🏷️ Basic Information

Make:

Cadillac

Model:

XLR

Year:

2006

Generation:

1st Generation

Platform:

Y-Body

Body Style:

Roadster/Convertible

👋 Introduction

Positioning:

Premium Luxury Sports Roadster

Competitors:

Porsche 911, Mercedes-Benz SL-Class, BMW Z4 M, Jaguar XK

Vehicle Features:

Retractable Hardtop, Rear-Wheel Drive, Advanced Suspension, Luxurious Interior

Value Proposition:

Empowers owners and technicians with dealership-level diagnostic and repair capabilities, saving time and money.

Digital Format Benefit:

Easy to use PDF, printable pages, zoomable images, no greasy pages, readily available.

📋 Manual Details

Coverage:

All Models & All Repairs A-Z

Page Count:

Not Specified

Manual Type:

Service and Repair Manual

Language:

English

Format:

PDF

File Size:

Not Specified (typically large due to detailed diagrams and schematics)

📖 Manual Coverage

Systems:

Engine, Control System, Mechanical, Fuel Service Specifications, Emission Control, Intake Exhaust Cooling, Lube, Ignition Starting Charging, Auto Transmission Clutch, Manual Transmission, Transfer Propeller Shaft, Drive Shaft, Differential, Axle Suspension, Tire & Wheel, Brake Control, Brake, Parking Brake, Steering Column, Power Steering, Air Condition, Suppl Restraint System, Seat Belt, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Lock, Meter Audio/Visual, Horn, Windshield/Glass Mirror, Instrument Panel, Seat, Engine Hood/ Door, Exterior & Interior, Electrical, Multiplex/ Can Communication

Procedures:

Maintenance, Diagnosis, Repair, Troubleshooting, Rebuild, Installation, Adjustment

Body And Trim Procedures:

Includes repair and adjustment procedures for convertible top, doors, hood, and interior trim components.

Depth:

Vehicle Specific, Factory High Detail, Step-by-step Instructions, Diagrams, Illustrations, Wiring Schematics, Specifications

Schematics Detail:

Comprehensive electrical system wiring diagrams for all major circuits.

Diagnostic Tools:

Procedures often require GM's Tech 2 scan tool or equivalent for advanced diagnostics.

📊 Manual Specifications

File Type:

PDF

Printability:

All Pages Printable, Enlarged Copies Available

Binding:

Digital (No Physical Binding)

Paper Type:

N/A (Digital Format)

Operating Systems:

Windows Vista (32 & 64-bit), XP, ME, 98, NT, 2000, Mac

Required Software:

Adobe PDF Reader, Winzip

⚙️ Engine Specifications

Engine Code:

LH2

Engine Type:

4.6L V8

Horsepower:

320 hp @ 6400 rpm

Torque:

310 lb-ft @ 4400 rpm

Fuel Delivery:

Sequential Port Fuel Injection

ECU:

Engine Control Module (ECM)

Emissions Control:

Catalytic Converters, Oxygen Sensors, EGR (Exhaust Gas Recirculation) as applicable for the model year.

Coolant Type:

Dex-Cool (Orange) Long-Life Coolant

Oil Type:

SAE 5W-30 Synthetic

Timing System:

Dual Overhead Camshafts (DOHC), Variable Valve Timing (VVT)

🔧 Transmission

Transmission Type:

6-Speed Automatic (6L50)

Optional Transmission:

N/A (Standard for 2006 XLR)

Transmission Features:

Driver Shift Control, Active Fuel Management (AFM) integration

Transmission Fluid:

Dexron VI Automatic Transmission Fluid

Transmission Gear Ratios:

Specific gear ratios for 6L50 are detailed within the manual for performance tuning and diagnostics.

📐 Dimensions

Length:

177.1 inches (4498 mm)

Width:

72.1 inches (1831 mm)

Height:

50.1 inches (1273 mm)

Wheelbase:

105.1 inches (2670 mm)

Front Track:

61.5 inches (1562 mm)

Rear Track:

62.2 inches (1580 mm)

Curb Weight:

Approximately 3630 lbs (1647 kg)

Trunk Volume:

11.9 cu ft (337 L) with roof up, reduced significantly with roof down

🛡️ Safety Features

NHTSA Front Impact:

5-Star

NHTSA Side Impact:

5-Star

Active Safety Systems:

StabiliTrak Electronic Stability Control, ABS, Traction Control, Tire Pressure Monitoring System (TPMS)

Passive Safety Features:

Front and Side Impact Airbags, Magnetic Ride Control (often considered a safety enhancement)

Seat Belts:

3-point front seat belts with pretensioners and load limiters

💡 Technology Features

Infotainment System:

Bose Premium Audio System, DVD Navigation System, Bluetooth Connectivity

Screen Size:

7-inch touch screen for infotainment and navigation.

Adaptive Cruise Control:

Available (Adaptive Cruise Control)

Connectivity Features:

OnStar communications system (subscription based)

Comfort Technology:

Heated and Ventilated Seats, Keyless Access with Push-Button Start, Head-Up Display (HUD)

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles or 12 months, whichever comes first (using synthetic oil).

Transmission Fluid Change:

Inspect every 15,000 miles, change as per service bulletin or under severe usage conditions.

Coolant Flush:

Every 5 years or 100,000 miles (initial fill) then as per service schedule.

Brake Fluid:

DOT 3 or DOT 4

Power Steering Fluid:

GM Power Steering Fluid (Dexron III/VI compatible)

Common Problems:

Retractable hardtop mechanism issues (actuator failures, hydraulic leaks), suspension component wear, potential electrical gremlins.

Common Maintenance Tasks:

Routine checks of convertible top hydraulic fluid, inspection of magnetic ride control sensors and actuators.

Oil Filter:

ACDelco PF48 (example, verify with specific VIN)

Air Filter:

ACDelco A3132C (example, verify with specific VIN)

📚 Vehicle History

Cadillac Legacy:

Long history of luxury, performance, and technological innovation in American automotive industry.

Xlr Origin:

Developed as Cadillac's flagship personal luxury sports car, built on the Corvette (C6) platform.

Xlr Variants:

XLR and XLR-V (supercharged V8 model, not covered by this specific manual).

Production Start Year:

2003 (for 2004 model year)

Production End Year:

2009

Manufacturing Location:

Bowling Green, Kentucky, USA

🏆 Awards & Recognition

Design Awards:

Often praised for its distinctive styling and luxurious appointments.

Consumer Reports Reliability:

Varied; early models may have had some reliability concerns reported in consumer surveys.
