🏷️ Basic Information

Make:

Chrysler

Model:

Sebring

Year:

2002

Model Code:

JS

👋 Introduction

Segment:

Mid-size Coupe/Sedan/Convertible

Competitors:

Ford Mustang, Chevrolet Camaro, Toyota Camry, Honda Accord, Nissan Altima

Platform:

Chrysler's JS platform, shared with the Dodge Stratus and Plymouth Breeze.

Body Styles:

Offered in Coupe, Sedan, and Convertible body styles.

📋 Manual Details

General:

Complete Repair and Service

Estimated:

Over 1500 pages (estimated for factory service manual of this era)

Type:

Factory Service Repair Manual

Language:

English

Format:

PDF (Digitally Delivered)

📖 Manual Coverage

Powertrain:

Engine Systems, Cooling System, Fuel System, Exhaust System, Transmission/Transaxle

Chassis:

Suspension, Brakes, Steering, Differential & Driveline, Tires/Wheels, Frame & Bumpers

Electrical:

Audio System, Chime/Buzzer, Electronic Control Modules (ECM/PCM), Ignition Control, Instrument Cluster, Lamps, Compass/Mini-Trip Computer, Power Systems, Restraints (Airbags), Speed Control, Vehicle Theft Security, Wipers/Washers, Wiring Diagrams

Body:

Body, Heating & Air Conditioning (HVAC), Emissions Control

Maintenance:

Lubrication & Maintenance, Fluid Specifications, Filter Replacements, Tune-up Procedures

Repair:

Component Removal & Installation, Diagnostic Procedures, Overhaul Procedures, Component Reassembly

Troubleshooting:

Diagnostic Trouble Codes (DTCs), Symptom-based Troubleshooting Charts, Electrical Circuit Diagnosis

Depth:

Comprehensive: From basic maintenance and fluid checks to in-depth engine and transmission diagnostics, electrical system troubleshooting, and body component repair. Includes detailed specifications and procedures used by professional technicians.

📊 Manual Specifications

PDF Features:

Searchable text, hyperlinked table of contents, zoomable diagrams and illustrations, printable pages.

Quality:

High-resolution digital reproduction of original factory documentation.

Binding:

N/A (Digitally Delivered PDF)

Paper:

N/A (Digitally Delivered PDF)

⚙️ Engine Specifications

Engine 2.0L 4 Cylinder:

2.0L DOHC 16-valve I4 (Engine code: EDZ)

Engine 2.7L V6:

2.7L DOHC 24-valve V6 (Engine code: EDB)

Engine 3.0L V6:

3.0L SOHC 12-valve V6 (Engine code: 6G72 - Mitsubishi sourced, phased out early in the generation)

Engine 3.5L V6:

3.5L SOHC 24-valve V6 (Engine code: EGF - High Output)

Horsepower 2.0L I4:

Approx. 134 hp @ 5800 RPM

Torque 2.0L I4:

Approx. 130 lb-ft @ 4400 RPM

Horsepower 2.7L V6:

Approx. 200 hp @ 6000 RPM

Torque 2.7L V6:

Approx. 192 lb-ft @ 4400 RPM

Horsepower 3.5L V6:

Approx. 230 hp @ 6000 RPM

Torque 3.5L V6:

Approx. 245 lb-ft @ 4000 RPM

Induction:

Electronic Multi-port Fuel Injection (MPI)

Fuel Type:

Unleaded gasoline

🔧 Transmission

Transmission Type:

4-speed Automatic Transaxle (e.g., 41TE, 42LE)

Transmission Type:

5-speed Manual Transaxle (Less common, primarily on 4-cylinder models)

Automatic Features:

Electronically controlled, torque converter clutch.

📐 Dimensions

Length Sedan:

Approx. 193.8 inches

Width:

Approx. 70.5 inches

Height Sedan:

Approx. 56.3 inches

Wheelbase:

Approx. 109.7 inches

Curb Weight Min:

Approx. 3200 lbs (for 4-cylinder coupe)

Curb Weight Max:

Approx. 3600 lbs (for V6 convertible)

🛡️ Safety Features

NHTSA Front Impact:

Not consistently rated across all configurations. Early models may have less robust side-impact protection.

ABS:

Standard on most trims, optional on base models.

Traction Control:

Available on V6 models.

Airbags:

Driver and front passenger airbags. Side airbags optional on some trims.

Seatbelts:

3-point front and rear seatbelts. Pretensioners for front seats.

💡 Technology Features

Audio System:

Optional premium audio systems with CD player, AM/FM radio. Cassette player common on base models.

Navigation:

Rarely available, likely aftermarket for this model year.

Cruise Control:

Standard on most trims, integrated into the steering wheel or column.

Power Windows Locks:

Power windows, power door locks, power mirrors standard on higher trims, optional on base.

Keyless Entry:

Optional keyless entry system.

🔧 Maintenance

Oil Change:

Every 7,500 miles or 6 months, whichever comes first (synthetic or synthetic blend recommended).

Coolant Flush:

Every 100,000 miles or 5 years for HOAT coolant.

Transmission Fluid Change:

Every 60,000 miles (for automatic transmissions).

Engine Oil:

SAE 5W-30 (API Certified, meets Chrysler MS-6395 specification).

Coolant:

Chrysler OAT (Orange) or HOAT (Yellow) Antifreeze/Coolant, 50/50 mixture with distilled water.

Transmission Fluid Auto:

ATF+4 (Automatic Transmission Fluid, Mopar part number 05013457AA or equivalent).

Brake Fluid:

DOT 3 brake fluid.

Engine Mounts:

Premature wear of engine mounts, especially on V6 models, leading to vibration.

Transmission Solenoids:

Transmission solenoid failure or erratic shifting, particularly in the 4-speed automatic.

Evaporative Emissions System:

Canister purge valve and vent valve failures leading to EVAP system codes.

Climate Control Actuators:

Failure of blend door actuators in the HVAC system, causing incorrect air temperature or direction.

📚 Vehicle History

Chrysler Legacy:

Chrysler's long history of producing comfortable and stylish American sedans and coupes.

Generation 2002:

This 2002 model represents the second generation of the Sebring, which debuted for the 2001 model year. It featured updated styling and platform enhancements compared to the first generation.

Manufacturing Location:

Sterling Heights, Michigan, USA

🏆 Awards & Recognition

Initial Reception:

Generally received mixed reviews. Praised for styling and comfort, criticized for powertrain refinement and build quality on some models.

Consumer Ratings:

Consumer satisfaction varied, with some owners reporting reliability issues. The V6 engines, especially the 2.7L, were generally preferred over the 4-cylinder for performance.
