Segment:
Luxury Mid-Size Sedan
Positioning:
The Cadillac CTS for 2013 continued its mission to compete against established European luxury sedans, offering a blend of American luxury, performance, and distinctive styling.
Competitors:
BMW 5 Series, Mercedes-Benz E-Class, Audi A6, Lexus GS, Acura TL.
Design:
Angular 'Art and Science' design language, distinctive grille, LED lighting elements.
Performance:
Rear-wheel drive bias, optional all-wheel drive, potent V6 engine options, available performance trims (e.g., CTS Vsport).
Coverage:
All models, engines, and trim levels for the 2013 Cadillac CTS.
Page Count Estimate:
Estimated 2000+ pages (typical for comprehensive workshop manuals).
Type:
Workshop Service Repair Manual
Format:
Digital Downloadable (PDF)
Powertrain:
Engine mechanical, fuel system, lubrication, cooling system, ignition system, exhaust system, engine management, transmission (automatic and manual), drivetrain, differentials.
Chassis:
Suspension (front and rear), steering system, brake system (hydraulic and electronic components), wheels, tires, alignment.
Electrical:
Battery, charging system, starting system, lighting, instrument cluster, body control modules, infotainment system, HVAC controls, power windows/locks/seats, wiring diagrams, diagnostic trouble codes (DTCs).
Body:
Body structure, exterior panels, interior trim, doors, glass, seats, airbags, safety restraint systems.
Maintenance:
Scheduled maintenance intervals, fluid changes, filter replacements, lubrication points, inspections.
Repair:
Step-by-step diagnostic and repair procedures for all major vehicle systems, including engine rebuilds, transmission overhauls, brake component replacement, electrical system troubleshooting, and body panel repair.
Troubleshooting:
Diagnostic flowcharts, symptom-based troubleshooting guides, common issues and their solutions.
Technical Specifications:
Torque specifications, clearances, fluid capacities, electrical resistance values, diagnostic data.
Depth:
Comprehensive from basic maintenance and fluid checks to advanced diagnostics, component replacement, and complete system overhauls.
Engine Code:
LF1 (3.6L V6 DI VVT)
Displacement:
3.6 Liters (3564 cc)
Configuration:
V6, 24-valve, DOHC
Bore X Stroke:
94.0 mm x 85.6 mm
Compression Ratio:
11.5:1
Fuel System:
Direct Injection (DI), Port Fuel Injection (PFI) on some variants, Electronic Throttle Control (ETC).
Horsepower:
323 hp @ 6800 rpm (3.6L V6 DI)
Torque:
278 lb-ft @ 4800 rpm (3.6L V6 DI)
Engine 2 Code:
LFX (3.6L V6 DI VVT - some variants)
Engine 2 Displacement:
3.6 Liters (3564 cc)
Engine 2 Horsepower:
Up to 323 hp
Engine 2 Torque:
Up to 278 lb-ft
Engine 3 Code:
LS3 (6.2L V8 - CTS Vsport)
Engine 3 Displacement:
6.2 Liters (6162 cc)
Engine 3 Horsepower:
420 hp @ 5900 rpm
Engine 3 Torque:
407 lb-ft @ 4500 rpm
Transmission Type:
6-speed automatic (RWD)
Transmission Type AWD:
6-speed automatic (AWD)
Transmission Vsport:
8-speed automatic (CTS Vsport)
Shift Modes:
Driver Shift Control (manual shifting capability), Paddle Shifters (on some models/trims).
Automatic Transmission Fluid:
Dexron VI (refer to manual for exact fill quantity and procedure).
NHTSA Overall:
5-Star (for many configurations, refer to specific NHTSA data for 2013 CTS)
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Standard Traction Control System (TCS)
Stability Control:
Standard StabiliTrak Electronic Stability Control (ESC)
Driver Assistance Optional:
Adaptive Cruise Control, Forward Collision Alert, Automatic Collision Preparation, Lane Departure Warning, Blind Spot Monitoring, Rear Cross-Traffic Alert.
Airbags:
Front airbags (driver and passenger), side-impact airbags (front and rear), head curtain airbags (front and rear).
Seatbelts:
Pretensioning seatbelts, LATCH child seat anchors.
Infotainment System:
Cadillac User Experience (CUE) with touch-screen interface, voice recognition, Bluetooth connectivity, USB ports.
Navigation:
Available HDD-based navigation system with real-time traffic.
Audio:
Bose premium audio system available, often with 10 speakers.
Adaptive Cruise Control:
Optional adaptive cruise control system with braking and acceleration control.
Parking Assist:
Available front and rear parking sensors, rearview camera.
Connectivity Options:
Bluetooth for phone and audio streaming, USB connectivity, auxiliary audio input.
Oil Change Interval:
Refer to manual; typically 7,500 - 10,000 miles or 12 months for synthetic oil, depending on driving conditions.
Engine Air Filter:
Inspect at 30,000 miles, replace as needed.
Cabin Air Filter:
Replace every 24,000 miles or 24 months.
Spark Plugs:
Typically around 100,000 miles for direct-injection engines (refer to specific plug type and manual recommendation).
Coolant Flush:
Refer to manual; often around 5 years or 100,000 miles for long-life coolants.
Engine Oil Type:
SAE 5W-30 Full Synthetic (GM dexos1 specification recommended).
Coolant Type:
GM Orange Coolant (50/50 mix of antifreeze and distilled water).
Brake Fluid Type:
DOT 3 or DOT 4.
Common Issues:
Potential for carbon buildup on intake valves (direct injection engines), occasional issues with infotainment system glitches, wear on suspension components (especially with performance trims or aggressive driving).
Cadillac Legacy:
Cadillac, America's longest-producing automobile brand, has a long history of luxury, innovation, and performance.
Cts Generation:
This 2013 model represents the second generation of the CTS (introduced for the 2008 model year), which was updated for 2012 with refreshed styling and technology.
Manufacturing Location:
Lansing Grand River Assembly, Lansing, Michigan, USA
