🏷️ Basic Information

Make:

Dodge

Model:

Journey

Year:

2009-2010

Platform:

JC platform

Chassis Code:

JC

👋 Introduction

Vehicle Segment:

Mid-size Crossover SUV

Target Audience:

Families, individuals seeking versatile cargo and passenger space with car-like driving dynamics.

Key Competitors:

Toyota Highlander, Honda Pilot, Ford Edge, Chevrolet Equinox, Nissan Murano.

Versatility:

Flexible seating configurations (5-seater and optional 7-seater), generous cargo space, optional all-wheel drive.

Value Proposition:

Offered a compelling blend of space, utility, and affordability within its segment.

📋 Manual Details

Systems Covered:

Engine Mechanical, Engine Performance, Transmissions (Automatic), Brakes, Steering, Suspension, Climate Control (HVAC), Electrical System, Body & Frame, Interior Systems, Exterior Trim, Safety Systems (SRS, ABS), Diagnostic Procedures, Maintenance Schedules, Wiring Diagrams, Torque Specifications, Diagnostic Trouble Codes (DTCs)

Page Count:

Extensive (specific count not provided, typical factory manuals are 1000+ pages)

Manual Type:

Factory Service Repair Manual

Language:

English

Format:

Digital (PDF)

📖 Manual Coverage

Engine Mechanical:

Complete overhaul procedures for all engine variants, including cylinder head, pistons, crankshaft, camshafts, timing, lubrication, and cooling systems.

Engine Performance:

Fuel injection, ignition system, emission controls, turbocharging (if applicable), engine diagnostics, and troubleshooting.

Transmission:

Detailed repair procedures for the automatic transmission, including valve body, torque converter, clutch packs, and electronic controls. Fluid specifications and fill procedures.

Brakes:

Diagnosis and repair of ABS, EBD, brake system bleeding, component replacement (calipers, rotors, pads), and parking brake systems.

Suspension Steering:

Front and rear suspension component diagnosis and replacement, alignment specifications, power steering system service, and steering column repairs.

Electrical System:

Complete wiring diagrams for all circuits, fuse and relay locations, diagnostic procedures for lighting, power accessories, sensors, and ECUs.

HVAC:

Air conditioning system service, refrigerant handling, heater core replacement, blower motor, and climate control unit diagnostics.

Body Frame:

Panel replacement procedures, structural repair guidelines, door and hinge adjustments, glass replacement, and interior trim removal/installation.

Safety Systems:

Airbag system diagnosis and replacement, seat belt service, SRS module troubleshooting, and seat sensor systems.

Maintenance:

Scheduled maintenance items, oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, and belt inspections.

Troubleshooting:

Systematic diagnostic flowcharts for common drivability, electrical, and mechanical issues, including DTC interpretation.

Repair:

Step-by-step repair instructions for all major vehicle components, including disassembly, component replacement, reassembly, and final testing.

Diagnostics:

Detailed procedures for using diagnostic scan tools, interpreting live data, performing actuator tests, and identifying faulty components.

Depth:

Comprehensive, from basic fluid level checks to complete engine and transmission overhauls, including electronic module programming and diagnostics.

📊 Manual Specifications

File Format:

PDF (Portable Document Format)

Searchability:

Searchable text for quick information retrieval.

Printability:

Printable pages for field use.

Quality:

High-resolution scans of original factory documentation, ensuring clarity of diagrams and text.

Binding Type:

N/A (Digital Format)

Paper Type:

N/A (Digital Format)

⚙️ Engine Specifications

Engine Code 2009 2010 V6:

EGV (3.5L Pentastar V6)

Engine Type 2009 2010 V6:

SOHC V6

Displacement 2009 2010 V6:

3.5 Liters (3518 cc)

Horsepower 2009 2010 V6:

235 hp @ 6400 rpm

Torque 2009 2010 V6:

232 lb-ft @ 4000 rpm

Fuel System V6:

Sequential Multi-Port Fuel Injection (MPI)

Engine Code 2009 4Cyl:

KPT (2.4L World Engine)

Engine Type 2009 4Cyl:

DOHC Inline-4

Displacement 2009 4Cyl:

2.4 Liters (2360 cc)

Horsepower 2009 4Cyl:

173 hp @ 6000 rpm

Torque 2009 4Cyl:

165 lb-ft @ 4000 rpm

Fuel System 4Cyl:

Multi-Point Fuel Injection (MPI)

Emission Controls:

California/Federal Tier 2 Bin 5, OBD-II compliant

🔧 Transmission

Transmission Type V6:

6-speed automatic (Autostick capability)

Transmission Type 4Cyl:

4-speed automatic

Drivetrain Options:

Front-Wheel Drive (FWD), All-Wheel Drive (AWD)

Transmission Fluid V6:

ATF+4 (Mopar specification)

Transmission Fluid 4Cyl:

ATF+4 (Mopar specification)

📐 Dimensions

Length:

188.8 inches (4796 mm)

Width:

72.5 inches (1842 mm)

Height:

66.1 inches (1679 mm)

Wheelbase:

113.8 inches (2891 mm)

Ground Clearance:

7.2 inches (183 mm)

Curb Weight FWD 4Cyl:

Approx. 3,770 lbs (1710 kg)

Curb Weight FWD V6:

Approx. 4,050 lbs (1837 kg)

Curb Weight AWD V6:

Approx. 4,280 lbs (1941 kg)

Cargo Volume Behind 3Rd Row:

Approx. 19.6 cu ft (555 L)

Cargo Volume Behind 2Nd Row:

Approx. 37.7 cu ft (1068 L)

Cargo Volume Behind 1St Row:

Approx. 68.6 cu ft (1943 L)

🛡️ Safety Features

NHTSA Front Crash Test:

5-Star (Driver & Passenger)

NHTSA Side Crash Test:

5-Star (Front & Rear Seat)

IIHS Front Overlap Test:

Good

IIHS Side Impact Test:

Good

ABS:

Standard 4-wheel Anti-lock Braking System (ABS)

Traction Control:

Standard Traction Control (TCS)

Electronic Stability Control:

Standard Electronic Stability Control (ESC) with electronic roll mitigation

Airbags Front:

Standard advanced multi-stage front airbags

Airbags Side:

Standard front seat-mounted side airbags

Airbags Curtain:

Standard full-length side-curtain airbags with rollover protection

Seatbelts:

3-point seat belts with pretensioners and load limiters

💡 Technology Features

Infotainment System:

Uconnect multimedia system with touch screen, available navigation, Bluetooth connectivity, and satellite radio.

Audio Options:

Available premium audio systems (e.g., Boston Acoustics).

Parking Assist:

Available rear park assist system with audible warnings.

Connectivity Features:

Available Bluetooth streaming audio and hands-free calling, USB input for media devices.

🔧 Maintenance

Oil Change Interval Synthetic:

7,500 miles (12,000 km) or 6 months (whichever comes first) with synthetic oil.

Oil Change Interval Conventional:

3,000 miles (5,000 km) or 3 months (whichever comes first) with conventional oil.

Engine Air Filter Replacement:

Every 15,000 - 30,000 miles (24,000 - 48,000 km), depending on driving conditions.

Cabin Air Filter Replacement:

Every 15,000 - 30,000 miles (24,000 - 48,000 km), depending on driving conditions.

Spark Plug Replacement V6:

Approx. 100,000 miles (160,000 km) with original equipment iridium plugs.

Transmission Fluid Service:

Recommended every 60,000 miles (96,000 km) for optimal performance.

Engine Oil Type:

SAE 5W-30 (API SN or newer)

Engine Oil Capacity V6:

5.0 US quarts (4.7 Liters)

Engine Oil Capacity 4Cyl:

4.0 US quarts (3.8 Liters)

Coolant Type:

Mopar HOAT (Hybrid Organic Acid Technology) Antifreeze/Coolant, OAT compatible (refer to manual for specific color/type).

Brake Fluid Type:

DOT 3

Common Problem HVAC:

Blend door actuator failures causing improper temperature control or airflow direction.

Common Problem Electrical:

Power window regulator failures, occasional issues with infotainment system responsiveness.

Common Problem Suspension:

Front suspension component wear (struts, ball joints) leading to noise or alignment issues.

Common Problem Engine:

Oil leaks from valve cover gaskets or oil pan on higher mileage vehicles. Occasional issues with the intake manifold runner control on V6 engines.

📚 Vehicle History

Brand Origin:

Dodge is an American brand with a long history in automotive manufacturing, known for performance and utility vehicles.

Introduction Year:

2008 (as a 2009 model year)

Design Inspiration:

Designed to offer a blend of minivan practicality, SUV capability, and car-like handling.

Manufacturing Plant:

Stirling Assembly Plant, Brampton, Ontario, Canada

Production Duration:

2008-2020 (for the Dodge Journey nameplate)

🏆 Awards & Recognition

Safety Award 2009:

IIHS Top Safety Pick (for 2009 models)

Safety Award 2010:

IIHS Top Safety Pick (for 2010 models)

Consumer Reports Reliability:

Variable (refer to specific year reviews; some years had better reliability than others, the manual provides the means to address these).
