Segment:
City Car / Subcompact
Target Audience:
Budget-conscious urban commuters, first-time car buyers.
Key Competitors:
Hyundai Atos, Kia Picanto, Suzuki Alto, Fiat Seicento.
Design Philosophy:
Compact dimensions, fuel efficiency, affordability, distinctive 'bug-eyed' styling.
Value Proposition:
Offers essential transportation and a low entry price point.
Years Covered:
2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010
Type:
Comprehensive Service & Repair Manual
Powertrain:
Engine mechanical, fuel system, ignition system, exhaust system, cooling system, lubrication system, engine management (ECU).
Drivetrain:
Clutch, manual transmission, automatic transmission (if applicable to specific models), driveshafts, differentials, axles.
Chassis:
Suspension (front and rear), steering system, braking system (hydraulic, ABS if equipped).
Electrical:
Starting and charging system, lighting, instrumentation, power windows, power locks, wipers, horn, fuses, relays, wiring diagrams.
Body And Trim:
Body panels, doors, hood, trunk, interior trim, seats, bumpers, glass, mirrors.
Maintenance:
Scheduled maintenance, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection and replacement.
Troubleshooting:
Diagnostic procedures for common issues, symptom-based troubleshooting guides, electrical fault finding.
Repair:
Step-by-step repair instructions for major components and systems, engine overhaul, transmission repair, suspension and brake component replacement.
Diagnostics:
OBD-II diagnostic trouble codes (DTCs) and their meanings, sensor testing procedures.
Depth:
Comprehensive, covering everything from basic maintenance to advanced engine and transmission rebuilds. Includes detailed specifications, torque values, and diagnostic procedures.
Engine Code:
F8CV (common variant)
Configuration:
Inline 3-cylinder, naturally aspirated
Displacement:
796 cc (0.8 L)
Bore X Stroke:
70.8 mm x 69.0 mm
Valve Train:
SOHC (Single Overhead Camshaft), 12 valves (4 per cylinder)
Horsepower Ps:
52 PS @ 6400 rpm
Horsepower Hp:
51 hp @ 6400 rpm
Torque Nm:
71 Nm (52 lb-ft) @ 4600 rpm
Fuel Delivery:
Multi-point Fuel Injection (MPI)
Fuel Type:
Unleaded Gasoline (Octane Rating: 91 or higher recommended)
Coolant Capacity:
Approx. 4.5 Liters (with heater)
Oil Capacity:
Approx. 3.2 Liters (with filter change)
Recommended Oil Grade:
API SF/SG or higher, SAE 10W-30 or 10W-40 (depending on climate)
Transmission Type:
5-Speed Manual Transmission
Transmission Type:
3-Speed Automatic Transmission (less common, often found on later models)
Manual Gear Ratios:
Specific ratios available in manual, e.g., 1st: 3.545, 2nd: 1.944, 3rd: 1.379, 4th: 1.031, 5th: 0.838, Reverse: 3.333. Final Drive: 4.118.
Manual Transmission Fluid Capacity:
Approx. 2.0 Liters
Manual Transmission Fluid Type:
API GL-4, SAE 75W-85 or 75W-90 gear oil.
Automatic Transmission Fluid Capacity:
Approx. 4.5 Liters (Total fill)
Automatic Fluid Specification
Automatic Transmission Fluid Type:
Dexron II/III or equivalent ATF.
Length:
3495 mm (137.6 in)
Height:
1500 mm (59.1 in)
Wheelbase:
2340 mm (92.1 in)
Ground Clearance:
Approx. 140 mm (5.5 in)
Curb Weight:
Approx. 770-850 kg (1698-1874 lbs) depending on equipment and transmission.
Gross Vehicle Weight Rating Gvwr:
Approx. 1250 kg (2756 lbs)
Towing Capacity:
Not officially specified for typical small city cars, generally not recommended.
Cargo Volume Seats Up:
Approx. 165 Liters
Cargo Volume Seats Down:
Approx. 800 Liters (with rear seats folded)
Euro Ncap Rating:
Early models had 3-star adult occupant protection, later improvements may vary. Check specific year and market ratings.
ABS:
Optional on some models, standard on higher trims.
Electronic Brakeforce Distribution Ebs:
Often integrated with ABS systems.
Airbags:
Driver airbag standard, passenger airbag optional on some models.
Seatbelts:
3-point front seatbelts with pretensioners, 3-point rear seatbelts (may vary).
Body Structure:
Reinforced safety cell with crumple zones.
Standard Features:
Basic AM/FM radio with CD player, 2-4 speakers depending on trim.
Optional Features:
Upgraded audio systems, potentially auxiliary input jacks on later models.
Parking Assistance:
Rear parking sensors were an optional feature on some higher trim levels.
Bluetooth:
Generally not available from factory on most models within this range. Aftermarket solutions are common.
Dashboard Layout:
Central instrument cluster with speedometer, tachometer (optional), fuel gauge, and temperature gauge. Simple and functional.
Oil Change Interval:
Every 15,000 km (9,300 miles) or 12 months, whichever comes first.
Air Filter Replacement:
Every 30,000 km (18,600 miles) or 24 months.
Spark Plug Replacement:
Every 45,000 km (28,000 miles).
Timing Belt Replacement:
Crucial: Every 75,000 km (46,600 miles) or 5 years. Failure can cause catastrophic engine damage.
Brake Fluid Type:
DOT 3 or DOT 4.
Coolant Type:
Ethylene glycol based antifreeze, mixed 50/50 with distilled water. Check for OAT/HOAT specifications if available.
Common Wear Items:
Exhaust system components, suspension bushings, clutch wear (especially in urban use), ignition coils.
Electrical Gremlins:
Corroded ground points, faulty window regulators, and intermittent dashboard warning lights can occur.
Engine Oil Consumption:
Some owners report minor oil consumption, especially at higher mileage; regular checks are advised.
Rust Susceptibility:
Depending on climate and underbody protection, rust can affect wheel arches, sills, and exhaust components.
Manufacturer Origin:
South Korea
Parent Company Evolution:
Originally Daewoo Motor, later acquired by General Motors.
Original Launch:
The Daewoo Matiz was originally designed by Italdesign Giugiaro.
Generations Within Range:
This range primarily covers the M150 (facelifted) and M200/M250 generations.
M200 Facelift:
Introduced around 2005, featuring revised front and rear styling, and interior updates.
Production Period:
The Matiz model line existed from 1998 to 2015, with this manual covering a significant portion of its European lifecycle under the Daewoo and later Chevrolet brands.
Manufacturing Locations:
Primarily South Korea, with significant production also occurring in Poland (for European markets) and Uzbekistan.
European Market Recognition:
The Matiz was popular in many European markets for its affordability and compact size, frequently appearing on lists of best-selling city cars.
Consumer Reviews:
Generally received mixed reviews, praised for economy and maneuverability but often criticized for build quality, refinement, and safety features compared to competitors.
Emissions Standards:
Models would comply with prevailing Euro emission standards for their respective production years (e.g., Euro 3, Euro 4).
