Segment:
Luxury Mid-size Sedan
Competitors:
BMW 5 Series, Mercedes-Benz E-Class, Audi A6, Lexus GS
Value Proposition:
Provides dealership-level technical information for DIY repairs, saving time and money.
Ease Of Use:
One easy-to-use PDF manual, eliminating the need to flip through multiple books. Searchable and printable.
Primary Coverage:
2016 Cadillac CTS All Models & All Repairs A-Z
Coverage Scope:
Vehicle Specific; Exact same manual used by dealership technicians.
Estimated Page Count:
Comprehensive (Specific count not provided, but implied extensive coverage for A-Z repairs)
Type:
Service and Repair Manual
Engine Systems:
Engine, Control System, Fuel Service Specifications, Emission Control, Intake Exhaust Cooling, Lube, Ignition Starting Charging
Drivetrain Systems:
Auto Transmission Clutch, Manual Transmission, Transfer Propeller Shaft, Drive Shaft, Differential, Axle Suspension
Chassis Systems:
Tire & Wheel, Brake Control, Brake, Parking Brake, Steering Column, Power Steering
Body And Interior Systems:
Air Condition, Suppl Restraint System, Seat Belt, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Lock, Meter Audio/Visual, Horn, Windshield/Glass Mirror, Instrument Panel, Seat, Engine Hood/ Door, Exterior & Interior
Electrical And Communication Systems:
Electrical, Multiplex/ Can Communication
Repair Procedures:
Complete Step-by-Step Instructions for all repairs (A-Z)
Diagnostic Procedures:
Diagnosis of all vehicle systems
Maintenance Procedures:
Maintenance schedules and procedures
Depth:
Factory High Detail; Includes diagrams, illustrations, wiring schematics, and specifications.
Printability:
All pages are printable; ability to blow up images and print enlarged copies.
Binding:
Digital (PDF) - No physical binding
Paper Type Suitability:
N/A (Digital format allows on-demand printing on any paper type)
Operating Systems:
Windows Vista (32 & 64), XP, ME, 98, NT, 2000, and Mac OS
Required Software:
Adobe PDF Reader and Winzip (both free online)
Engine 1 Displacement:
2.0L Turbocharged Inline-4 (RPO LTG)
Engine 1 Horsepower:
268 hp @ 5600 rpm
Engine 1 Torque:
295 lb-ft @ 1700-5500 rpm
Engine 2 Displacement:
3.6L Naturally Aspirated V6 (RPO LGX)
Engine 2 Horsepower:
323 hp @ 6800 rpm
Engine 2 Torque:
285 lb-ft @ 4800 rpm
Performance Engine Displacement:
3.6L Twin-Turbocharged V6 (RPO LT4 - CTS-V)
Performance Engine Horsepower:
640 hp @ 6400 rpm
Performance Engine Torque:
630 lb-ft @ 3600 rpm
Fuel Delivery:
Direct Injection (DI)
Emission System:
Catalytic Converters, Oxygen Sensors, Evaporative Emission Control (EVAP) System
Transmission Type Std:
8-speed automatic (8L45) for 2.0L and 3.6L RWD models
Transmission Type Opt:
8-speed automatic (8L90) for 3.6L Twin-Turbo and AWD models
Transmission Type Performance:
8-speed automatic (8L90) for CTS-V
Manual Transmission Option
Manual Availability:
Limited availability, typically not the standard or widely advertised option for 2016 models.
Transmission Features:
Driver Shift Control, Paddle Shifters (on select trims/models)
Curb Weight Base:
Approximately 3,600 - 3,800 lbs (varies by engine and drivetrain)
Gross Vehicle Weight Rating:
Approximately 4,700 - 4,900 lbs (varies)
Trunk Volume:
13.7 cubic feet
NHTSA Overall Rating:
5-Star (for models tested)
IIHS Top Safety Pick:
Yes (for models tested with specific optional equipment)
Airbags:
Frontal, Side-Impact, Curtain, Knee Airbags
Seat Belts:
3-point, pretensioners, load limiters
Child Seat Anchors:
LATCH system
Traction Control:
StabiliTrak electronic stability and traction control
Braking System:
4-wheel disc brakes with ABS
Driver Assistance Features:
Available features include Forward Collision Alert, Lane Departure Warning, Lane Keep Assist, Blind Spot Alert, Rear Cross-Traffic Alert, Adaptive Cruise Control, Automatic Parking Assist.
Infotainment System:
Cadillac CUE (Cadillac User Experience) with 8-inch touchscreen.
Connectivity Features:
Bluetooth, USB ports, SiriusXM Satellite Radio, available Apple CarPlay and Android Auto integration (software dependent).
Driver Assistance Suite:
Comprehensive suite of available driver assistance systems including adaptive cruise control, automatic parking, lane keeping assist, blind-spot monitoring, and forward collision warning.
Suspension System:
Available Magnetic Ride Control adaptive suspension.
Driving Modes:
Driver Mode Selector (Tour, Sport, Snow/Ice) influencing throttle response, transmission shift points, and steering feel.
Oil Change Interval:
Typically 7,500 miles or 6 months, or as indicated by the Oil Life Monitoring System.
Tire Rotation Interval:
Every 7,500 miles
Brake Fluid Flush:
Consult manual, often around 2-3 years or 30,000-45,000 miles.
Engine Coolant Flush:
Refer to manual; initial change at 5 years/150,000 miles, then every 2-3 years/30,000-45,000 miles.
Engine Oil Specification:
Dexos1 Gen 2 SAE 0W-20 Synthetic (for 2.0L Turbo and 3.6L V6). Check manual for specific variant.
Transmission Fluid Type Auto:
Dexron ULV (Ultra Low Viscosity) for 8-speed automatics.
Coolant Type:
GM Super Coolant (Pink) - Dex-Cool compatible
Known Issues Common Problems
Potential Issues:
Water pump leaks (especially on V6 engines), transmission issues (shifting complaints, fluid leaks), electronic control module (ECM) glitches, carbon buildup in direct-injection engines, potential for door handle illumination failures.
Cadillac Legacy:
Long-standing American luxury marque known for innovation and upscale vehicles.
Cadillac Cts Evolution:
The 2016 CTS is part of the third generation, which saw a significant redesign focusing on sharper styling, improved performance, and a more engaging driving experience, moving towards a more athletic luxury sedan.
Manufacturing Location:
Lansing Grand River Assembly, Lansing, Michigan, USA
