Target Audience:
DIY car owners, independent repair shops, enthusiasts looking for accurate and detailed vehicle repair information
Vehicle Segment:
Subcompact car
Advantage:
Provides factory-level technical data and procedures, ensuring accuracy and completeness beyond generic repair guides. Offers the convenience of digital access, searchability, and selective printing.
User Experience:
Easy-to-use PDF format, no need to flip through multiple books, printable sections for workshop use, ability to zoom in on diagrams and illustrations.
Benefits:
Saves time and money on repairs, empowers owners with knowledge to maintain and fix their vehicle, provides access to dealer-level diagnostic and repair information.
Vehicles Covered:
All 2012-2017 Chevrolet Sonic models (sedan and hatchback)
Repair Scope:
Complete A-Z repairs, maintenance, diagnostics, and servicing
Engine Variants Covered:
1.4L Turbocharged Ecotec (LUJ/LUV) and 1.6L Ecotec (LDE)
Estimated Pages:
Extensive (specific count not provided, but described as 'everything you will ever need')
Type:
Factory Service and Repair Manual (equivalent to dealer technician manual)
Powertrain:
Engine (all variants), Fuel System, Emission Control, Intake & Exhaust Systems, Cooling System, Lubrication System, Ignition System, Starting & Charging System, Automatic Transmission, Manual Transmission, Clutch, Transfer Case (if applicable), Drive Shaft, Differential, Axles
Chassis:
Suspension System (front and rear), Steering Column, Power Steering, Brake Control, Brake System (front and rear), Parking Brake, Wheels, Tires
Body & Electrical:
Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer Systems, Door Locks, Meter & Audio Systems, Visual Systems, Horn, Windshield, Glass & Mirrors, Instrument Panel, Seats, Engine Hood, Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication
Engine Management System:
Includes fuel injection, ignition timing, emissions control, engine sensors, and actuators.
Body Control Modules:
Covers various Body Control Modules (BCM) and their functions.
Maintenance:
Scheduled maintenance, fluid level checks and changes, filter replacements, inspection procedures
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), component testing, wiring schematic interpretation
Repair:
Step-by-step repair procedures for all major components and systems, including disassembly, reassembly, and component replacement
Wiring Schematics:
Detailed and comprehensive wiring diagrams for all electrical systems and components, essential for troubleshooting and repair.
Torque Specifications:
Precise torque values for all fasteners and critical components.
Depth:
Comprehensive. Covers everything from basic fluid changes and inspections to complex engine rebuilds, transmission overhauls, and advanced electrical diagnostics, including detailed wiring schematics.
Special Tools:
Lists required special tools for specific diagnostic and repair procedures.
Searchability:
Searchable PDF text for quick information retrieval.
Printability:
High quality, printable pages. Ability to enlarge images for clarity.
Binding:
Digital (no physical binding)
Paper Type:
N/A (digital format)
Operating Systems:
Windows (Vista 32/64, XP, ME, 98, NT, 2000), Mac OS
Software Requirements:
Adobe PDF Reader, WinZip (free online)
Engine Options:
1.4L Turbocharged Ecotec (LUJ/LUV), 1.6L Ecotec (LDE)
1.4L Turbo (Luj/Luv) Horsepower:
138 hp @ 4900 rpm (approx.)
1.4L Turbo (Luj/Luv) Torque:
148 lb-ft @ 2500 rpm (approx.)
1.6L (Lde) Horsepower:
115 hp @ 6000 rpm (approx.)
1.6L (Lde) Torque:
111 lb-ft @ 4000 rpm (approx.)
Fuel Delivery:
Port Fuel Injection (PFI) for 1.6L, Direct Injection (DI) for 1.4L Turbo
ECU Details:
Detailed information on Engine Control Unit (ECU) operation, sensors, and actuators
NHTSA Overall Rating:
5-Star (for most configurations)
Braking System:
Front disc / Rear drum (standard), Front and Rear disc (optional/higher trims), ABS, EBD, Traction Control, StabiliTrak (ESC)
Airbags:
Frontal airbags, front side-impact airbags, curtain side airbags (coverage and availability depend on trim level)
Seat Belts:
3-point seat belts with pretensioners and load limiters
Infotainment System:
Chevrolet MyLink infotainment system (available on certain trims/options), featuring touchscreen, Bluetooth connectivity, Pandora, Stitcher
Audio Options:
Standard AM/FM/MP3, optional SiriusXM Satellite Radio
Cruise Control:
Standard or optional depending on trim level
Connectivity Features:
USB ports, auxiliary input jack, available OnStar communications
Oil Change:
Every 7,500 miles or 6 months, whichever comes first (synthetic oil recommended)
Tire Rotation:
Every 7,500 miles
Engine Air Filter:
Inspect every 22,500 miles, replace as needed
Cabin Air Filter:
Replace every 22,500 miles or as needed
Spark Plugs:
1.4L Turbo: 97,500 miles (iridium); 1.6L: 100,000 miles (platinum)
Engine Oil Type:
SAE 5W-30 Synthetic (API SN certified)
Coolant Type:
GM P/N 12346290 (Dex-Cool Extended Life Orange)
Engine Oil Capacity 1.4T:
4.2 US quarts (3.97 Liters) with filter change
Engine Oil Capacity 1.6L:
4.0 US quarts (3.78 Liters) with filter change
Common Problems Mentioned:
Oil leaks (especially valve cover gasket), turbocharger issues (on 1.4T), ignition coil failures, transmission complaints (less common), exhaust manifold cracks (on 1.4T)
Manufacturer:
Chevrolet (a division of General Motors)
Introduction Date:
Launched in 2011 for the 2012 model year as a global compact car
Facelift:
Received a facelift for the 2016 model year, including updated styling and features.
Manufacturing Locations:
Korea (GM Daewoo/GM Korea), South Korea; Ramos Arizpe, Mexico; St. Petersburg, Russia
