Chery J11 Chery Tiggo Chery Ruihu Complete Workshop Service Repair Manual 2008 2009 2010 2011 2012 2013 2014

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

🏷️ Basic Information Identification Make: Chery Model: J11 / Tiggo / Ruihu Model Designation: Chery J11 (export markets), Chery Tiggo (original name/some markets), Chery Ruihu (original name/some markets) Generation Generation...

20 people are viewing this right now

类型: Car

斯库: 205048

标签: 2008 2009 2010 2011 2012 2013 2014 A Models Car Cars Chery Featured J11 Ruihu Tiggo

产品多属性

Description

🏷️ Basic Information

Identification

Make:

Chery

Model:

J11 / Tiggo / Ruihu

Model Designation:

Chery J11 (export markets), Chery Tiggo (original name/some markets), Chery Ruihu (original name/some markets)

Generation

Generation Years:

First Generation (T11)

👋 Introduction

Market Position

Vehicle Segment:

Compact Crossover SUV (SUV-B segment)

Competitive Analysis

Key Competitors Era:

Suzuki Vitara, Honda CR-V, Toyota RAV4, Nissan Qashqai (in its respective markets)

Key Features

Value Proposition:

Affordable entry into the compact SUV segment, offering a balance of utility and passenger comfort.

Design Inspiration:

Often noted for styling cues reminiscent of contemporary European or Japanese SUVs of its time.

📋 Manual Details

Coverage Areas

Model Years Covered:

2008, 2009, 2010, 2011, 2012, 2013, 2014

Engine Variants Covered:

All engine variants are covered (specific engines detailed below)

Trim Levels Covered:

All trim levels are covered

Transmission Types Covered:

All transmission types are covered (manual and automatic)

Page Count

Estimated Page Count:

Extensive; typically 1000+ pages for a complete workshop manual

Manual Type

Type:

Complete Workshop Service Repair Manual

Language

Language:

English (assumed based on product description)

Format

Format:

Digital Downloadable (PDF)

📖 Manual Coverage

Systems Covered

Engine Mechanical:

Engine overhaul, cylinder head, block, pistons, crankshaft, camshaft, timing, lubrication, cooling system

Engine Electrical:

Ignition system, starting system, charging system, ECU, sensors, wiring diagrams

Fuel System:

Fuel injection, fuel pump, fuel filter, fuel lines, evaporative emission control (EVAP)

Transmission Manual:

Clutch, gearbox overhaul, gear shift mechanism, drivelines

Transmission Automatic:

Automatic transmission overhaul, valve body, torque converter, electronic controls, fluid management

Drivetrain:

Front axle, rear axle, differential, driveshafts, CV joints

Suspension:

Front suspension (McPherson struts, control arms), rear suspension (multi-link, independent), shock absorbers, springs

Steering:

Power steering system (hydraulic/electric), steering column, tie rods, steering rack

Brakes:

Brake system components, hydraulic system, ABS, EBD, disc brakes, drum brakes, parking brake

Body Exterior:

Body panel removal/installation, doors, hood, trunk lid, bumpers, glass replacement, sunroof

Body Interior:

Dashboard, trim panels, seats, upholstery, headliner, HVAC controls

Electrical Body:

Lighting system (headlights, taillights, interior), power windows, power locks, mirrors, wipers, horn

HVAC:

Air conditioning system, heater core, blower motor, ventilation, refrigerant handling

Safety Systems:

Airbag system, seat belt pre-tensioners, SRS components

Diagnostic Troubleshooting:

Diagnostic trouble codes (DTCs), symptom-based troubleshooting guides

Procedures Included

Maintenance:

Scheduled maintenance, oil changes, filter replacements, fluid checks and changes, spark plug replacement, belt inspection and replacement

Repair:

Detailed step-by-step repair procedures for all covered systems

Overhaul:

Complete engine and transmission overhaul procedures

Installation:

Installation procedures for major components (e.g., engine, transmission, suspension parts)

Adjustment:

Adjustment procedures for brakes, clutch, parking brake, wheel alignment

Troubleshooting:

Systematic troubleshooting guides for common and uncommon problems

Specifications:

Torque specifications, clearances, fluid capacities, electrical specifications

Wiring Diagrams:

Comprehensive electrical wiring diagrams for all systems

Technical Depth

Depth:

Comprehensive: from basic maintenance to complete engine and transmission rebuilds, including advanced diagnostics and component replacement

📊 Manual Specifications

File Format

Format:

Searchability:

Searchable text (typical for professional PDF manuals)

Print Quality

Quality:

High quality, suitable for printing individual pages or chapters

Binding Type

Type:

N/A (Digital Download)

Paper Type

Type:

N/A (Digital Download)

⚙️ Engine Specifications

Primary Engine

Engine Code:

Likely SQRD4G20 (2.0L DOHC)

Engine Type:

Inline 4-cylinder, DOHC, 16-valve

Displacement:

1997 cc (2.0 Liters)

Performance

Horsepower Approx:

115 - 130 PS (approx. 113-128 hp) at 5,500 rpm (depending on market and specific engine tune)

Torque Approx:

170 - 180 Nm (approx. 125-133 lb-ft) at 4,000-4,500 rpm (depending on market and specific engine tune)

Fuel System

Fuel Delivery:

Multi-point fuel injection (MPI)

Fuel Type:

Unleaded Gasoline (Petrol)

Other

Emission Control:

Euro III/IV compliant (market dependent)

🔧 Transmission

Standard

Type:

5-speed Manual Transmission

Optional

Type:

4-speed Automatic Transmission

Features

Drive Type:

Front-Wheel Drive (FWD) standard, All-Wheel Drive (AWD) optional on some models.

📐 Dimensions

Exterior

Length:

Approx. 4,390 mm (172.8 inches)

Width:

Approx. 1,795 mm (70.7 inches)

Height:

Approx. 1,675 mm (66.0 inches)

Wheelbase:

Approx. 2,610 mm (102.8 inches)

Weights

Curb Weight Approx:

1,400 - 1,500 kg (3,086 - 3,307 lbs) depending on configuration.

Cargo

Cargo Volume Approx:

Highly variable, but typically around 350-450 liters with rear seats up.

🛡️ Safety Features

Ratings

Crash Test Data:

Limited official global crash test data available. C-NCAP ratings vary by specific test year and configuration.

Active Features

Anti-lock Braking System (ABS) typically standard on most models.

Electronic Brake-force Distribution (EBD) usually paired with ABS.

Traction Control:

Traction Control System (TCS) may be available on higher trims or later models.

Passive Features

Airbags:

Front airbags for driver and passenger. Side airbags and curtain airbags may be optional or standard on specific trims.

Seat Belts:

Three-point seat belts with pre-tensioners for front occupants. Three-point or two-point for rear occupants.

💡 Technology Features

Infotainment

Audio System:

Factory fitted CD/MP3 player with AM/FM radio, often with AUX input. Higher trims might have a more integrated system.

Connectivity:

Limited connectivity options by modern standards; usually basic USB or AUX ports.

Driver Assistance

Parking Sensors:

Rear parking sensors may be available on higher trim levels or as an aftermarket addition.

Comfort Features

Climate Control:

Manual air conditioning with manual fan speed and temperature control. Automatic climate control is rare.

Convenience Features:

Power windows (all or front only), power mirrors, remote central locking, cruise control (on some higher trims).

🔧 Maintenance

Service Intervals

Oil Change Interval:

Typically every 5,000 - 10,000 km (3,000 - 6,000 miles) or 6-12 months, whichever comes first. Consult manual for specific interval.

Air Filter Replacement:

Every 20,000 - 30,000 km (12,000 - 18,000 miles) or as needed based on driving conditions.

Spark Plug Replacement:

Typically around 40,000 - 60,000 km (25,000 - 37,000 miles) for standard plugs; longer for iridium/platinum.

Transmission Fluid Change:

Manual: Check for leaks; typically no scheduled change unless indicated. Automatic: Every 40,000 - 80,000 km (25,000 - 50,000 miles) or as per manual. Use specified ATF.

Fluid Specifications

Engine Oil Type:

API SG/SH/SJ/SL or higher, SAE 5W-30 or 5W-40 (consult manual for exact grade and capacity).

Coolant Type:

Ethylene glycol-based antifreeze, typically a green or orange color. Check manual for specific type and mixture ratio.

Brake Fluid Type:

DOT 3 or DOT 4 brake fluid.

Power Steering Fluid:

ATF Dexron III or compatible fluid, unless specified otherwise.

Known Issues

Common Wear Items:

Suspension components (bushings, ball joints), wheel bearings, clutch wear (manual transmission).

Electrical Quirks:

Occasional issues with power window regulators, door lock actuators, and sensors (e.g., O2 sensors, crank position sensors) may be reported.

Engine Performance:

Some owners report rough idling or minor performance issues potentially related to fuel system cleanliness or ignition system components.

📚 Vehicle History

Brand Heritage

Brand Origin:

Chery Automobile Co., Ltd. is a Chinese state-owned automobile manufacturer headquartered in Wuhu, Anhui province.

Model Evolution

First Generation Launch:

The first generation (T11) was launched in China in 2005 as the Chery Tiggo.

Global Markets:

It was later rebadged and sold in various international markets, including Australia (as Chery J11), South America, Eastern Europe, and parts of Asia.

Production

Manufacturing Locations:

Primarily manufactured in China, with potential assembly in other international markets through joint ventures or CKD kits.

🏆 Awards & Recognition

Recognitions

Safety Ratings:

As mentioned, specific global awards are scarce, but it aimed to meet safety standards for its target markets. C-NCAP ratings provide an indication.

Ratings

Reliability Perception:

Perception varies widely. While offering value, long-term reliability may not match established Japanese or European brands, often depending on build quality and adherence to maintenance schedules.
