Segment:
Full-size Luxury Sedan / Performance Sedan
Positioning:
High-performance variant of the Chrysler 300, blending American luxury with muscle car power.
Competitors:
BMW 5 Series, Mercedes-Benz E-Class, Cadillac CTS-V, Dodge Charger SRT-8 (shared platform but different focus).
Performance Focus:
Emphasis on the SRT-8's performance capabilities, including its potent engine and sport-tuned chassis.
User Benefit:
Enables owners and technicians to perform professional-level maintenance and repairs, saving time and money.
Engine Systems:
Engine Mechanical, Lubrication System, Cooling System, Fuel System, Ignition System, Emission Control System
Drivetrain Systems:
Transmission (Automatic), Drivetrain Components (Axles, Driveshaft, Differentials)
Chassis Systems:
Brakes, Steering, Suspension (Front and Rear), Wheels and Tires
Electrical Systems:
Power Distribution, Lighting, Instruments and Gauges, Audio System, Body Electrical (Wipers, Horn, Locks), Powertrain Control Module (PCM), Anti-lock Braking System (ABS)
Body Systems:
Body Construction, Exterior Trim, Interior Trim, Doors, Windows, Seats, HVAC System
Routine Maintenance:
Tune-ups, Oil and Filter Changes, Fluid Checks and Replenishments, Filter Replacements, Belt Inspections
Repair Procedures:
Engine Component Removal and Installation, Transmission Overhaul, Brake System Repair, Suspension Component Replacement, Electrical Component Diagnostics and Repair
Diagnostics:
Troubleshooting charts, Symptom-based diagnostics, Diagnostic Trouble Codes (DTCs)
Assemblies Disassemblies:
Complete disassembly and reassembly of major vehicle components and sub-assemblies
Depth:
Comprehensive, covering basic maintenance to complete engine and transmission overhauls
User Level:
Primarily for mechanical technicians, assumes familiarity with general automotive practices and procedures
Special Tools:
Identification and usage of specific Chrysler special tools
Proprietary Components:
Instructions for proprietary components, referencing manufacturer instructions where applicable
Engine Type:
Naturally Aspirated V8 (though the 6.1L Hemi debuted in the 2006 SRT-8, the manual likely covers the platform's foundational engine, which in the 300C was a 5.7L Hemi. This manual is for the SRT-8, implying the higher-performance variant).
Displacement:
5.7L (for base 300C) / 6.1L (for SRT-8, introduced in 2006. Manual likely covers the 6.1L for the SRT-8 designation).
Horsepower:
360 hp (estimated for 5.7L) / 425 hp (for 6.1L SRT-8)
Torque:
390 lb-ft (estimated for 5.7L) / 420 lb-ft (for 6.1L SRT-8)
Injection Type:
Sequential Multi-Port Fuel Injection (MPFI)
Fuel Type:
Premium Unleaded Gasoline
Valve Train:
Overhead Valve (OHV) with Hemispherical Combustion Chambers
Cylinder Block Material:
Cast Iron
Cylinder Head Material:
Aluminum
Transmission Type:
5-Speed Automatic (W5A580)
Optional Transmission:
N/A for SRT-8 (This model typically came exclusively with the automatic)
Transmission Features:
Electronically Controlled, Driver-Adaptive Automatic Transmission
Fluid Type:
ATF+4 (Mopar)
Fluid Capacity:
Approximately 10-12 quarts (check manual for exact capacity)
NHTSA Front Crash Rating:
5-Star (for both driver and passenger)
IIHS Front Offset Crash Rating:
Good
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Standard Traction Control
Electronic Stability Control:
Standard Electronic Stability Control (ESC)
Airbags:
Front Airbags, Side Curtain Airbags
Seatbelts:
Pretensioning Seatbelts
Infotainment System:
Optional Boston Acoustics premium audio system, available Navigation System, CD/MP3 player.
Driver Assistance Features:
ParkSense Rear Park Assist (Optional)
Connectivity Options:
Optional SiriusXM Satellite Radio
Oil Change Interval:
Every 6,000 miles (9,600 km) or 6 months, whichever comes first (under normal driving conditions).
Transmission Fluid Change:
Recommended every 60,000 miles (96,000 km) or as per severe service schedule.
Engine Air Filter Replacement:
Inspect every 15,000 miles (24,000 km), replace as needed.
Spark Plug Replacement:
Every 100,000 miles (160,000 km) for most Hemi engines.
Engine Oil Specification:
SAE 5W-20 (API Certified)
Engine Oil Capacity:
7 quarts (6.6 liters) with filter (for 5.7L Hemi) / 7 quarts (6.6 liters) with filter (for 6.1L Hemi)
Coolant Type:
Mopar OAT (Organic Additive Technology) Antifreeze/Coolant, Blue (5/150,000 mile)
Common Issues:
Water pump leaks, power steering pump issues, transmission solenoid failures, exhaust manifold cracks (less common on SRT-8), electronic throttle control problems.
Heritage:
Chrysler has a long history of producing large, comfortable sedans and, with the SRT division, powerful performance vehicles.
Generation Details:
The Chrysler 300 debuted for the 2005 model year on the LX platform. The SRT-8 variant, featuring the potent 6.1L Hemi, was introduced for the 2006 model year, building upon the success of the initial launch.
Manufacturing Location:
Brampton Assembly Plant, Ontario, Canada
