarks.

Handling Reviews:

Widely lauded by automotive journalists for its sharp handling and communicative steering, a testament to the Alpha platform's engineering.
