🏷️ Basic Information

Make:

Chrysler

Model:

Pacifica

Year:

2004

Chassis Code:

CS

👋 Introduction

Segment:

Mid-size Crossover SUV

Competitors:

Ford Freestyle, Toyota Highlander, Honda Pilot, Nissan Murano

Design:

Distinctive styling, spacious interior, available third-row seating

📋 Manual Details

Manual Type:

Factory Service Repair Workshop Manual

Language:

English

Format:

PDF Download

Compatibility:

All Windows & Mac operating systems

Requirements:

Adobe PDF Reader, WinZip

📖 Manual Coverage

Powertrain:

Engine Systems, Automatic Transmission, Differential and Driveline, Exhaust System, Fuel System, Emission Control

Chassis:

Suspension, Brakes, Steering, Tires/Wheels, Frame and Bumpers

Electrical:

Audio/Video, Chime/Buzzer, Clock, Electronic Control Modules, Horn, Ignition Control, Instrument Cluster, Lamps, Message Systems, Power Systems, Restraints, Speed Control, Vehicle Theft Security, Wipers/Washers, Navigation/Telecommunication, Wiring

Body:

Body, Heating and Air Conditioning

Maintenance:

Lubrication and Maintenance, Scheduled Maintenance

Repair:

Complete Disassembly and Reassembly Procedures, Component Repair, System Diagnosis

Diagnostics:

DTC Index, Troubleshooting Guides

Depth:

Detailed illustrations, step-by-step instructions, suitable for DIY and experienced mechanics

📊 Manual Specifications

File Format:

PDF

Print Quality:

Printable pages

Searchability:

Likely searchable text within PDF (dependent on OCR quality if scanned)

⚙️ Engine Specifications

Engine Type:

3.5L SOHC V6 (High Output variant likely for CS designation)

Displacement:

3.5 Liters

Cylinders:

6

Valvetrain:

SOHC (Single Overhead Camshaft)

Induction:

Multi-point Fuel Injection (MPI)

🔧 Transmission

Transmission Type:

4-speed Automatic Transaxle

Drivetrain:

All-Wheel Drive (AWD) likely standard or optional for CS designation

📐 Dimensions

Length:

Approximately 199.9 inches

Width:

Approximately 77.7 inches

Height:

Approximately 66.4 inches

Seating Capacity:

Up to 7 passengers (2+2+3 configuration typical)

Curb Weight:

Approx. 4,300 - 4,600 lbs (depending on drivetrain)

🛡️ Safety Features

NHTSA Frontal Crash:

5-Star (Driver and Passenger, likely for 2004 model)

NHTSA Side Impact:

4-Star (Front and Rear Seat Passenger, likely for 2004 model)

Braking:

Anti-lock Braking System (ABS), Electronic Brake-force Distribution (EBD)

Airbags:

Frontal airbags, Side-curtain airbags (likely standard or optional for all rows)

💡 Technology Features

Audio System:

Available premium audio systems with CD player, AM/FM radio. Optional rear-seat entertainment system.

Cruise Control:

Standard Speed Control

Navigation:

Optional factory navigation system available

🔧 Maintenance

Oil Change:

Typically every 3,000 - 7,500 miles depending on oil type and driving conditions (refer to manual for specifics)

Tire Rotation:

Every 5,000 - 7,500 miles

Engine Oil:

SAE 5W-30 Synthetic (Refer to manual for exact API classification and Mopar specifications)

Transmission Fluid:

Chrysler ATF+4 (Mopar J-Spec ATF+4)

Coolant:

OAT (Organic Additive Technology) IAT (Inorganic Additive Technology) compatible HOAT (Hybrid Organic Additive Technology) antifreeze/coolant (typically 50/50 mix with distilled water)

Transmission:

Early models of the 4-speed automatic could experience solenoid issues or torque converter problems.

Suspension:

Front suspension components (struts, ball joints, sway bar links) can wear over time.

Electrical:

Water intrusion into the Totally Integrated Power Module (TIPM) can cause various electrical gremlins.

📚 Vehicle History

Manufacturer:

Chrysler, a division of Stellantis (formerly Fiat Chrysler Automobiles)

Introduction Year:

2004

Platform:

Chrysler Minivan platform (RS platform basis), re-engineered for crossover application

🏆 Awards & Recognition

Safety Rating:

Achieved high safety ratings from NHTSA for the 2004 model year.
