Market Position:
Premium full-size luxury SUV, competing with models like Lincoln Navigator, Lexus LX, and Infiniti QX80. This manual targets Escalade owners and independent repair shops seeking authoritative repair data.
Target Audience:
Escalade owners seeking to perform their own maintenance and repairs, independent auto repair shops, automotive technicians.
Competitive Analysis:
Provides dealer-level technical information, surpassing generic aftermarket manuals in specificity and accuracy for the Cadillac Escalade.
Key Features:
Vehicle-specific, comprehensive A-Z coverage, step-by-step instructions, detailed diagrams, wiring schematics, and specifications in a single, easily navigable PDF format.
Ease Of Use:
Digital format allows for quick searching, zooming, and printing of specific sections, making it practical for use in any workshop environment.
Systems Covered:
Engine, Control System, Mechanical, Fuel System, Emission Control, Intake, Exhaust, Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Clutch, Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axle, Suspension, Tire & Wheel, Brake Control, Brakes, Parking Brake, Steering Column, Power Steering, Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer System, Door Locks, Meter & Audio/Visual, Horn, Windshield/Glass/Mirrors, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication
Powertrain Control Module PCM Coverage:
Detailed information on PCM operation, diagnostic trouble codes (DTCs), and reprogramming procedures.
Body Control Module Bcm Coverage:
Extensive coverage of the BCM for interior and exterior electronics, door modules, power windows, locks, and lighting.
Suspension System Coverage:
Independent front suspension, multi-link rear suspension, Magnetic Ride Control system (if equipped), air suspension system (if equipped).
Steering System Coverage:
Hydraulic power steering system, steering column components, intermediate shaft, power steering fluid and pump.
Climate Control System Coverage:
Front and rear climate control systems, A/C compressor, refrigerant, evaporator, condenser, blower motor, and HVAC controls.
Chassis And Body Coverage:
Frame inspection and repair, body panel replacement, door mechanisms, hood and tailgate operation, weatherstripping.
Procedures Included:
Maintenance, Service, Diagnosis, Repair, Troubleshooting, Component Replacement, System Overhaul, Wiring Schematic Interpretation
Diagnostics Procedures:
On-board diagnostics (OBD-II) system interpretation, scan tool data analysis, circuit testing, component testing.
Engine Rebuild Procedures:
Detailed steps for engine disassembly, inspection, component replacement (pistons, rings, bearings, valves), and reassembly.
Electrical Component Testing:
Testing procedures for alternators, starters, batteries, fuses, relays, sensors, and actuators.
Technical Depth:
Factory-level detailed step-by-step instructions, diagrams, illustrations, and wiring schematics for comprehensive vehicle repair.
Wiring Schematics Detail:
Comprehensive and high-quality wiring diagrams for all electrical systems, color-coded and component-identified.
Standard Transmission:
6-speed automatic (6L80/6L90)
Optional Transmission:
N/A (6-speed automatic was standard across the range)
Transmission Features:
Includes manual mode (Tap Shift), Tow/Haul mode, and Driver Shift Control.
Transmission Fluid Capacity:
Approximately 9.7 US quarts (9.2 liters) for the 6L80/6L90 transmission. (Verify with manual for exact capacity during rebuild).
Transfer Case Type:
Full-time, electronically controlled, 2-speed (with neutral and low range) on 4WD models.
Differential Type:
G80 locking rear differential (optional), open front differential.
Wheelbase:
116.0 inches (Standard), 130.0 inches (ESV)
Overall Length:
200.7 inches (Standard), 222.4 inches (ESV)
Track Width Front:
Approx. 68.2 inches
Track Width Rear:
Approx. 68.0 inches
Curb Weight:
Approx. 5,400 - 5,800 lbs (depending on configuration)
Gross Vehicle Weight Rating Gvwr:
Approx. 7,300 - 7,500 lbs (depending on configuration)
Towing Capacity:
Up to 8,300 lbs (depending on configuration and trailering package).
Cargo Volume:
Up to 108.3 cu ft (behind front seats, standard wheelbase); Up to 137.4 cu ft (behind front seats, ESV)
NHTSA Overall Safety Rating:
Typically 5-star for frontal and side impact (check specific year for exact ratings).
Active Features:
StabiliTrak Electronic Stability Control, Traction Control System (TCS), Anti-lock Braking System (ABS), Rearview Camera, Ultrasonic Rear Parking Assist.
Braking System:
Four-wheel disc brakes with ABS, often equipped with Brembo front brakes on performance-oriented trims.
Tire Pressure Monitoring System Tpms:
Standard on all models.
Passive Features:
Frontal airbags, front and second-row side-impact airbags, head curtain airbags for all rows, front seat belt pretensioners.
Seat Belt Features:
3-point height-adjustable front seat belts with pretensioners, second and third-row seat belts.
Infotainment System:
Cadillac CUE (Cadillac User Experience) on later models, or earlier systems featuring touchscreens, navigation, premium audio (Bose), and Bluetooth connectivity.
Audio System Options:
Bose premium audio systems with varying speaker counts (e.g., 10-speaker, 16-speaker).
Driver Assistance Features:
Optional features could include Adaptive Cruise Control, Magnetic Ride Control suspension, and Keyless Access with push-button start.
Connectivity Options:
Bluetooth for hands-free calling and audio streaming, USB ports, auxiliary audio input.
Oil Change Interval:
Every 7,500 miles or 12 months, whichever comes first (using synthetic oil). Check manual for specific oil type and capacity.
Transmission Fluid Service Interval:
Every 100,000 miles, or sooner under severe towing conditions. Refer to manual for exact procedure.
Engine Oil Specification:
GM dexos1™ Synthetic 5W-30 (or equivalent API SN certified oil)
Transmission Fluid Specification:
Dexron VI Automatic Transmission Fluid
Coolant Specification:
GM Dex-Cool (OAT) Extended Life Antifreeze/Coolant
Brake Fluid Specification:
DOT 3 or DOT 4 High-Temperature Brake Fluid
Known Issues:
Potential for AFM (Active Fuel Management) lifter issues, transmission solenoid issues, and electrical gremlins in some units. The manual addresses diagnostic and repair procedures for these common concerns.
Suspension Components:
Potential wear in control arm bushings, ball joints, and tie rod ends, especially on higher-mileage vehicles. Magnetic Ride Control sensors can also fail.
Brand Heritage:
Cadillac, a historic American luxury brand, known for its opulent interiors, powerful engines, and comfortable ride.
Cadillac Philosophy:
Cadillac's historical commitment to luxury, performance, and innovation is evident in the Escalade's design and engineering.
Model Evolution:
The third generation (2007-2014) of the Escalade marked a significant redesign with a more powerful V8 engine, updated styling, and enhanced technology, solidifying its position as a segment leader.
Design Philosophy:
Emphasis on robust body-on-frame construction for towing and durability, combined with luxurious appointments and advanced comfort features.
Generation Transition:
This generation (2007-2014) is often referred to as the 'GMT900' Escalade, featuring a more integrated body-on-frame design and updated styling cues.
Production Location:
Arlington, Texas, USA
