Positioning:
Comprehensive repair resource for Chrysler Pacifica owners seeking dealership-level accuracy.
Advantage:
Provides vehicle-specific information, unlike generic repair guides, ensuring accurate and efficient repairs.
Content Highlight:
Exact replica of technician manuals, digital format for convenience and portability.
User Benefit:
Empowers owners to perform maintenance and repairs, saving time and money.
Powertrain:
Engine, Fuel System, Emission Control, Intake/Exhaust, Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Clutch
Drivetrain:
Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axle, Suspension, Tires & Wheels
Chassis:
Brake Control, Brakes, Parking Brake, Steering Column, Power Steering
Electrical And Electronics:
Air Conditioning, Supplemental Restraint System (SRS), Seat Belt Systems, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Locks, Meter/Audio/Visual, Horn, Windshield/Glass/Mirror, Instrument Panel, Electrical System, Multiplex/CAN Communication
Body And Interior:
Engine Hood/Door, Exterior & Interior Trim, Seats
Diagnostic Procedures:
Detailed troubleshooting, fault code interpretation, diagnostic flowcharts
Maintenance Procedures:
Scheduled maintenance, fluid changes, filter replacements, lubrication
Repair Procedures:
Component removal, installation, adjustment, and replacement for all major systems
Specifications And Data:
Torque specifications, clearances, fluid types and capacities, electrical parameters
Depth:
Factory-level detail, intended for professional technicians and advanced DIYers
Content Type:
Step-by-step instructions, diagrams, illustrations, wiring schematics
Engine Type:
3.5L SOHC V6 (EGG)
Engine Displacement:
3.5 Liters / 3518 cc
Bore X Stroke:
92.0 mm x 87.1 mm
Horsepower:
200 hp @ 5400 rpm (approx.)
Torque:
220 lb-ft @ 3400 rpm (approx.)
Fuel Delivery:
Sequential Multi-Port Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline, 87 octane (minimum)
ECM Module:
Chrysler DRB III diagnostic tool compatibility
Length:
198.7 inches (504.7 mm)
Width:
78.1 inches (198.4 mm)
Height:
65.9 inches (167.4 mm)
Wheelbase:
116.0 inches (2946 mm)
Front Track:
65.0 inches (1651 mm)
Rear Track:
65.1 inches (1654 mm)
Curb Weight:
Approx. 4,439 - 4,611 lbs (2013 - 2091 kg) depending on configuration
Gross Vehicle Weight Rating:
Approx. 5,800 lbs (2630 kg)
Cargo Volume Behind 3Rd Row:
Approx. 12.3 cu ft (0.35 m³)
Cargo Volume Behind 2Nd Row:
Approx. 40.5 cu ft (1.15 m³)
Cargo Volume Behind 1St Row:
Approx. 85.5 cu ft (2.42 m³)
NHTSA Front Driver Impact:
5 Stars (for 2006 model)
NHTSA Front Passenger Impact:
5 Stars (for 2006 model)
NHTSA Side Driver Impact:
4 Stars (for 2006 model)
NHTSA Side Passenger Impact:
5 Stars (for 2006 model)
IIHS Front Offset Crash Rating:
Good (for 2006 model)
IIHS Side Impact Crash Rating:
Good (for 2006 model)
Traction Control:
Standard on all models
Electronic Stability Control:
Optional (Electronic Stability Program - ESP)
Airbags Front:
Advanced front airbags (driver and passenger)
Airbags Side:
Side curtain airbags (for all three rows)
Seatbelts:
3-point seat belts with pretensioners and load limiters
Audio System:
Optional Boston Acoustics premium audio system available.
Navigation:
Optional factory-installed navigation system.
Parking Assist:
Optional rear park assist system.
Auxiliary Input:
Optional auxiliary audio input jack.
Cruise Control:
Standard cruise control system.
Oil Change Interval:
Every 3,000-5,000 miles or 3-6 months, depending on driving conditions and oil type used. Refer to manual for specific recommendations.
Engine Air Filter:
Inspect every 15,000 miles, replace as needed. Consult manual for precise interval.
Cabin Air Filter:
Inspect every 15,000 miles, replace as needed. Consult manual for precise interval.
Transmission Fluid Service:
Inspect fluid level and condition every 30,000 miles. Fluid and filter replacement typically recommended every 60,000-100,000 miles, check manual.
Engine Oil:
SAE 5W-30 (API Certified, ILSAC GF-3)
Engine Oil Capacity:
5.0 quarts (4.7 liters) with filter change
Coolant:
Mopar OAT (Organic Additive Technology) or equivalent HOAT coolant, 50/50 mix with distilled water.
Power Steering Fluid:
ATF+4 (Mopar)
Common Issue 1:
Transmission issues (e.g., harsh shifting, slipping) due to wear or fluid degradation.
Common Issue 2:
Water pump leaks or failure.
Common Issue 3:
Power steering pump noise or leaks.
Common Issue 4:
Electrical issues, particularly with the TIPM (Totally Integrated Power Module).
Common Issue 5:
Rattles and squeaks from interior trim panels.
Brand Origin:
Chrysler, an American automotive manufacturer with a long history of innovation.
Introduction Year:
2004 model year
Platform:
Chrysler CS platform, shared with Dodge Magnum and Charger (with modifications).
Facelift Info:
Received a minor refresh for the 2007 model year, but the 2006 remains part of the initial generation.
Manufacturing Location:
Windsor Assembly Plant, Ontario, Canada
Production Years:
2004 - 2008
Safety Award NHTSA:
Received high safety ratings from NHTSA (5-star front, 4-star side impact).
IIHS Safety Rating:
Good ratings from IIHS in front and side impact tests.
Manual Certification:
Factory authorized content, ensuring accuracy and adherence to OEM standards.
