Chevrolet Chevy Corvette 1997-2004 Service Repair Workshop Manual Download PDF

常规价格: $16.99
促销价: $16.99
常规价格
单价: 单价

Basic Information Identification Make: Chevrolet Model: Corvette Generation: C5 Product Name: Chevrolet Chevy Corvette 1997-2004 Service Repair Workshop Manual Download PDF Introduction Market Position Positioning: The Chevrolet Corvette (C5 generation)...

18 people are viewing this right now

类型: Car

斯库: 83499

标签: 1997 1998 1999 2000 2001 2002 2003 2004 Car Cars Chevrolet Chevy Corvette Corvette Featured

产品多属性

Description

Basic Information
Identification
Make:	Chevrolet
Model:	Corvette
Generation:	C5
Product Name:	Chevrolet Chevy Corvette 1997-2004 Service Repair Workshop Manual Download PDF

Introduction
Market Position
Positioning:	The Chevrolet Corvette (C5 generation) was positioned as a premier American sports car, offering high performance and advanced technology for its era, directly competing with European sports car manufacturers.
Competitive Analysis
Competitors:	Porsche 911, BMW Z3/Z4 M Coupe, Mercedes-Benz SLK, Dodge Viper.
Key Features
Vehicle Highlights:	Rear-wheel drive, front-engine V8, lightweight composite body panels, advanced suspension, powerful engine options, distinct styling.
Manual Value Proposition
Value For Owner:	Provides owners with the capability to perform a wide range of maintenance and repair tasks, reducing reliance on dealership service and potentially saving significant costs.

Manual Details
Coverage Areas
Vehicle Years:	1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004
Engine Coverage:	All gasoline engine variants for the specified years (primarily LS1 and LS6)
Trim Level Coverage:	All trim levels (e.g., Coupe, Convertible, Hardtop, Z06)
Page Count
Estimated Pages:	Hundreds (specific count not provided, but described as extensive)
Manual Type
Type:	Factory Service Repair Workshop Manual
Language
Language:	English
Format
Format:	Downloadable PDF

Manual Coverage
Systems Covered
Powertrain:	Engine, Fuel System, Exhaust System, Cooling System, Lubrication System, Transmission (Manual & Automatic)
Chassis:	Suspension (Front & Rear), Steering, Brakes (ABS, Traction Control), Wheels & Tires
Electrical:	Body Control Module (BCM), Powertrain Control Module (PCM), Lighting, Instruments, Audio System, HVAC Controls, SRS (Airbag) System, Security System
Body And Frame:	Exterior Body Panels, Interior Trim, Seats, Doors, Windows, Roof System (Convertible Top)
Procedures Included
Maintenance:	Scheduled Maintenance (oil changes, filter replacements, fluid checks), Tune-ups, Inspections
Repair:	Component Replacement (engine components, transmission, suspension parts, brake assemblies, electrical modules), Body Panel Repair, Interior Component Repair
Troubleshooting:	Diagnostic Trouble Codes (DTCs), Symptom-based Troubleshooting Guides, Electrical Circuit Diagnosis
Technical Depth
Depth:	Comprehensive (from basic fluid checks to complete engine and transmission overhauls, including electrical system diagnostics and component replacement)

Manual Specifications
File Format
File Type:	PDF
Searchability:	Likely searchable text-based PDF, allowing for quick information retrieval.
Compatibility:	Fully compatible with Windows and MAC computers.
Print Quality
Printability:	Printable (single pages or entire manual)
Binding Type
Digital Binding:	N/A (Digital Download)
Paper Type
Digital Paper Type:	N/A (Digital Download)
Access
Usage License:	Lifetime use, no expiry, multiple device usage.

Engine Specifications
Primary Engine
Engine Code:	LS1
Engine Type:	5.7L (350 ci) V8, Overhead Valve (OHV), 16-valve, Aluminum Block & Heads
Horsepower Ls1:	345-350 hp @ 5600 rpm (varies slightly by year)
Torque Ls1:	350-375 lb-ft @ 4400 rpm (varies slightly by year)
Performance
Z06 Engine:	LS6 5.7L (350 ci) V8
Z06 Horsepower:	405 hp @ 6000 rpm
Z06 Torque:	400 lb-ft @ 4800 rpm
Fuel System
Injection Type:	Sequential Fuel Injection (SFI)
Fuel Type:	Unleaded Premium Gasoline (91 octane or higher recommended)
Cooling System
Coolant Capacity:	Approx. 10.5 quarts (9.9 liters) with 50/50 mix of Dex-Cool and distilled water

Transmission
Standard
Transmission Type:	6-speed Manual (Tremec T-56)
Optional
Transmission Type:	4-speed Automatic (4L60-E)
Features
Manual Features:	Close-ratio gearing, hydraulic clutch actuation
Automatic Features:	Electronically controlled, performance shift modes
Fluid Specifications
Manual Transmission Fluid:	Dexron III/Mercon ATF (for Tremec T-56), or specific manual transmission fluid as per GM spec
Automatic Transmission Fluid:	Dexron III/Mercon ATF

Dimensions
Exterior
Length:	179.7 inches (4564 mm)
Width:	73.6 inches (1870 mm)
Height:	47.8 inches (1214 mm)
Wheelbase:	104.5 inches (2654 mm)
Weights
Curb Weight Coupe:	Approx. 3,216 lbs (1,459 kg)
Curb Weight Convertible:	Approx. 3,334 lbs (1,512 kg)
Cargo
Cargo Volume:	Approx. 13.9 cubic feet (Coupe), 13.0 cubic feet (Convertible)

Safety Features
Ratings
NHTSA Front Impact:	5-Star (Driver), 4-Star (Passenger) for 1997-2004 models.
Active Features
Active Safety:	Anti-lock Braking System (ABS), Traction Control System (TCS), Active Handling (optional/standard on later/Z06 models), Daytime Running Lights (DRLs)
Passive Features
Passive Safety:	Driver and Passenger Frontal Airbags, Side-Impact Protection (door beams), Crumple Zones, Reinforced Passenger Compartment

Technology Features
Infotainment
Audio System:	AM/FM Stereo with CD Player (Bose premium audio optional), optional Navigation System on later models.
Driver Assistance
Traction Control:	Standard on all models, integrated with ABS and Active Handling.
Active Handling:	Electronic stability control system that intervenes during extreme maneuvers to help maintain vehicle control.
Connectivity
Connectivity Features:	Limited for the era; primarily focused on the audio system and optional navigation. No Bluetooth or USB connectivity typical of modern vehicles.

Maintenance
Service Intervals
Oil Change Interval:	Every 7,500 miles or 12 months (whichever comes first), or as indicated by the Oil Life Monitoring System.
Tire Rotation:	Every 7,500 miles
Coolant Flush:	Every 100,000 miles or 5 years for initial service, then every 50,000 miles or 5 years thereafter.
Fluid Specifications
Engine Oil:	SAE 5W-30 Synthetic (API Certified SM or higher)
Brake Fluid:	DOT 3
Power Steering Fluid:	GM Power Steering Fluid (or equivalent Dexron III/Mercon ATF)
Known Issues
Common Issues:	Driver's side power window regulator failure, rear main seal leaks (LS1 engines), clutch master cylinder issues, harmonic balancer failure (LS1), coolant leaks from cross-over pipe, some electronic module failures.
Z06 Specific Issues:	Oil consumption on early LS6 engines, potential for valve spring issues on some performance variants.

Vehicle History
Brand Heritage
Heritage:	Chevrolet has a long and storied history with the Corvette nameplate, dating back to 1953, establishing it as America's Sports Car.
Model Evolution
C5 Introduction:	The C5 generation, introduced for the 1997 model year, represented a significant redesign with a new platform, powertrain, and chassis, improving performance, handling, and ergonomics.
Z06 Introduction:	The high-performance Z06 model was introduced for the 2001 model year, featuring the more powerful LS6 engine, stiffer suspension, and reduced weight for track-focused performance.
Production
Production Years:	1997-2004
Manufacturing Location:	Bowling Green, Kentucky, USA

Awards & Recognition
Recognitions
Performance Awards:	Consistently praised by automotive publications for its performance, handling, and value compared to European rivals. Featured on Car and Driver's '10Best' list multiple times.
Design Awards:	Praised for its cohesive and modern styling, a significant departure from previous Corvette generations.
