Canon ImageClass MF6500 6530 6540 6550 6580 Service & Repair Manual + Parts Catalog

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Canon Model: ImageClass MF6500 Series Model Variant: MF6530, MF6540, MF6550, MF6580 Product Type: Service & Repair Manual + Parts Catalog Product Format: PDF Download 📋...

17 people are viewing this right now

类型: Office Machine

斯库: 25373

标签: Canon MF6500 MF6530 MF6540 MF6550 MF6580 Office Machine

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Canon

Model:

ImageClass MF6500 Series

Model Variant:

MF6530, MF6540, MF6550, MF6580

Product Type:

Service & Repair Manual + Parts Catalog

Product Format:

PDF Download

📋 Manual Details

Documentation

Manual Type:

Service and Repair Manual

Included Content:

Disassembly, Part Replacement, Maintenance

Language:

English (Assumed, based on typical manuals)

Page Count:

Not Specified (PDF download, size varies)

Access Method:

Digital Download

⚙️ Engine Specifications

Printer Engine

Engine Type:

Laser Printer Engine

Printing Technology:

Monochrome Laser Printing

Resolution Dpi:

Up to 1200 x 600 dpi

Print Speed Ppm:

Varies by model (e.g., MF6530: 20 ppm, MF6580: 25 ppm)

Warm Up Time:

Approx. 13.5 seconds or less

First Print Out Time:

Approx. 8 seconds or less

🔧 Transmission

Paper Handling

Paper Input Capacity Standard:

250 sheets

Paper Input Capacity Optional:

Optional Tray: 250 sheets

Paper Output Capacity:

100 sheets

Paper Sizes Supported:

A4, B5, Letter, Legal, Executive, Custom sizes

📐 Dimensions

Physical Attributes

Width Mm:

Approx. 470mm

Depth Mm:

Approx. 440mm

Height Mm:

Approx. 400mm

Weight Kg:

Approx. 23 kg (without toner)

🔧 Maintenance

Consumables

Toner Cartridge Yield:

Varies (e.g., 2,500 pages for standard, 5,000 pages for high-yield)

Drum Unit Yield:

Varies (e.g., 15,000 pages)

Cleaning Procedures

Cleaning Frequency Recommendation:

As per manual instructions (e.g., based on print volume or issues)

Troubleshooting

Common Issues Covered:

Paper jams, print quality issues, error codes, hardware malfunctions

Part Replacement

Key Replaceable Parts:

Toner cartridge, drum unit, fuser unit, pickup rollers, transfer belt

📄 Connectivity

Interface

Standard Interface:

USB 2.0
