🏷️ Basic Information

Make:

Chevrolet

Model:

Impala

Year:

2016

Generation:

Tenth Generation (2014-2020)

Platform:

GM Epsilon II

👋 Introduction

Segment:

Full-size Sedan

Key Competitors:

Toyota Avalon, Nissan Maxima, Ford Taurus, Dodge Charger

Value Proposition:

Offers a blend of comfort, style, and modern technology at a competitive price point within its segment.

Manual Advantage:

Provides the same level of detail and accuracy as dealership technician manuals, enabling DIY repairs and informed maintenance decisions.

Ease Of Use:

All pages printable, allowing users to print only necessary sections. Zoomable images and diagrams for clarity.

📋 Manual Details

Coverage:

All Models & All Repairs A-Z

Estimated Page Count:

Extensive (typical for factory service manuals covering all models and systems)

Type:

Service and Repair Manual

Language:

English

Format:

PDF

📖 Manual Coverage

Powertrain:

Engine Mechanical, Fuel System, Cooling System, Lube System, Ignition System, Starting & Charging System, Exhaust System, Engine Control System, Automatic Transmission, Manual Transmission (if applicable to specific trims), Drivetrain (Drive Shaft, Differential, Axles)

Chassis:

Suspension System, Steering System (including Power Steering), Brake System (including ABS and Parking Brake), Wheel & Tire Specifications

Body And Interior:

Exterior Body Panels, Interior Trim, Doors, Seats, Glass & Mirrors, Climate Control (HVAC), Restraint Systems (Airbags, Seatbelts), Wiper & Washer System, Horn

Electrical And Electronics:

Complete Electrical Schematics, Wiring Diagrams, Multiplex/CAN Communication, Engine Immobilizer, Cruise Control, Meter/Audio/Visual Systems, Instrument Panel

Emission Control:

Emission control systems, evaporative emission control (EVAP), catalytic converter diagnostics, oxygen sensor systems.

Supplemental Restraint System:

Airbag system operation, diagnostics, component replacement, and safety precautions.

Steering:

Power steering system, steering column components, wheel alignment specifications.

Brake System:

Front and rear brake component replacement (pads, rotors, calipers), hydraulic system bleeding, parking brake service, ABS system diagnosis.

Suspension System:

Front and rear suspension components (struts, shocks, control arms, ball joints), chassis lubrication, wheel bearing service.

Maintenance:

Scheduled Maintenance, Fluid Checks and Changes, Filter Replacements, Tire Rotation

Diagnostics:

Troubleshooting Charts, Diagnostic Trouble Codes (DTCs) interpretation, System Testing Procedures

Repair:

Step-by-step repair instructions for all major vehicle components and systems, including engine rebuild, transmission overhaul, brake component replacement, suspension and steering repair, electrical system diagnostics and repair, body panel repair, HVAC system repair.

Installation:

Installation procedures for replacement parts and accessories.

Engine Management:

Engine performance diagnosis, fuel injection system service, ignition system timing and diagnosis, variable valve timing (VVT) system service.

Body And Trim:

Door panel removal and installation, seat adjustment and removal, interior trim piece replacement, exterior panel alignment and repair procedures.

Depth:

Factory-level diagnostics, repair, and maintenance. Includes detailed specifications, torque values, clearances, and troubleshooting trees.

Electrical Schematics Detail:

Comprehensive wiring diagrams for all electrical systems, including detailed harness routing, connector pinouts, and component locations.

Diagnostic Tools:

Information on using diagnostic scan tools (e.g., GM MDI) for retrieving data, performing actuations, and module programming.

📊 Manual Specifications

File Type:

PDF

Software Compatibility:

Compatible with Windows Vista 32/64, XP, ME, 98, NT, 2000, and Mac OS. Requires Adobe PDF Reader and Winzip (free).

Printability:

High-resolution, printable pages. Allows for zooming into diagrams and illustrations.

Binding:

Digital (No physical binding)

Paper Recommendation:

N/A (Digital Format)

⚙️ Engine Specifications

2.5L I4:

2.5L DOHC I4 (LUK), EPA estimated 197 hp @ 6300 rpm, 191 lb-ft torque @ 4400 rpm

3.6L V6:

3.6L DOHC V6 (LFX), EPA estimated 305 hp @ 6800 rpm, 264 lb-ft torque @ 5200 rpm

Acceleration 0 60 V6:

Approximately 6.0 - 6.5 seconds (V6 models)

Injection Type:

Direct Injection

Recommended Fuel:

Regular Unleaded Gasoline (87 octane)

Engine Code Lfx:

3.6L V6: LFX

Engine Code Luk:

2.5L I4: LUK

🔧 Transmission

Transmission Type:

6-speed automatic transmission (M7U or MYB)

Optional Transmission:

N/A for 2016 model year

Transmission Features:

Driver Shift Control, Electronic Range Select

📐 Dimensions

Length:

201.0 inches

Width:

73.0 inches

Height:

57.9 inches

Wheelbase:

111.7 inches

Trunk Volume:

18.9 cubic feet

Curb Weight I4:

Approximately 3,650 lbs (2.5L I4)

Curb Weight V6:

Approximately 3,750 lbs (3.6L V6)

🛡️ Safety Features

NHTSA Overall Rating:

5-Star Overall Safety Rating (NHTSA)

Active Safety Features:

StabiliTrak Electronic Stability Control, Traction Control System, Anti-lock Braking System (ABS), Electronic Brake Force Distribution (EBD), Brake Assist

Passive Safety Features:

Ten standard airbags (front, side, knee, roof-mounted curtain), front seatbelt pretensioners, LATCH child seat anchors.

Driver Assistance Packages:

Available Forward Collision Alert, Lane Departure Warning, Rear Vision Camera, Rear Park Assist.

💡 Technology Features

Infotainment System:

Chevrolet MyLink infotainment system with 8-inch diagonal color touch-screen display, Apple CarPlay and Android Auto compatibility (on select trims/packages), Bluetooth streaming audio, USB ports, auxiliary input jack.

Driver Assistance Systems:

Available Adaptive Cruise Control, Automatic Collision Preparation, Park Assist.

Connectivity Features:

Available Wi-Fi hotspot, OnStar connectivity with 4G LTE.

🔧 Maintenance

Oil Change Interval:

Every 7,500 miles or 12 months, whichever comes first (with synthetic oil).

Tire Rotation Interval:

Every 7,500 miles

Engine Coolant Flush:

First flush at 150,000 miles, then every 60,000 miles thereafter.

Engine Oil Type:

SAE 0W-20 Full Synthetic (GM dexos1 Gen 2 recommended)

Transmission Fluid Type:

Dexron-VI Automatic Transmission Fluid

Coolant Type:

GM Orange or equivalent, meeting GM6247M specification

Common Complaints:

Occasional reports of infotainment system glitches, minor interior rattles, and early brake pad wear. The manual provides detailed troubleshooting for these and all other potential issues.

Engine Oil Capacity I4:

5.3 US quarts (5.0 liters) with filter change (2.5L I4)

Engine Oil Capacity V6:

6.0 US quarts (5.7 liters) with filter change (3.6L V6)

Coolant Capacity:

Approximately 9.5 US quarts (9.0 liters) (V6), 8.5 US quarts (8.0 liters) (I4)

Spark Plug Type I4:

NGK LTR6AI-9 or AC Delco 41-110 (I4)

Spark Plug Type V6:

AC Delco 41-110 or NGK LTR6AI-9 (V6)

📚 Vehicle History

Chevrolet Legacy:

Chevrolet, founded in 1911, has a long history of producing reliable and accessible vehicles for the American market.

Impala History:

The Impala nameplate has been used for various Chevrolet models since 1958, evolving from a full-size luxury car to a more mainstream sedan. The 2014 redesign marked a significant shift to the Epsilon II platform, introducing a more modern design and front-wheel drive layout.

Assembly Locations:

Detroit-Hamtramck Assembly Plant, Michigan, USA

🏆 Awards & Recognition

IIHS Top Safety Pick:

Impala models equipped with specific optional safety features received the IIHS Top Safety Pick award in some years.
