Chevrolet CRUZE JG JH 2010-2016 Service Repair Manual

常规价格: $17.99
促销价: $17.99
常规价格
单价: 单价

Basic Information Identification Make: Chevrolet / Holden Model: Cruze Generation: J300 (JG/JH) Production Years: 2010-2016 Chassis Codes: JG (2008-2012, early models), JH (2013-2016, facelift) Market Relevance: USA (Chevrolet Cruze), Australia/New...

23 people are viewing this right now

类型: Car

斯库: 95609

标签: 2010 2011 2012 2013 2014 2015 2016 Car Cars Chevrolet CRUZE JG JH Featured LUV

产品多属性

Description

Basic Information
Identification
Make:	Chevrolet / Holden
Model:	Cruze
Generation:	J300 (JG/JH)
Production Years:	2010-2016
Chassis Codes:	JG (2008-2012, early models), JH (2013-2016, facelift)
Market Relevance:	USA (Chevrolet Cruze), Australia/New Zealand (Holden Cruze)
Drive Configuration:	Left-Hand Drive (LHD) USA version, applicable to Right-Hand Drive (RHD) Australian/New Zealand models with minor noted differences.

Introduction
Market Position
Positioning:	A comprehensive and authoritative resource for owners and professional technicians alike, bridging the gap between basic maintenance and in-depth repair for the Chevrolet/Holden Cruze.
Competitive Analysis
Value Proposition:	Offers factory-level repair information that can significantly reduce diagnostic time and repair costs, providing detailed procedures often unavailable in generic automotive guides.
Key Features
Manual Features:	Packed with illustrations, instructions, photos, and diagrams to facilitate understanding and execution of repair tasks. The extensive page count indicates a high level of detail.

Manual Details
Coverage Areas
Engine Variants Covered:	1.4L Turbocharged LUV (Inline-4 Petrol), 1.8L LWE (Inline-4 Petrol), 1.8L LUW (Inline-4 Petrol), 2.0L Turbocharged LNP (Inline-4 Diesel VCDi)
Transmission Variants Covered:	6-Speed M32 Manual, 6-Speed GM 6T30 Automatic, 6-Speed GM 6T40 Automatic
Page Count
Total Pages:	9140
Manual Type
Type:	Workshop Service and Repair Manual
Language
Language:	English
Format
Format:	PDF
Digital Features:	Printable pages, Copyable to hard drive, Searchable text (assumed for PDF format)
Compatibility
Operating Systems:	All Windows (XP, Vista, 7, 8, 10, ME, 98, NT, 2000), Mac, Tablets, Phones (32/64-bit compatible)

Manual Coverage
Systems Covered
Major Systems:	Engine Mechanical, Engine Cooling, Engine Electrical, Engine Exhaust, Engine Performance, Engine Controls, Fuel System, HVAC (Manual & Automatic), Lighting, Seat Belts, SRS, Steering, Power Steering, Steering Wheel & Column, Suspension, Tires & Wheels, Wheel Alignment, Brakes, ABS, Parking Brake, Driveline & Axles, Electrical System, Power Outlets, Automatic Transmission, Manual Transmission, Clutch, Shift Lock Control, Body & Frame, Exterior Panels, Collision Repair, Exterior Trim, Interior Trim, Instrument Panel, Console, Seats, Paint & Coatings, Sunroof, Wipers & Washers, Wiring Systems, Power Management, Data Communications, Cruise Control, Immobilizer, Object Detection, Cellular, Entertainment, Navigation.
Procedures Included
Repair Procedures:	Detailed instructions and step-by-step diagrams for all workshop procedures, including diagnostics, troubleshooting, repair, overhaul, and replacement of components.
Technical Depth
Depth:	Comprehensive workshop-level technical information, covering everything from basic maintenance to complex diagnostics and major component overhauls. Includes DTC index.
Diagnostic Information
Diagnostic Tools:	Includes vehicle diagnostic information, vibration diagnosis and correction, and DTC index (Trouble Codes), enabling technicians to identify and resolve issues effectively.
Special Tools
Special Tools And Equipment:	Covers special tools and equipment required for specific repair and maintenance procedures.
Wiring Diagrams
Electrical Schematics:	Extensive wiring diagrams are included for diagnosing and repairing electrical systems.

Manual Specifications
File Format
Format:	PDF
Print Quality
Quality:	High-quality scans/digital rendering of original factory manual, optimized for clarity of illustrations, diagrams, and text.
Binding Type
Binding:	Digital (PDF) - No physical binding
Paper Type
Paper Type:	N/A (Digital Format)
Usability
Accessibility:	Designed for ease of use on various devices, allowing for quick access to information.

Engine Specifications
Primary Engine 1 4L Turbo
Engine Code:	LUV
Configuration:	1.4L 4-Cylinder Inline, DOHC, Turbocharged, VVT
Fuel System:	Multi-Point Fuel Injection (MFI)
Primary Engine 1 8L
Engine Codes:	LWE, LUW
Configuration:	1.8L 4-Cylinder Inline, DOHC, VVT
Fuel System:	Multi-Point Fuel Injection (MFI)
Primary Engine 2 0L Diesel
Engine Code:	LNP
Configuration:	2.0L (1998 cc) 4-Cylinder In-line, Turbocharged & Intercooled, DOHC, VCDi
Fuel System:	Common Rail Diesel Injection (CRDi) / VCDi

Transmission
Standard Transmission
Type:	6-Speed Manual Transmission
Model Code:	M32
Optional Transmission 1
Type:	6-Speed Automatic Transmission
Model Code:	GM 6T30
Optional Transmission 2
Type:	6-Speed Automatic Transmission
Model Code:	GM 6T40
Features
Transmission Coverage:	Detailed procedures for repair, maintenance, and diagnosis of all covered manual and automatic transmissions, including shift lock control.

Dimensions
Exterior
Body Styles:	Sedan, Hatchback (depending on market and specific model year)
Weights
Curb Weight Range:	Approx. 1350 - 1500 kg (Varies significantly by engine and transmission)
Gross Vehicle Weight Rating:	Refer to specific vehicle plate (typically around 1900-2000 kg)

Safety Features
Ratings
NHTSA Ratings Usa:	5-star overall safety rating from NHTSA for certain model years (refer to specific year reports for details).
Ancap Ratings Aus:	5-star ANCAP safety rating for Australian models (refer to specific year reports for details).
Active Features
Braking Systems:	Antilock Brake System (ABS), Electronic Brake-force Distribution (EBD), Brake Assist (BA).
Stability Control:	Electronic Stability Control (ESC) / Traction Control System (TCS) often standard or available.
Passive Features
Airbags:	Front, side, and curtain airbags are typically standard or optional depending on trim level and market.
Seat Belts:	Pretensioner equipped seat belts, active head restraints (on some models).
Child Anchors:	ISOFIX/LATCH child seat anchor points.

Technology Features
Infotainment
Infotainment Systems:	Covers various infotainment and navigation systems, including features for cellular connectivity and entertainment.
Driver Assistance
Driver Assistance Features:	Details on cruise control systems, object detection systems (e.g., parking sensors, rearview cameras on later models), and related electronic modules.
Connectivity
Data Communications:	Covers the vehicle's data communication networks (e.g., CAN bus) and modules, essential for diagnostics and system integration.
Convenience
Customer Controls:	Information on secondary and configurable customer controls, remote functions, immobilizer systems, and theft deterrent systems.

Maintenance
Service Intervals
Oil Change Interval:	Typically every 15,000 km or 12 months, whichever comes first (refer to manual for specific engine/oil type). Diesel may have different intervals.
Other Intervals:	Spark plug replacement (e.g., 1.4T at ~160,000 km), cabin air filter, engine air filter, brake fluid flush, coolant replacement (e.g., Dex-Cool long-life).
Fluid Specifications
Engine Oil:	API SN, ACEA C3 or equivalent, viscosity typically 5W-30 or 0W-20 for petrol, 5W-30 low-SAPS for diesel. Refer to manual for exact specification (e.g., GM dexos2®).
Coolant:	GM specification OAT (Organic Additive Technology) coolant, typically Dex-Cool (ethylene glycol based, orange color).
Transmission Fluid Auto:	Dexron VI or equivalent for 6T30/6T40 transmissions.
Transmission Fluid Manual:	API GL-4 or GL-5 specification gear oil, viscosity typically 75W-90.
Known Issues
Common Wear Items:	Suspension components (bushings, struts), exhaust system components, brake pads and rotors, coolant leaks (especially from thermostat housing or hoses), potential turbocharger issues on 1.4T models, oil cooler leaks.
Common Electrical Issues:	Issues with body control modules, infotainment system glitches, sensor failures (e.g., ABS sensors).
Diesel Specific:	Potential issues with Diesel Particulate Filter (DPF) regeneration, glow plugs, and common rail injection system components on the 2.0L diesel.

Vehicle History
Brand Heritage
Chevrolet Lineage:	The Chevrolet Cruze is part of General Motors' global strategy to offer a consistent compact car model across various markets.
Model Evolution
J300 Generation:	The J300 platform Cruze was launched globally around 2008 and received a significant facelift (JH) for the 2013 model year, introducing updated styling, features, and powertrain options.
Production
Manufacturing Locations:	Globally produced, including major facilities in South Korea (Daewoo origins), USA, and Australia.

Awards & Recognition
Recognitions
Safety Awards:	Awarded top safety picks by organizations like IIHS (USA) and ANCAP (Australia) for specific model years, reflecting strong performance in crash testing.
Ratings
Consumer Reports:	Consumer Reports ratings vary by year, with some model years indicating average or below-average predicted reliability. This manual is crucial for addressing potential issues.
Certifications
Oem Certification:	This manual is a reproduction of the original OEM service information, essential for maintaining warranty compliance and ensuring manufacturer-specified procedures are followed.
