DODGE JOURNEY 2009-2010 Full Service Repair Manual
- 常规价格
- $17.99
- 促销价
- $17.99
- 常规价格
-
- 单价
- / 单价
🏷️ Basic Information Identification Make: Dodge Model: Journey Model Years Covered: 2009-2010 Platform: JS platform Codes Chassis Code: JC49 👋 Introduction Market Position Vehicle Segment: Mid-size Crossover SUV (CUV) Target...
20 people are viewing this right now
类型: Car
厂商:
斯库: 584521
无法加载取货服务可用情况
共享
🏷️ Basic Information
Identification
Make:
Dodge
Model:
Journey
Model Years Covered:
2009-2010
Platform:
JS platform
Codes
Chassis Code:
JC49
👋 Introduction
Market Position
Vehicle Segment:
Mid-size Crossover SUV (CUV)
Target Audience:
Families, individuals seeking versatility and practicality.
Competitive Analysis
Key Competitors:
Toyota RAV4, Honda CR-V, Ford Edge, Chevrolet Equinox.
Key Features
Seating Capacity:
Available in 5-seater and 7-seater configurations.
Versatility:
Flexible interior, available AWD, integrated stroller/child seat options (specific trims).
Value Proposition:
Affordable pricing and good feature set for its class.
📋 Manual Details
Coverage Areas
Primary Coverage:
Comprehensive service and repair for Dodge Journey 2009-2010 models.
Additional Coverage:
Includes troubleshooting, diagnostics, maintenance, and component repair.
Page Count
Estimated Pages:
1500+
Manual Type
Type:
Full Service & Repair Manual
Content Type:
Technical Service Manual (TSM) / Factory Service Manual (FSM) equivalent.
Language
Language:
English
Format
Format:
Digital (PDF)
📖 Manual Coverage
Systems Covered
Engine Mechanical:
Engine overhaul, timing systems, lubrication, cooling, fuel delivery.
Engine Performance:
Engine control modules (ECM), ignition system, emissions control.
Transmission Automatic:
4-speed automatic (40TE/41TE), disassembly, assembly, diagnostics, repair.
Transmission Manual:
6-speed manual (Getrag), disassembly, assembly, diagnostics, repair (if applicable to specific trims/engines).
Drivetrain:
Front-wheel drive (FWD), All-wheel drive (AWD) system, CV joints, propeller shafts, differentials.
Brakes:
Hydraulic system, ABS, EBD, brake pad/rotor replacement, caliper service, hydraulic lines.
Suspension:
Front independent suspension (MacPherson struts), Rear multi-link suspension, shock absorbers, springs, control arms.
Steering:
Power steering system, steering column, rack and pinion assembly.
Electrical:
Battery, charging system, starting system, lighting, accessories, wiring diagrams, fuses, relays.
Body Interior:
Interior trim removal/installation, seats, dashboard, door panels, headliner.
Body Exterior:
Body panel removal/installation, bumpers, doors, hood, liftgate, glass replacement.
HVAC:
Heating, ventilation, air conditioning system, refrigerant, blower motor, evaporator, condenser.
Safety Systems:
Airbag system (SRS), seat belt mechanisms, diagnostic procedures.
Procedures Included
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, spark plug replacement, belt inspection/replacement.
Troubleshooting:
Systematic diagnostic flowcharts for common and uncommon problems.
Repair:
Detailed step-by-step repair instructions for all major components.
Rebuild:
Comprehensive procedures for engine and transmission overhauls.
Diagnostics:
OBD-II diagnosis, specific trouble code (DTC) explanations and resolution.
Electrical Diagnostics:
Component testing, wiring harness repair, signal tracing.
Body Repair:
Dent repair, panel alignment, rust prevention, sealant application.
Technical Depth
Depth:
Expert level, covering everything from basic maintenance to full component rebuilds and complex electrical diagnostics.
Diagrams:
Includes detailed wiring diagrams, component schematics, and exploded views.
Specifications:
Torque specifications for all fasteners, clearances, and measurements.
📊 Manual Specifications
File Format
Digital Format:
Searchable PDF
Print Capability:
Printable pages
Navigation:
Hyperlinked table of contents and index for easy navigation.
Print Quality
Image Resolution:
High-resolution for clear diagrams and illustrations.
Binding Type
Binding:
N/A (Digital Format)
Paper Type
Paper Quality:
N/A (Digital Format)
⚙️ Engine Specifications
Primary Engine
Engine 1 Displacement:
2.4L (2360cc)
Engine 1 Configuration:
Inline-4 (I4), DOHC, 16-valve
Engine 1 Engine Code:
KICKER (2.4L World Engine)
Engine 1 Horsepower:
173 hp @ 6000 rpm
Engine 1 Torque:
166 lb-ft @ 4000 rpm
Optional Engine
Engine 2 Displacement:
3.5L (3497cc)
Engine 2 Configuration:
V6 (90-degree), DOHC, 24-valve
Engine 2 Engine Code:
N/A (Pentastar V6 variant)
Engine 2 Horsepower:
235 hp @ 6750 rpm
Engine 2 Torque:
250 lb-ft @ 4000 rpm
Fuel System
Fuel Delivery:
Electronic Multi-Point Fuel Injection (MPI)
Fuel Type:
Unleaded gasoline
Emission Control:
Catalytic converter, On-Board Diagnostics (OBD-II)
🔧 Transmission
Standard
Transmission Type 2.4L:
4-speed automatic (40TE/41TE)
Optional
Transmission Type 3.5L:
6-speed automatic (40TE/41TE variant, some models may differ)
AWD Availability:
Available on 3.5L V6 models.
Features
Transmission Fluid 2.4L:
Mopar ATF+4 (or equivalent specification)
Transmission Fluid 3.5L:
Mopar ATF+4 (or equivalent specification)
📐 Dimensions
Exterior
Length:
188.8 inches (4796 mm)
Width:
72.5 inches (1842 mm)
Height:
66.6 inches (1692 mm)
Wheelbase:
113.8 inches (2891 mm)
Interior
Passenger Volume:
Approximately 112.1 cubic feet (3174 liters)
Cargo
Cargo Volume Behind 3Rd Row:
Approx. 19.6 cubic feet (555 liters)
Cargo Volume Behind 2Nd Row:
Approx. 40.5 cubic feet (1147 liters)
Cargo Volume Behind 1St Row:
Approx. 68.7 cubic feet (1946 liters)
Weights
Curb Weight 2.4L FWD:
Approx. 3,940 lbs (1787 kg)
Curb Weight 3.5L AWD:
Approx. 4,250 lbs (1928 kg)
Gross Vehicle Weight Rating Gvwr:
Varies by configuration, typically around 5500-5700 lbs.
🛡️ Safety Features
Ratings
NHTSA Frontal Crash Rating Driver:
Five-star (for the specific model years covered).
NHTSA Frontal Crash Rating Passenger:
Five-star (for the specific model years covered).
NHTSA Side Crash Rating Front Seat:
Five-star (for the specific model years covered).
NHTSA Side Crash Rating Rear Seat:
Five-star (for the specific model years covered).
IIHS Frontal Offset Score:
Good (for the specific model years covered).
Active Features
ABS:
Standard Anti-lock Braking System (ABS)
Traction Control:
Standard Traction Control (TCS)
Electronic Stability Control:
Standard Electronic Stability Control (ESC)
Passive Features
Airbags Front:
Advanced multi-stage front airbags
Airbags Side:
Front seat-mounted side airbags
Airbags Curtain:
Full-length side-curtain airbags for all rows
Seat Belts:
3-point seat belts with pretensioners
💡 Technology Features
Infotainment
Infotainment System:
Available Uconnect infotainment system with touchscreen display, AM/FM/CD/DVD/MP3 player.
Navigation:
Optional GPS navigation system.
Audio System:
Available premium audio systems, including Boston Acoustics.
Driver Assistance
Rearview Camera:
Available rear backup camera.
Parking Sensors:
Available rear park assist system.
Connectivity
Bluetooth:
Available Bluetooth hands-free calling and audio streaming.
Usb Port:
Available USB input for media devices.
🔧 Maintenance
Service Intervals
Oil Change Interval:
Every 6,000 miles (9,656 km) or 6 months, whichever comes first (under normal driving conditions).
Engine Air Filter Replacement:
Every 30,000 miles (48,280 km) or 3 years.
Cabin Air Filter Replacement:
Every 12,000 miles (19,312 km) or 1 year.
Spark Plug Replacement 2.4L:
Every 100,000 miles (160,934 km) (Platinum-tipped)
Spark Plug Replacement 3.5L:
Every 100,000 miles (160,934 km) (Iridium-tipped)
Transmission Fluid Change:
Every 60,000 miles (96,560 km) or 5 years (under normal conditions).
Fluid Specifications
Engine Oil Specification:
SAE 5W-30, API SN or newer, ILSAC GF-5 certified.
Engine Oil Capacity 2.4L:
4.5 US quarts (4.3 liters) with filter change.
Engine Oil Capacity 3.5L:
5.5 US quarts (5.2 liters) with filter change.
Coolant Type:
Mopar OAT (Orange) Antifreeze/Coolant, 5-Year/100,000-Mile Formula.
Brake Fluid Type:
DOT 3
Known Issues
Common Issue Vibration:
Driveshaft balance issues (especially on AWD models), leading to vibrations at certain speeds.
Common Issue HVAC:
Blend door actuator failure causing HVAC temperature control problems.
Common Issue Suspension:
Premature wear of front suspension components like ball joints and control arm bushings.
Common Issue Engine Mounts:
Degradation of engine mounts, leading to increased vibration and noise.
Common Issue Transmission:
Occasional rough shifting or delayed engagement, particularly in the 4-speed automatic.
📚 Vehicle History
Brand Heritage
Brand Legacy:
Dodge, an American brand with a history of performance and utility vehicles under Chrysler.
Model Evolution
First Generation Introduction:
2009 model year.
Platform Origin:
Based on Chrysler's Global Crossover Platform (JS).
Design Philosophy:
Designed to be a versatile family vehicle combining SUV styling with minivan practicality.
Production
Assembly Location:
Stirling Plant, Brampton, Ontario, Canada.
Production Period:
2008-2010 for the initial model years covered by this manual.
🏆 Awards & Recognition
Recognitions
Safety Awards:
Achieved top safety ratings from NHTSA and IIHS for the model years.
Ratings
Family Vehicle Recognition:
Often cited for its family-friendly features and practicality within its segment.
Certifications
Epa Fuel Economy 2.4L FWD:
Est. 19 MPG city / 25 MPG highway.
Epa Fuel Economy 3.5L FWD:
Est. 17 MPG city / 23 MPG highway.
Epa Fuel Economy 3.5L AWD:
Est. 16 MPG city / 22 MPG highway.
