Target Audience:
DIY mechanics, automotive enthusiasts, independent repair shops, and owners seeking to understand and maintain their Dodge Dart.
Advantage:
Provides dealership-level technical information, offering a significant advantage over generic repair guides. Focuses on vehicle-specific data for accurate repairs.
Content Delivery:
Single, easy-to-use PDF manual, eliminating the need to flip through multiple physical books.
Usability:
Printable pages, blow-up images, and digital storage offer flexibility and durability compared to traditional paper manuals.
Diy Advantage:
Empowers owners to perform repairs and maintenance themselves, saving money on labor costs and gaining a deeper understanding of their vehicle.
Primary Coverage:
Service and Repair
Scope:
All Models and All Repairs A-Z
Specific Coverage Examples:
Includes detailed sections on Engine Mechanical, Fuel System, Cooling, Lubrication, Ignition, Starting & Charging, Transmissions (Manual/Auto), Clutch, Drive Axle, Suspension, Steering, Brakes, HVAC, SRS, Body, Chassis Electrical, Multiplex Communications, and more.
Estimated Page Count:
Extensive (Specific count not provided, but described as comprehensive for all repairs A-Z)
Type:
Factory Service Manual
Powertrain:
Engine (all variants), Fuel System, Emission Control, Intake/Exhaust Systems, Cooling System, Lube System, Ignition System, Starting System, Charging System, Automatic Transmission, Manual Transmission, Clutch, Transfer Case (if applicable), Drive Shaft, Differential, Axles.
Chassis:
Suspension, Steering Column, Power Steering, Brakes (Hydraulic, Parking), Brake Control Systems, Wheels, Tires.
Electrical Electronics:
Electrical System, Wiring Schematics, Multiplex/CAN Communication, Engine Control System, Immobilizer System, Cruise Control, Horn, Lighting, Gauges and Instruments, Audio/Visual Systems, Power Accessories (Windows, Locks).
Body Interior Safety:
Air Conditioning System, Supplemental Restraint System (SRS/Airbags), Seat Belts, HVAC Controls, Interior Trim, Exterior Body Panels, Doors, Hood, Glass, Mirrors, Wiper and Washer Systems, Seats.
Maintenance:
Routine maintenance, fluid changes, filter replacements, inspection procedures.
Diagnostics:
Troubleshooting guides, diagnostic trouble codes (DTCs), symptom-based diagnostics.
Repair:
Step-by-step repair procedures for all major and minor components and systems, including disassembly, assembly, and adjustment.
Specifications:
Torque specifications, clearances, fluid types and capacities, electrical values, emissions data.
Engine Repair:
Complete engine overhaul procedures, cylinder head removal/installation, piston/ring replacement, crankshaft/bearing service, timing belt/chain replacement (if applicable).
Brake Repair:
Front and rear brake pad/rotor replacement, caliper service, brake line bleeding, parking brake adjustment and repair.
Electrical Diagnostics:
Step-by-step troubleshooting for electrical faults, including pinpoint tests, component testing, and detailed wiring diagrams for every system.
Depth:
Comprehensive: From basic maintenance to in-depth diagnostics and complete component overhauls. Vehicle-specific, not generic.
Searchability:
Likely searchable text within the PDF, enabling quick access to information.
Printability:
Fully printable, allowing users to print specific pages or sections for workshop use.
Scalability:
Illustrations and diagrams can be blown up for enlarged printing.
Type:
Digital (no physical binding)
Digital Equivalent:
Not applicable; digital format provides a clean, non-greasy experience.
Operating Systems:
Windows (Vista 32/64, XP, ME, 98, NT, 2000), Mac Compatible.
Software:
Adobe PDF Reader, Winzip (or equivalent unzipping software).
Engine Options:
Likely includes 1.4L Multi-Air Turbo I4, 2.0L Tigershark I4, and 2.4L Tigershark I4 engines.
Horsepower Torque:
Specific figures vary by engine option (e.g., 1.4L Turbo ~160 hp, 2.4L ~184 hp). Manual will detail exact specs and performance data for each variant.
System Type:
Fuel injection (likely multi-port or direct injection depending on engine). Manual will detail fuel pump, injectors, pressure regulator, and system diagnostics.
ECU Details:
Details on Engine Control Unit (ECU) operation, sensor inputs, and output controls will be present, along with wiring schematics for the engine control system.
Common Engine Codes:
Manual will reference specific engine codes (e.g., E.O. for 1.4L Multi-Air Turbo, E.C. for 2.0L, E.D. for 2.4L Tigershark) for precise identification and service.
Transmission Types:
Manual transmission (e.g., 6-speed) and automatic transmission (e.g., 6-speed dual-clutch or conventional automatic).
Optional Transmission:
The manual will cover all factory-offered transmission variants for the 2013-2016 Dart.
Transmission Service:
Procedures for clutch replacement, transmission fluid changes (including type and capacity), internal component repair, and diagnostic procedures for both manual and automatic transmissions.
Wheelbase:
Approximately 106.4 inches (2703 mm).
Length:
Approximately 177.0 inches (4496 mm).
Width:
Approximately 70.2 inches (1783 mm).
Height:
Approximately 57.7 inches (1466 mm).
Curb Weight:
Varies by configuration, typically ranging from approximately 3,000 to 3,300 lbs (1361 to 1497 kg).
Gross Vehicle Weight Rating:
Specific GVWRs will be detailed in the manual for each configuration.
NHTSA Ratings:
The manual will contain information related to the vehicle's safety structure and systems, which contribute to its NHTSA and IIHS ratings. Specific ratings vary by model year and equipment.
Active Safety Systems:
Coverage of ABS, Traction Control (TCS), Electronic Stability Control (ESC), and potentially driver-assist features if equipped.
Passive Safety Systems:
Detailed information on airbags (front, side, curtain), seat belt pre-tensioners, and the Supplemental Restraint System (SRS) control module and wiring.
Uconnect System:
The manual will cover the operation and potential troubleshooting of the Uconnect infotainment system, including touchscreen interfaces, audio, navigation (if equipped), and Bluetooth connectivity.
Available Features:
Information regarding available features like rearview cameras, parking sensors, and potentially blind-spot monitoring or cross-path detection will be included in the electrical and diagnostic sections.
Multiplex Can Bus:
Detailed wiring schematics and explanations of the vehicle's CAN (Controller Area Network) bus system, crucial for diagnosing communication issues between modules.
Oil Change Interval:
Typically 8,000 to 10,000 miles or 12 months, depending on driving conditions and oil type. Specific intervals detailed in the manual.
Tire Rotation:
Recommended every 6,000 to 8,000 miles.
Major Service:
The manual will outline intervals for spark plug replacement, coolant flush, brake fluid change, and other major maintenance items based on mileage and time.
Engine Oil:
Likely SAE 0W-20 synthetic or synthetic blend, meeting Chrysler MS-6395 specification. Manual will confirm exact type and capacity per engine.
Coolant:
Mopar OAT (Orange) or equivalent HOAT coolant meeting Chrysler MS-9769 specification. Manual will provide capacity and flush intervals.
Transmission Fluid Atf:
Specific ATF type for automatic transmissions (e.g., ATF+4 or equivalent) and gear oil for manual transmissions. Capacities and change intervals will be listed.
Brake Fluid:
Likely DOT 3 or DOT 4 brake fluid. Manual will specify type and capacity for bleeding.
Common Problems:
The manual may implicitly address common issues through detailed diagnostic procedures. Potential areas of concern for this model might include early transmission issues (especially DCTs), HVAC system performance, and some electrical gremlins. The manual's detailed troubleshooting will be invaluable for these.
Dodge Legacy:
The Dodge Dart nameplate has historical significance within Chrysler's product lineup, with this modern iteration aiming to revive the brand's presence in the compact sedan segment.
Dart Generation:
This generation of the Dodge Dart (2013-2016) was a significant undertaking, designed on Fiat Chrysler Automobiles' (FCA) Global Small Wide Architecture, shared with other Alfa Romeo and Fiat models.
Manufacturing Location:
The Dodge Dart was primarily manufactured at the Belvidere Assembly Plant in Belvidere, Illinois, USA.
