🏷️ Basic Information

Make:

Daihatsu

Model:

Terios

Generation Code:

J100

Platform:

Daihatsu Rocky Platform

👋 Introduction

Vehicle Segment:

Compact SUV / Mini SUV

Target Audience:

Owners seeking to perform DIY maintenance and repairs, independent repair shops, enthusiasts.

Competitors Era:

Suzuki Vitara, Mitsubishi Pajero Mini, Toyota RAV4 (early generation), Honda CR-V (early generation)

Vehicle Selling Points:

Compact size, 4WD capability, rugged styling, fuel efficiency, affordability.

Benefit To Owner:

Empowers owners with comprehensive knowledge to maintain, diagnose, and repair their vehicle, saving on labor costs and ensuring longevity.

📋 Manual Details

Primary Coverage:

Complete Workshop Service and Repair

Vehicle Focus:

Daihatsu Terios J100

Estimated Pages:

Varies by edition, typically 1000+ pages for a complete factory manual

Type:

Factory Service Manual (FSM) / Workshop Repair Manual

Language:

English

Digital Format:

PDF

📖 Manual Coverage

Powertrain:

Engine Mechanical, EFI System, Emission Control, Lubrication, Cooling, Ignition, Starting, Charging, Clutch, Manual Transmission, Automatic Transmission, Transmission & Transfer, Propeller Shaft, Front & Rear Differential

Chassis:

Front Axle & Suspension, Rear Axle & Suspension, Brake (including ABS), Steering

Electrical Body:

Body, Body Electrical (including Airbag System & Immobilizer System), Harness & Wiring Diagram

Maintenance Tasks:

Scheduled maintenance, fluid changes, filter replacements, inspections

Diagnostic Procedures:

Troubleshooting guides for various systems, diagnostic trouble codes (DTCs)

Repair Operations:

Component removal, installation, overhaul, and adjustment

Calibration Settings:

Wheel alignment, brake bleeding, ABS system calibration (where applicable)

Depth:

Comprehensive, covering basic to advanced repair and diagnostic procedures, including detailed specifications and diagrams.

📊 Manual Specifications

Compatibility:

All versions of Windows & Mac

Software Requirements:

Adobe PDF Reader, WinZip (for extraction if compressed)

Printability:

All pages are printable

Digital Binding:

N/A (Digital Download)

Digital Paper Type:

N/A (Digital Download)

⚙️ Engine Specifications

Engine Code:

G13BB (Common)

Engine Type:

Inline 4-Cylinder, DOHC, 16-Valve

Displacement:

1.3 Liters (1300 cc)

Bore X Stroke:

74.0 mm x 77.0 mm (Typical)

Compression Ratio:

9.5:1 (Typical)

Horsepower:

85-90 PS (approx. 84-89 bhp) at 6000 rpm (Typical)

Torque:

115-120 Nm (approx. 85-89 lb-ft) at 3500 rpm (Typical)

Induction:

Electronic Fuel Injection (EFI)

Fuel Type:

Unleaded Gasoline (Octane rating as per local market)

Cooling Type:

Water-Cooled

Oil Type Recommendation:

API SG/SH/SJ or ACEA A2/A3, SAE 10W-30 or 10W-40 (refer to manual for specific climate recommendations)

Timing Drive:

Timing Belt

🔧 Transmission

Transmission Type:

5-Speed Manual Transmission

Transmission Type:

4-Speed Automatic Transmission

Drive System:

Part-time 4WD (with optional selectable 2WD/4WD)

Transfer Case:

Two-speed transfer case with high/low range (standard on 4WD models)

Manual Transmission Fluid:

API GL-4, SAE 75W-90 (Refer to manual for specific capacity)

Automatic Transmission Fluid:

Dexron II/III or equivalent (Refer to manual for specific capacity)

📐 Dimensions

Length:

Approx. 3,700 - 3,995 mm

Width:

Approx. 1,600 - 1,695 mm

Height:

Approx. 1,685 - 1,725 mm

Wheelbase:

Approx. 2,430 mm

Curb Weight:

Approx. 1,050 - 1,200 kg (depending on configuration)

Gross Vehicle Weight Rating:

Varies by market and model (Refer to vehicle VIN plate)

🛡️ Safety Features

Crash Test Results:

Varies by market and testing agency. Generally modest for the era.

ABS:

Available as an option on some models, covered in the manual.

Airbags:

Driver and passenger airbags (optional on some early models, standard on later/higher trims), covered in manual.

Seatbelts:

Standard 3-point seatbelts with pretensioners (front seats).

💡 Technology Features

Audio System:

Basic AM/FM radio with cassette or CD player (depending on trim/year). Aftermarket upgrades common.

ABS Availability:

Optional, becoming more prevalent on later models and higher trims.

Immobilizer System:

Included on later models, detailed in the Body Electrical section.

Airbag System:

Covered extensively in the manual, including diagnostic and repair procedures.

🔧 Maintenance

Oil Change Interval:

Every 5,000 km or 6 months, whichever comes first (Typical, consult manual for exact OEM recommendation).

Engine Oil Filter Replacement:

At every oil change.

Air Filter Replacement:

Every 20,000 km or as needed based on driving conditions (Refer to manual).

Spark Plug Replacement:

Typically every 30,000-40,000 km (depending on plug type, consult manual).

Timing Belt Replacement:

Crucial interval, typically 80,000 - 100,000 km or 5-7 years due to risk of catastrophic failure if it breaks. Manual will specify.

Coolant Type:

Ethylene Glycol based antifreeze coolant, typically a pink or red formulation (refer to manual for specific OEM approval and capacity).

Brake Fluid Type:

DOT 3 or DOT 4 (refer to manual for specific recommendation).

Power Steering Fluid Type:

DEXRON-II or equivalent (if equipped with power steering).

Common Wear Items:

Clutch wear (especially in manual models), suspension components (bushings, ball joints), exhaust system corrosion.

Engine Minor Concerns:

Minor oil leaks from gaskets, potential for exhaust manifold cracks on high-mileage vehicles. Timing belt maintenance is critical.

Electrical Quirks:

Older models may experience issues with window regulators, door lock actuators, or corrosion on electrical connectors, all detailed in the electrical section of the manual.

📚 Vehicle History

Daihatsu Specialty:

Daihatsu has a long history of producing small, fuel-efficient, and capable vehicles, often with a focus on off-road ability in their SUVs.

Terios J100 Introduction:

Launched in 1997 as a compact and affordable SUV, positioned as a more accessible alternative to larger models.

Terios J100 Facelift:

Received minor updates and styling revisions during its production run.

Production Years:

1997 - 2006

Manufacturing Locations:

Japan, and licensed production in various countries.

🏆 Awards & Recognition

Vehicle Awards:

While specific major awards for the J100 Terios are not widely publicized globally, it gained a reputation for value and capability in its segment.
