Vehicle Segment:
Luxury Crossover SUV
Target Audience:
Owners seeking to perform their own maintenance and repairs, DIY enthusiasts, independent repair shops
Competitive Set 2016:
Acura RDX, BMW X3, Audi Q5, Lexus NX, Mercedes-Benz GLC
Manual Advantage:
Vehicle-specific, factory-authorized content, comprehensive coverage, digital format benefits (searchability, portability)
Value Proposition:
Empowers owners with the exact same information used by dealership technicians, enabling accurate diagnosis and repair, potentially saving significant costs on labor and misdiagnoses.
Powertrain:
Engine, Fuel System, Cooling System, Lubrication System, Emission Control System, Intake/Exhaust Systems, Automatic Transmission, Transfer Case, Drive Shafts, Differentials, Axles
Chassis:
Suspension System, Steering System, Power Steering, Brakes (Hydraulic and Parking), Wheels and Tires
Electrical And Electronics:
Ignition System, Starting and Charging System, Lighting, Instrument Panel, Body Control Modules, Multiplex/CAN Communication, Audio/Visual Systems, Horn, Wiper/Washer System, Door Locks, Cruise Control, Engine Immobilizer, Supplemental Restraint System (Airbags, Seatbelts)
Body And Interior:
Exterior Body Panels, Interior Trim, Seats, Engine Hood, Doors, Glass and Mirrors, Instrument Panel Assembly
Maintenance Procedures:
Scheduled Maintenance, Fluid Changes, Filter Replacements, Inspections
Diagnostic Procedures:
Troubleshooting Guides, Diagnostic Trouble Codes (DTCs), Symptom-Based Diagnostics, Component Testing
Repair Procedures:
Step-by-Step Repair Instructions, Component Removal and Installation, Reassembly, Adjustments
Technical Data And Specifications:
Torque Specifications, Clearances, Fluid Capacities, Electrical Specifications, Performance Data
Depth Of Coverage:
Factory-Level Detail, Technician-Grade Information, Comprehensive Rebuild Procedures, Advanced Diagnostics
Diagrams And Illustrations:
Detailed Exploded Views, Component Diagrams, Routing Diagrams, Wiring Schematics
Printability:
Fully Printable (individual pages or sections)
Image Scalability:
High-resolution images, zoomable for detailed viewing and printing
Binding Type:
N/A (Digital Format)
Paper Type:
N/A (Digital Format)
PDF Reader:
Adobe PDF Reader (Free)
Unzipping Software:
Winzip or equivalent (Free options available)
Operating Systems:
Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac Compatible
Engine Code Family:
GM Lambda II (LF3)
Engine Configuration:
3.6L V6 DOHC VVT DI (Direct Injection)
Horsepower Est:
308 hp @ 6800 rpm (typical for this engine)
Torque Est:
265 lb-ft @ 2400 rpm (typical for this engine)
Fuel Delivery:
Direct Injection (DI)
Fuel Type:
Premium Unleaded Gasoline Recommended
Engine Oil Type:
SAE 0W-30 Full Synthetic (GM dexos1™ Gen 2 or equivalent)
Engine Oil Capacity Qts:
6.0 quarts (with filter change)
Coolant Type:
GM Super Coolant (Orange, P/N 12346180 or equivalent)
Transmission Type:
6-Speed Automatic
Transmission Model Code Est:
GM 6T70 / 6T75 family
Drive Type:
Front-Wheel Drive (FWD) and All-Wheel Drive (AWD) available
Transmission Features:
Driver Shift Control, Tap-Up/Tap-Down manual mode
Transmission Fluid Type:
Dexron-VI Automatic Transmission Fluid (ATF)
Transmission Fluid Capacity Qts:
Approx. 8.0 quarts (dry fill)
NHTSA Overall Rating:
5-Star (for models tested)
IIHS Top Safety Pick:
Likely recipient of 'Top Safety Pick' or similar designations for the model year.
Active Safety Systems:
Anti-lock Braking System (ABS), Traction Control System (TCS), Electronic Stability Control (ESC), Available Driver Assist Systems (e.g., Forward Collision Alert, Lane Departure Warning, Adaptive Cruise Control)
Passive Safety Features:
Driver and front passenger airbags, Front and rear side-curtain airbags, Front seat-mounted side airbags, Seatbelt pretensioners
Infotainment System:
Cadillac CUE (Cadillac User Experience) with touchscreen interface.
Connectivity Features:
Bluetooth connectivity for audio streaming and hands-free calling, USB ports, Available Navigation System, Available Bose® premium audio system.
Driver Assistance Features:
Rear Vision Camera, Rear Park Assist, Available Driver Awareness Package (includes Forward Collision Alert, Lane Departure Warning), Available Driver Assist Package (includes Adaptive Cruise Control, Automatic Collision Preparation).
Multiplex Communication:
Extensive use of Controller Area Network (CAN) bus for communication between various control modules. Manual provides detailed wiring schematics.
Oil Change Interval:
Every 7,500 miles or 12 months, whichever comes first, with synthetic oil. (Refer to manual for specific conditions)
Tire Rotation Interval:
Every 7,500 miles
Cabin Air Filter Replacement:
Every 20,000-30,000 miles or as needed.
Spark Plug Replacement:
Platinum or Iridium plugs typically last 100,000 miles, but refer to manual for specific recommendation.
Brake Fluid Type:
DOT 3 or DOT 4 (check reservoir cap)
Power Steering Fluid Type:
GM Power Steering Fluid (P/N 89021184 or equivalent)
Common Complaints:
Potential for transmission issues (e.g., harsh shifting, delayed engagement), fuel system component failures (e.g., fuel pump, injectors), electrical glitches (e.g., infotainment system), suspension component wear (e.g., control arm bushings).
Diagnostic Challenges:
Complex electronic systems and CAN bus communication can make diagnosis challenging without specialized tools and knowledge, which this manual provides.
Cadillac Heritage:
American luxury automotive brand with a long history of innovation and premium vehicles.
Srx Generations:
First Generation (2004–2009), Second Generation (2010–2016). The 2016 model represents the final year of the second generation.
Second Gen Updates:
The second generation saw significant updates, including a move to a transverse-mounted engine and platform (shared with Chevrolet Equinox/GMC Terrain) and a focus on improved fuel efficiency and a more car-like driving experience compared to the first generation.
Production Location:
Likely assembled at GM's Lansing Delta Assembly Plant in Lansing, Michigan.
Awards History Mention:
While specific awards for the 2016 SRX may vary, Cadillac models often receive recognition for luxury appointments, comfortable ride, and quiet interiors.
Consumer Ratings Mention:
Owners often praise the SRX's comfortable ride, quiet cabin, and upscale interior, though some may note the powertrain's less sporty feel compared to German rivals.
