🏷️ Basic Information

Make:

Dodge

Model:

Journey

Year:

2015

Platform:

JCUV (Dodge's internal designation for the Journey platform)

Chassis Code:

PM (for the 2015 model year)

👋 Introduction

Segment:

Mid-size Crossover SUV (CUV).

Target Audience:

Families and individuals seeking versatile, comfortable, and practical transportation with available AWD and three-row seating.

Key Competitors:

Toyota Highlander, Honda Pilot, Ford Explorer, Chevrolet Traverse, Kia Sorento, Hyundai Santa Fe.

Seating Capacity:

Available 5 or 7-passenger seating configuration with optional third-row bench.

Cargo Volume:

Flexible cargo space with fold-flat second and third-row seats.

Powertrain Options:

Choice between fuel-efficient four-cylinder and powerful V6 engines, with FWD and AWD options.

Interior Amenities:

Focus on comfort, convenience, and available family-oriented features like dual-zone climate control and rear-seat entertainment.

📋 Manual Details

Coverage Focus:

Comprehensive service and repair for all systems of the 2015 Dodge Journey.

Trim Level Coverage:

All trim levels, including SE, SXT, Crossroad, Limited, and R/T.

Page Count:

Approximately 2000+ pages (typical for comprehensive factory service manuals).

Manual Type:

Factory Authorized Service and Repair Manual.

Language:

English

Format:

Digital Download (PDF) or Printed Book.

📖 Manual Coverage

Engine Mechanical:

Detailed diagnostics, repair, and overhaul for 2.4L I4 (TigerShark) and 3.6L V6 (Pentastar) engines. Includes timing system, cylinder head, block assembly, lubrication system, cooling system, fuel delivery, and exhaust system.

Transmission Automatic:

Complete coverage for the 62TE 6-speed automatic transmission. Includes diagnostics, fluid service, valve body repair, torque converter replacement, and internal component overhaul.

Drivetrain:

Front-wheel drive (FWD) and All-wheel drive (AWD) systems. Includes CV joints, propeller shaft, rear differential, and transfer case.

Suspension:

Front and rear suspension components. Includes struts, shock absorbers, control arms, ball joints, bushings, sway bars, and wheel bearings. Alignment specifications included.

Brakes:

Hydraulic brake system, ABS, Traction Control, Electronic Stability Control (ESC). Includes brake rotor and pad replacement, caliper service, brake fluid flush, and bleed procedures. Diagnostic Trouble Codes (DTCs) related to braking systems.

Steering:

Power steering system (electric power steering - EPS for many models). Includes steering column, rack and pinion assembly, and power steering pump/motor (if applicable).

Electrical System:

Complete electrical schematics, component locations, wiring diagrams for all systems. Includes battery, charging system, starter, lighting, power windows, locks, seats, and accessories.

HVAC:

Heating, Ventilation, and Air Conditioning (HVAC) system. Includes refrigerant system, compressor, condenser, evaporator, blower motor, climate control module, and diagnosis of airflow and temperature issues.

Body Interior:

Interior trim removal and installation, seating systems, dashboard, door panels, headliner, and body sealing.

Body Exterior:

Exterior body panels, doors, hood, liftgate, bumpers, glass replacement, and trim pieces. Includes panel alignment and hardware specifications.

Restraint Systems:

Airbag system, seat belts, and SRS module. Includes diagnostic procedures and replacement of SRS components.

Infotainment And Navigation:

Uconnect system, radio, navigation, display screen, and associated modules. Basic troubleshooting and component replacement.

Body Control Module Bcm:

Diagnosis and programming of the Body Control Module and related functions.

Preventative Maintenance:

Scheduled maintenance tasks, oil changes, filter replacements, fluid checks, tire rotation, and inspections.

Troubleshooting:

Systematic diagnostic procedures for common and complex problems, including symptom-based diagnostics and DTC interpretation.

Repair And Replacement:

Step-by-step instructions for removing, installing, and repairing all major vehicle components.

Disassembly And Assembly:

Detailed instructions for engine, transmission, and component disassembly and reassembly with torque specifications.

Diagnostics And Testing:

Procedures for using diagnostic tools (like scan tools), testing electrical circuits, sensors, actuators, and mechanical components.

Specifications And Tolerances:

All necessary technical specifications, torque values, clearances, and fluid capacities.

Depth Of Information:

Full factory-level repair procedures, including component-level diagnostics, rebuilding procedures, and advanced electrical troubleshooting.

Diagnostic Charts:

Includes detailed diagnostic flowcharts and symptom-to-cause analysis for various issues.

Wiring Diagrams:

High-quality, detailed electrical wiring diagrams with component identification and connector pinouts.

📊 Manual Specifications

Digital Format:

Searchable PDF with hyperlinked table of contents for easy navigation.

Print Quality:

High-resolution scans of original factory manuals, ensuring clear text and diagrams.

Printed Binding:

Professionally bound for durability in a workshop environment.

Printed Paper:

Durable, high-quality paper designed to withstand frequent use and exposure to shop conditions.

⚙️ Engine Specifications

Engine 1 Name:

2.4L DOHC 16-Valve I4 (TigerShark)

Engine 1 Displacement:

2360 cc (144 cubic inches)

Engine 1 Bore X Stroke:

88.0 mm x 97.0 mm

Engine 1 Horsepower:

173 hp @ 6,000 RPM

Engine 1 Torque:

166 lb-ft @ 4,400 RPM

Engine 1 Compression Ratio:

10.0:1

Engine 1 Timing System:

Dual Variable Valve Timing (VVT).

Engine 2 Name:

3.6L DOHC 24-Valve V6 (Pentastar)

Engine 2 Displacement:

3604 cc (220 cubic inches)

Engine 2 Bore X Stroke:

96.0 mm x 83.1 mm

Engine 2 Horsepower:

283 hp @ 6,400 RPM

Engine 2 Torque:

260 lb-ft @ 4,400 RPM

Engine 2 Compression Ratio:

10.0:1

Engine 2 Timing System:

Dual Variable Valve Timing (VVT).

Fuel Induction:

Sequential Multi-Port Fuel Injection (MPI).

Fuel Type:

Unleaded gasoline.

Fuel Octane Rating:

87 octane recommended (91 octane for optimal performance with 3.6L V6).

🔧 Transmission

Transmission Type 1:

6-speed automatic (62TE)

Drive Layout 1:

Front-Wheel Drive (FWD) standard on most trims.

Transmission Type 2:

6-speed automatic (62TE)

Drive Layout 2:

All-Wheel Drive (AWD) available, particularly with the 3.6L V6 engine.

Transmission Fluid:

Mopar ATF+4 or equivalent.

Transmission Fluid Capacity:

Approximately 8.0 quarts (7.6 liters) for fluid change, 10.4 quarts (9.8 liters) for complete overhaul.

📐 Dimensions

Length:

192.4 inches (4887 mm)

Width:

72.5 inches (1841 mm) (excluding mirrors)

Height:

67.1 inches (1704 mm)

Wheelbase:

113.8 inches (2891 mm)

Passenger Volume:

Approximately 120.3 cubic feet (3407 liters)

Cargo Volume Behind 3Rd Row:

Approx. 12.2 cubic feet (345 liters)

Cargo Volume Behind 2Nd Row:

Approx. 37.7 cubic feet (1068 liters)

Cargo Volume Behind 1St Row:

Approx. 68.3 cubic feet (1934 liters)

Curb Weight Min:

Approx. 3,900 lbs (1769 kg) for base FWD models.

Curb Weight Max:

Approx. 4,300 lbs (1950 kg) for AWD V6 models.

Gross Vehicle Weight Rating Gvwr:

Approx. 5,775 lbs (2619 kg)

Towing Capacity:

Up to 2,000 lbs (907 kg) when properly equipped (with V6 engine and tow package).

🛡️ Safety Features

NHTSA Overall:

4 out of 5 stars (for 2015 models).

IIHS Top Safety Pick:

None specifically designated as Top Safety Pick in 2015, but generally performed well in crash tests.

Electronic Stability Control:

Standard.

Traction Control:

Standard.

Antilock Braking System:

Standard (4-wheel disc brakes).

Brake Assist:

Standard.

Tire Pressure Monitoring System:

Standard.

Airbags:

Driver and front-passenger advanced multi-stage airbags, driver's knee airbag, front-seat mounted side airbags, and roof-mounted side-curtain airbags for all rows.

Seat Belts:

3-point seat belts with pretensioners and load limiters.

Child Seat Anchors:

LATCH (Lower Anchors and Tethers for Children) system.

💡 Technology Features

Infotainment System:

Uconnect system with touchscreen display (5-inch or 8.4-inch depending on trim/options).

Audio Options:

AM/FM/SiriusXM Satellite Radio, CD/DVD player (optional), USB and Auxiliary input jacks.

Available Features 1:

Rearview camera.

Available Features 2:

ParkView rear backup camera.

Available Features 3:

ParkSense rear park assist.

Connectivity Features:

Bluetooth streaming audio and hands-free calling, USB charging ports.

Navigation:

Available integrated navigation system with SiriusXM Traffic and Travel Link.

🔧 Maintenance

Oil Change Interval:

Every 10,000 miles (16,000 km) or 12 months, whichever comes first (using synthetic oil and oil filter).

Engine Air Filter Replacement:

Every 30,000 miles (48,000 km) or as needed based on inspection.

Cabin Air Filter Replacement:

Every 15,000 miles (24,000 km) or 12 months.

Transmission Fluid Change:

Every 60,000 miles (96,000 km) for normal service, or 30,000 miles (48,000 km) for severe service/towing.

Coolant Flush:

Every 100,000 miles (160,000 km) or 5 years, whichever comes first.

Spark Plug Replacement 4 Cyl:

Every 100,000 miles (160,000 km) (Iridium tipped).

Spark Plug Replacement 6 Cyl:

Every 100,000 miles (160,000 km) (Iridium tipped).

Engine Oil Type:

SAE 0W-20 Full Synthetic (API Certified).

Engine Oil Capacity 4 Cyl:

4.5 quarts (4.3 liters)

Engine Oil Capacity 6 Cyl:

6.0 quarts (5.7 liters)

Coolant Type:

Mopar OAT (Organic Additive Technology) Antifreeze/Coolant, Pink.

Brake Fluid Type:

DOT 3 or DOT 4.

Common Issue 1:

Water pump leaks (especially on 3.6L Pentastar V6).

Common Issue 2:

Transmission shift quality issues or torque converter shudder.

Common Issue 3:

Suspension component wear (e.g., ball joints, control arm bushings).

Common Issue 4:

Power door lock actuators failing.

Common Issue 5:

HVAC blower motor resistor failure.

Common Issue 6:

Check engine lights related to evaporative emission system (EVAP) leaks.

📚 Vehicle History

Brand Origin:

Dodge is an American automotive brand founded in 1900 by John and Horace Dodge, originally as a supplier of parts and transmissions for Ford.

First Generation:

Introduced for the 2009 model year as a 2009 Dodge Journey.

Platform Basis:

Based on the DaimlerChrysler platform shared with vehicles like the Chrysler Sebring and Avenger (platform code JS).

2011 Facelift:

Received a significant refresh for the 2011 model year, improving interior quality, powertrain options (introduction of the Pentastar V6), suspension tuning, and exterior styling.

2015 Updates:

The 2015 model year saw minor updates, including new trim levels like the 'Crossroad' and minor feature packaging adjustments. Powertrain remained largely consistent with the 2011-2014 models.

Assembly Plant:

Belvidere Assembly Plant, Belvidere, Illinois, USA.

Production Years:

2009 - 2020 (North American market).

🏆 Awards & Recognition

Kbb Best Family Cars:

Has been recognized in Kelley Blue Book's '10 Best Family Cars' lists in previous years, highlighting its practicality and family-oriented features.

Consumer Reports Ratings:

Received average to above-average predicted reliability ratings from Consumer Reports in some model years, though specific ratings can vary annually.
