Vehicle Segment:
Compact Crossover SUV
Competitors:
Jeep Liberty (shares platform), Toyota RAV4, Honda CR-V, Ford Escape.
Unique Selling Points:
Rugged styling, available V6 engines, SUV versatility with a more aggressive aesthetic.
Primary Users:
Professional mechanics, DIY enthusiasts, and owners seeking in-depth vehicle knowledge.
Benefits For Owner:
Enables efficient maintenance, proactive issue resolution, and informed repair decisions, potentially saving on labor costs.
Engine Mechanical:
Detailed repair and overhaul procedures for all engine variants.
Engine Management:
Diagnosis, testing, and repair of fuel injection, ignition, emissions, and sensors.
Transmission Manual:
Repair and overhaul procedures for manual transmissions.
Transmission Automatic:
Diagnosis, repair, and overhaul procedures for automatic transmissions.
Drivetrain:
Coverage of transfer case, differentials, drive shafts, and CV joints.
Suspension:
Front and rear suspension component inspection, replacement, and alignment.
Steering:
Power steering system diagnosis and repair, steering column and linkage.
Brakes:
Disc and drum brake system inspection, repair, ABS diagnostics, and bleeding procedures.
Electrical System:
Comprehensive electrical troubleshooting, component testing, and detailed wiring diagrams.
Body Exterior:
Body panel repair, door mechanisms, glass, trim, and exterior lighting.
Body Interior:
Interior trim, upholstery, seating systems, HVAC controls, and dashboard components.
HVAC:
Heating, ventilation, and air conditioning system diagnosis and repair.
Cooling System:
Radiator, fan, thermostat, coolant hoses, and water pump service.
Exhaust System:
Exhaust manifold, catalytic converter, mufflers, and pipe replacement.
Maintenance:
Scheduled maintenance, fluid changes, filter replacements, and inspections.
Troubleshooting:
Systematic diagnostic procedures for identifying and resolving common and complex issues.
Repair:
Step-by-step repair instructions for nearly all vehicle components.
Rebuild:
Detailed procedures for rebuilding major components like engines and transmissions.
Restoration:
Information useful for refurbishing and restoring the vehicle to a high standard.
Diagnostics:
Diagnostic trouble codes (DTCs) interpretation and guided diagnostic routines.
Electrical Diagnostics:
Troubleshooting electrical issues using wiring diagrams and component testing.
Depth:
Comprehensive, suitable for professional technicians and advanced DIY enthusiasts.
Engine Options:
2.8L I4 Diesel (Europe/other markets), 3.7L V6 Magnum, 4.0L V6 SOHC.
Horsepower 3.7L:
210 hp @ 5200 rpm
Torque 3.7L:
235 lb-ft @ 4000 rpm
Horsepower 4.0L:
255 hp @ 6000 rpm
Torque 4.0L:
275 lb-ft @ 4000 rpm
Fuel Delivery:
Multi-port Electronic Fuel Injection (MPI) for all gasoline engines.
Engine Code 3.7L:
JK (often associated with this engine)
Engine Code 4.0L:
K (often associated with this engine)
Standard Transmission:
6-speed Manual (less common, primarily on base models)
Optional Transmission:
4-speed Automatic (42RLE)
Optional Transmission V6:
5-speed Automatic (NAG1 - Mercedes-Benz sourced, for 4.0L V6)
Drivetrain Options:
Rear-Wheel Drive (RWD), Part-Time 4-Wheel Drive (4WD).
Length:
Approximately 176.4 inches (4480 mm)
Width:
Approximately 72.1 inches (1831 mm)
Height:
Approximately 68.7 inches (1745 mm)
Wheelbase:
Approximately 109.8 inches (2789 mm)
Curb Weight Base:
Approx. 3,835 lbs (1739 kg)
Curb Weight V6 4Wd:
Approx. 4,171 lbs (1892 kg)
Cargo Volume Behind Rear Seat:
Approx. 19.5 cu ft (552 L)
Cargo Volume Max:
Approx. 62.7 cu ft (1776 L)
NHTSA Frontal Driver:
4 Stars
NHTSA Frontal Passenger:
4 Stars
NHTSA Side Driver:
5 Stars
NHTSA Side Passenger:
5 Stars
Traction Control:
Standard (Electronic).
Electronic Stability Control:
Standard (Electronic Stability Control - ESC).
Antilock Brakes:
Standard (4-wheel disc ABS).
Airbags Front:
Standard advanced driver and front-passenger airbags.
Airbags Side Curtain:
Available/Standard (depending on trim) front and rear side curtain airbags.
Oil Change Interval:
Typically 5,000-7,500 miles or 6 months (refer to manual for specific engine/oil type).
Tire Rotation:
Every 5,000-7,500 miles.
Spark Plug Replacement:
Refer to manual, often around 60,000-100,000 miles depending on type (e.g., platinum/iridium).
Engine Oil 3.7L:
SAE 5W-30 (API certified, synthetic or synthetic blend recommended).
Engine Oil 4.0L:
SAE 5W-30 (API certified, synthetic or synthetic blend recommended).
Transmission Fluid Automatic:
Chrysler ATF+4 (Mopar Part Number 05013457AA or equivalent).
Coolant:
Chrysler OAT (Organic Additive Technology) coolant (Mopar Part Number 05103539AA or equivalent, typically orange).
Common Complaints:
Some owners report issues with the 4-speed automatic transmission (42RLE) regarding harsh shifts or premature failure. Ignition coil failures, water pump leaks, and minor electrical gremlins can also occur.
