🏷️ Basic Information

Make:

Cadillac

Model:

SRX

Year:

2012

Vehicle Platform:

GM Epsilon II

👋 Introduction

Positioning:

Premium crossover SUV catering to a luxury segment, offering comfort, technology, and performance.

Competitors:

Audi Q5, BMW X3, Lexus RX, Mercedes-Benz GLK-Class, Acura RDX.

Features:

Available with front-wheel drive or adaptive all-wheel drive, advanced infotainment, comfortable interior, good cargo space.

📋 Manual Details

Systems Covered Broad:

All models, all repairs A-Z

Estimated Page Count:

Detailed, typically several thousand pages for a comprehensive factory manual.

Type:

Factory Service and Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Engine Mechanical:

Detailed disassembly, assembly, inspection, and repair procedures for all engine components.

Engine Control System:

Diagnostic procedures, sensor/actuator testing, ECU identification and troubleshooting.

Fuel System:

Fuel pump, injectors, fuel pressure, evaporative emission control (EVAP) system service.

Emission Control:

Catalytic converter, O2 sensors, EGR system, evaporative emissions, diagnostic trouble codes (DTCs) related to emissions.

Intake Exhaust Cooling:

Intake manifold, exhaust system, cooling system components (radiator, water pump, thermostat), pressure testing.

Lube Oil System:

Oil pump, oil filter, oil cooler (if applicable), oil pressure testing, lubrication points.

Ignition Starting Charging:

Spark plugs, ignition coils, starter motor, alternator, battery testing, charging system diagnostics.

Automatic Transmission:

Removal, installation, internal component repair, fluid and filter service, torque converter diagnostics.

Manual Transmission:

Service procedures for manual transmission variants, clutch service.

Transfer Case Propeller Shaft:

Service and repair of the transfer case and propeller shaft assemblies.

Drive Shaft Axle:

Front and rear drive shafts, CV joints, axle shafts, hub assemblies.

Suspension:

Front and rear suspension components (struts, shocks, control arms, ball joints, bushings), alignment specifications.

Tire Wheel:

Tire pressure monitoring system (TPMS) service, wheel bearing replacement, wheel alignment specifications.

Brake Control System:

ABS, EBD, traction control system diagnostics and repair, hydraulic component service.

Brake System:

Disc brake and drum brake service, caliper replacement, rotor resurfacing/replacement, brake bleeding procedures.

Parking Brake:

Service and adjustment of the parking brake system.

Steering Column:

Tilt and telescoping steering column service, ignition switch replacement.

Power Steering:

Hydraulic power steering pump, rack and pinion service, fluid replacement.

Air Conditioning:

Refrigerant handling, compressor, condenser, evaporator service, system diagnostics, leak detection.

Supplemental Restraint System:

Airbag system diagnostics, module replacement, sensor calibration, seat belt pre-tensioner service.

Seat Belt:

Seat belt assembly inspection, replacement, and related components.

Engine Immobilizer:

Immobilizer system operation and troubleshooting.

Cruise Control:

Cruise control system diagnostics and repair.

Wiper Washer System:

Wiper motor, washer pump, linkage service, fluid replacement.

Door Lock System:

Power door locks, keyless entry system service, actuator replacement.

Meter Audio Visual:

Instrument cluster diagnostics, infotainment system service, speaker replacement.

Horn System:

Horn operation diagnostics and repair.

Windshield Glass Mirror:

Windshield replacement, mirror assembly service.

Instrument Panel:

Instrument cluster removal, installation, and related components.

Seats:

Power seat adjustment mechanisms, heating/ventilation systems, seat trim service.

Engine Hood Door Body:

Hood latch and strut service, door hinge and lock mechanism repair, body panel alignment.

Exterior Interior Trim:

Fascias, moldings, interior trim panels, headliner service.

Electrical System:

Comprehensive wiring diagrams, fuse box locations, relay functions, component testing.

Multiplex Can Communication:

CAN bus system diagnostics, module communication troubleshooting, network analysis.

Maintenance Procedures:

Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs.

Diagnostic Procedures:

Step-by-step troubleshooting guides for all major systems, including symptom-based diagnosis.

Repair Procedures:

Complete disassembly, repair, and reassembly instructions for all vehicle components.

Installation Procedures:

Correct installation methods for replacement parts and accessories.

Wiring Schematics:

Detailed, system-specific wiring diagrams for all electrical circuits.

Depth:

Factory-level detail, covering basic maintenance to complex diagnostics and complete mechanical/electrical overhauls.

📊 Manual Specifications

Compatibility:

Windows (Vista32/64, XP, ME, 98, NT, 2000) and Mac compatible.

Printability:

All pages are printable, allowing for enlarged image printing.

Binding Type:

Digital (PDF), no physical binding.

Paper Type:

N/A (Digital format).

⚙️ Engine Specifications

Engine Code And Displacement:

LU1 (3.6L V6 Direct Injection VVT)

Horsepower:

302 hp @ 6300 rpm

Torque:

260 lb-ft @ 3400 rpm

Fuel Delivery:

Direct Injection

Fuel Type:

Premium Unleaded Gasoline (Recommended)

🔧 Transmission

Transmission Type:

6-speed automatic transmission (Hydra-Matic 6T70/75)

Optional Transmission:

N/A for 2012 model year (only automatic available).

Transmission Features:

Driver Shift Control (manual mode), Adaptive Shift Control (ASC).

📐 Dimensions

Length:

190.8 inches

Width:

75.2 inches

Height:

65.7 inches

Wheelbase:

110.5 inches

Curb Weight:

Approximately 4,300 - 4,500 lbs depending on configuration.

🛡️ Safety Features

NHTSA Overall Rating:

Likely 4 or 5 stars (specific rating varies by test year and configuration).

Active Safety Features:

StabiliTrak® Electronic Stability Control, Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Brake-force Distribution (EBD).

Passive Safety Features:

Front airbags, front side-impact airbags, roof-mounted side-curtain airbags for front and second-row passengers, front seatbelt pretensioners, LATCH child seat anchor system.

💡 Technology Features

Infotainment System:

Cadillac User Experience (CUE) system with touch screen interface, Bluetooth connectivity, USB ports, optional navigation.

Driver Assistance Features:

Available rear vision camera, ultrasonic rear parking assist, optional adaptive remote start.

Connectivity Options:

OnStar® system (with subscription), Bluetooth for phone and audio streaming.

🔧 Maintenance

Oil Change Interval:

Typically every 7,500 to 10,000 miles or 6-12 months, depending on driving conditions and oil type (consult manual for exact recommendation based on Oil Life Monitoring System).

Tire Rotation Interval:

Every 7,500 miles.

Engine Oil Type:

SAE 5W-30 Synthetic (GM dexos1™ approved is highly recommended).

Transmission Fluid Type:

Dexron-VI Automatic Transmission Fluid (ATF).

Coolant Type:

GM P/N 89029609 (or equivalent) - Orange-colored silicate-free coolant.

Common Problems:

Potential issues can include oil leaks from valve cover gaskets or oil pan, power steering pump whine, and sometimes issues with the exhaust system flex pipes. Electronic issues related to sensors or modules can also occur, typical of complex luxury vehicles.

📚 Vehicle History

Heritage Focus:

Cadillac, as a luxury division of General Motors, has a long history of producing premium vehicles known for comfort and advanced technology.

Second Generation Introduction:

The second generation SRX was introduced for the 2010 model year, moving to the Epsilon II platform shared with models like the Chevrolet Equinox and GMC Terrain, but with significant Cadillac-specific styling and luxury enhancements.

Manufacturing Location:

GM's Ramos Arizpe Assembly Plant in Mexico.

🏆 Awards & Recognition

Safety Awards:

While specific awards for the 2012 model may vary, the SRX line often received praise for its safety features and structural integrity from organizations like the IIHS and NHTSA.
