Target Audience:
DIY Enthusiasts, Independent Repair Shops, Owner seeking to maintain/repair their vehicle.
Value Proposition:
Provides the same technical information as used by dealership technicians, offering significant cost savings over professional repair services.
Accessibility:
Single, easy-to-use PDF manual, eliminating the need to search multiple physical books.
Convenience:
Printable pages allow for portability into the garage or workshop. Digital format prevents greasy pages or lost paper manuals.
Scope:
All Models & All Repairs A-Z
Detail Level:
Vehicle Specific, Dealer Technician Equivalent
Estimated Page Count:
Extensive (Detailed coverage implies hundreds to potentially thousands of pages equivalent)
Type:
Service and Repair Manual
Delivery:
Digital Download
Powertrain:
Engine, Fuel Service, Emission Control, Intake/Exhaust/Cooling, Lube, Ignition, Starting, Charging, Automatic Transmission, Manual Transmission, Transfer Case, Propeller Shaft, Drive Shaft, Differential, Axles
Chassis:
Suspension, Tire & Wheel, Brake Control, Brakes, Parking Brake, Steering Column, Power Steering
Electrical And Body:
Air Conditioning, Supplemental Restraint System (SRS), Seat Belts, Engine Immobilizer, Cruise Control, Wiper & Washer, Door Locks, Meter/Audio/Visual, Horn, Windshield/Glass/Mirror, Instrument Panel, Seats, Engine Hood/Doors, Exterior & Interior Trim, Electrical Systems, Multiplex/CAN Communication
Maintenance:
Scheduled Maintenance, Fluid Changes, Filter Replacements, Inspection Procedures
Diagnostics:
Troubleshooting Guides, Diagnostic Trouble Codes (DTCs), Symptom-Based Diagnostics
Repair:
Step-by-Step Repair Instructions for all major components and systems
Component Replacement:
Detailed procedures for replacing engine parts, transmission components, suspension parts, brake assemblies, interior/exterior panels, and electrical modules.
Depth:
Comprehensive: Covers basic maintenance, component-level diagnostics, in-depth repair procedures, and advanced system troubleshooting.
Visuals:
Includes Diagrams, Illustrations, Wiring Schematics
Compatibility:
Windows (Vista 32/64, XP, ME, 98, NT, 2000) and Mac OS
Required Software:
Adobe PDF Reader, Winzip (or equivalent decompression utility)
Printable:
Yes (All pages are printable)
Zoom Capability:
Yes (Images can be blown up for enlarged copies)
Binding:
N/A (Digital format, no physical binding)
Paper Type:
N/A (Digital format, no physical paper type)
NHTSA Front Impact Driver:
5-Star (2010 Model Year)
NHTSA Front Impact Passenger:
5-Star (2010 Model Year)
IIHS Side Impact Driver:
Good (2010 Model Year)
IIHS Side Impact Rear Passenger:
Good (2010 Model Year)
ABS:
Standard (Anti-lock Braking System)
Traction Control:
Standard (Traction Control System)
Esp:
Standard (Electronic Stability Program)
Airbags:
Front, Side, and Curtain Airbags
Seatbelts:
Front Seatbelt Pretensioners
Audio System:
Optional Boston Acoustics premium sound system, Uconnect infotainment system with voice command and Bluetooth connectivity available on higher trims.
Cruise Control:
Standard on most trims, with steering wheel controls.
Tire Pressure Monitoring:
Standard (Tire Pressure Monitoring System - TPMS)
Auxiliary Input:
Available Auxiliary audio input jack
Usb Port:
Available USB port for media playback and device charging (with Uconnect)
Oil Change Interval:
Every 6,000 miles or 6 months (severe service) / 10,000 miles or 12 months (normal service) with synthetic oil, or as per oil life monitoring system.
Tire Rotation:
Every 6,000 miles
Engine Coolant Flush:
Every 100,000 miles or 10 years for the first service, then every 50,000 miles or 5 years thereafter.
Engine Oil Type:
SAE 5W-20 (meeting Chrysler MS-6395 specification)
Engine Oil Capacity 2.4L:
Approx. 4.5 US quarts (4.3 liters)
Engine Oil Capacity 3.5L V6:
Approx. 6.0 US quarts (5.7 liters)
Coolant Type:
OAT (Organic Acid Technology) Antifreeze/Coolant, typically Mopar OAT or equivalent (color may vary, consult manual for specific type).
Common Complaints:
Power steering pump issues, HVAC system blower motor failures, suspension component wear (ball joints, control arms), transmission solenoid issues (in some cases).
Recall Information:
Specific recalls may apply; the manual would detail procedures related to addressing these.
Parent Company:
Chrysler Group LLC (now part of Stellantis)
Generation:
Second Generation (2007-2014)
Design Basis:
Based on the Chrysler JS platform, shared with vehicles like the Dodge Caliber and Jeep Patriot/Compass.
Manufacturing Location:
Sterling Heights, Michigan, USA
