🏷️ Basic Information

Make:

Chrysler

Model:

Aspen

Model Year:

2007-2009

Generation Code:

GY

Vin Prefix:

1C4

👋 Introduction

Target Audience:

DIY enthusiasts, independent repair shops, Chrysler dealerships

Manual Equivalence:

Same as manual used by official workshops

Content Highlights:

Extensive coverage, detailed illustrations, factory-level accuracy

User Experience:

Easy to read, print, and navigate on various devices

📋 Manual Details

Covered Years:

2007, 2008, 2009

Covered Models:

Chrysler Aspen

Page Count:

6000+

Manual Type:

Factory Workshop Service Repair Manual

Language:

English

Format:

PDF

Delivery Method:

Download Link

Platform Compatibility:

Windows & Mac Computers (including Windows 10, 8, 7, Vista 32/64, XP, ME, 98, NT, 2000), Tablet, Phone

Architecture Compatibility:

32/64 bit

📖 Manual Coverage

Powertrain:

4.7L Engine, 5.7L Engine, Transmission Control, Transfer Case, Front Axle, Rear Axle (8-1/4" & 9-1/4"), Propeller Shafts, Half Shafts

Chassis:

Suspension (Front & Rear), Steering, Brake Service Info, ABS Service, ABS Electrical

Electrical:

ABS Electrical, Audio Video Electrical, Battery, Charging, Chime Buzzer Electrical, Cruise Control Electrical, Defogger Electrical, Door Locks Electrical, ECM Electrical, Electrical Component Locator, Horn Electrical, Ignition System Electrical, Lighting Exterior Electric, Lighting Interior Electric, Navigation Electrical, PCM-ECM Programming, Power Distribution, Power Liftgate Electrical, Power Mirrors Electrical, Restraints Electrical, Transfer Case Electrical, Transmission Control Electrical, Wiper Front Electrical, Wiper Rear Electrical

Body And Trim:

Bumpers, Doors (Front & Rear), Glass, Hood, Liftgate, Interior, Seats, Sunroof

Comfort And Convenience:

Audio Video Service, HVAC Service, HVAC Electric, Defogger, Door Locks Service, Cruise Control, Power Liftgate Service, Power Mirrors Service, Wiper Washer

Fuel And Emissions:

Fuel System, Engine Emission, Engine Exhaust

Instrumentation And Controls:

Instrument Panel, Cruise Control

Lighting:

Exterior Lighting, Interior Lighting

Body Hardware:

Doors (Front/Rear), Liftgate, Hood, Bumpers, Glass, Sunroof

Cooling And Exhaust:

Engine Cooling, Engine Exhaust

Ignition And Starting:

Ignition System Electrical, Ignition System Service, Starting Service

Audio Visual And Navigation:

Audio Video Electrical, Audio Video Service, Navigation, Navigation Electrical

Power Accessories:

Door Locks Service, Door Locks Electrical, Power Liftgate Service, Power Liftgate Electrical, Power Mirrors Service, Power Mirrors Electrical

Wipers And Washers:

Wiper Front Electrical, Wiper Rear Electrical, Wiper Washer

Restraints:

Restraints Electrical, Restraints Service

Maintenance:

Routine Maintenance, Fluid Changes, Filter Replacements, Lubrication

Diagnostics:

Trouble Codes, System Diagnosis, Component Testing

Repair:

Component Removal and Installation, Reassembly, Adjustments, Overhauls

Troubleshooting:

Step-by-step troubleshooting guides for various systems

Electrical Repair:

Wiring Diagrams, Connector Pinouts, Component Testing, Repair of Electrical Circuits

Depth Of Coverage:

Comprehensive factory-level repair and diagnostic information

Illustrations:

Hi-Resolution Illustrations, Photos, and Diagrams

Instruction Style:

Detailed step-by-step instructions for all workshop procedures

📊 Manual Specifications

File Type:

PDF

Searchable Text:

Likely (typical for factory PDFs)

Print Quality Indicator:

Hi-Resolution

Printability:

Print pages directly from CD or copy to hard drive

Binding Type:

Digital (PDF) - No physical binding

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Option 1:

4.7L SOHC V8 Magnum

Engine Option 2:

5.7L HEMI Multi-Displacement V8

4.7L Horsepower Approx:

303 hp @ 5650 rpm

4.7L Torque Approx:

330 lb-ft @ 3650 rpm

5.7L Horsepower Approx:

357 hp @ 5000 rpm

5.7L Torque Approx:

389 lb-ft @ 4000 rpm

Fuel Delivery:

Electronic Fuel Injection (Multi-Port or Sequential)

Timing System 4.7L:

SOHC, Timing Chain

Timing System 5.7L:

OHV (HEMI), Timing Chain

🔧 Transmission

Transmission Type:

5-Speed Automatic (545RFE)

Transfer Case:

Command-Trac NV244 (2-speed, electronic shift) or Quadra-Trac II NV271 (optional on some models)

Transmission Features:

Electronic control, Tow/Haul mode

Transmission Fluid Type:

ATF+4 (MS-9602)

📐 Dimensions

Wheelbase:

119.2 inches (3028 mm)

Length:

200.0 inches (5080 mm)

Width:

78.2 inches (1986 mm)

Height:

75.7 inches (1923 mm)

Cargo Volume Behind 3Rd Row:

16.7 cubic feet (0.47 m³)

Cargo Volume Behind 2Nd Row:

49.1 cubic feet (1.39 m³)

Cargo Volume Behind 1St Row:

99.2 cubic feet (2.81 m³)

Curb Weight Approx:

5,000 - 5,500 lbs (2268 - 2495 kg)

Towing Capacity Max:

7,000 - 7,500 lbs (3175 - 3402 kg) (depending on configuration)

🛡️ Safety Features

NHTSA Front Crash Test Driver:

5-star (2007-2009 models)

NHTSA Front Crash Test Passenger:

5-star (2007-2009 models)

NHTSA Side Impact Front Driver:

5-star (2007-2009 models)

NHTSA Side Impact Front Passenger:

5-star (2007-2009 models)

NHTSA Side Impact Rear Driver:

5-star (2007-2009 models)

NHTSA Side Impact Rear Passenger:

5-star (2007-2009 models)

IIHS Roof Strength:

Good (2007-2009 models)

Braking System:

4-wheel Anti-lock Brakes (ABS)

Traction Control:

Electronic Stability Program (ESP), Traction Control System (TCS)

Tire Pressure Monitoring:

Tire Pressure Monitoring System (TPMS)

Airbags:

Multi-stage Front Airbags, Side Curtain Airbags (all rows), Front Side Airbags

Seatbelts:

3-point seatbelts with pretensioners and load limiters

💡 Technology Features

Infotainment System:

Optional MyGIG Multimedia Infotainment System (HDD-based navigation, CD/DVD player, SiriusXM Satellite Radio, Uconnect hands-free communication)

Parking Assistance:

Optional ParkView Rear Back-Up Camera, ParkSense Rear Park Assist System

Connectivity Features:

Optional Uconnect Bluetooth hands-free communication

🔧 Maintenance

Oil Change Interval:

Every 6,000 miles or 6 months (synthetic blend recommended)

Tire Rotation Interval:

Every 7,500 miles

Transmission Fluid Change Interval:

Every 60,000 miles (severe service) or 100,000 miles (normal service)

Coolant Flush Interval:

Every 60,000 miles or 5 years

Engine Oil Type 4.7L:

SAE 5W-20 (API SN or higher)

Engine Oil Type 5.7L:

SAE 5W-20 (API SN or higher)

Engine Oil Capacity 4.7L:

7 quarts (6.6 liters) with filter

Engine Oil Capacity 5.7L:

7 quarts (6.6 liters) with filter

Coolant Type:

Mopar OAT (Organic Additive Technology) Antifreeze/Coolant (MS-9769)

Brake Fluid Type:

DOT 3

Common Issues:

Potential for head gasket issues on earlier 5.7L HEMI engines, minor electrical gremlins, HVAC blend door actuator failures, potential for rust on the unibody frame if not maintained in corrosive environments.

📚 Vehicle History

Brand Introduction:

Chrysler, a division of Fiat Chrysler Automobiles (formerly DaimlerChrysler, Chrysler Group LLC)

Segment:

Full-size SUV

Platform Sharing:

Shared platform with Dodge Durango

Production Period:

2004-2009 (Chrysler Aspen was introduced for the 2007 model year)

Manufacturing Location:

Newark, Delaware, USA

🏆 Awards & Recognition

Safety Recognition Summary:

Consistently received high safety ratings from NHTSA for occupant protection.
