Segment:
Compact SUV / Crossover
Target Audience:
Families, individuals seeking versatile and practical transportation
Key Competitors:
Toyota RAV4, Honda CR-V, Chevrolet Equinox, Nissan Rogue
Vehicle Features:
Available AWD, comfortable ride, practical cargo space, choice of efficient engines, hybrid option
Benefit To Owner:
Empowers owners with the knowledge to perform maintenance and repairs, saving time and money, ensuring proper vehicle upkeep.
Diagnostic Capability:
Provides detailed diagnostic procedures mirroring dealership capabilities.
Covered Years:
2008, 2009, 2010, 2011, 2012
Covered Trims:
SE, SEL, Titanium
Covered Powertrain:
Gasoline and Hybrid variants
Estimated Page Count:
Extensive (Specific count not provided, implies comprehensive coverage)
Type:
Factory Service Workshop Manual
Indexing:
Searchable PDF with Index
Operating Systems:
Windows (95, 98, ME, XP, Vista, 7), Linux, MAC OS
Engine Mechanical:
Complete overhaul, diagnosis, repair of all engine components
Engine Electrical:
Wiring diagrams, component testing, diagnostic procedures
Emission Control:
Diagnosis and repair of EVAP, EGR, and other emission systems
Fuel System:
Fuel pump, injectors, pressure regulator, lines, and tank service
Clutch System:
Clutch operation, inspection, and replacement procedures (for manual transmission models)
Transaxle Manual:
Manual transmission overhaul, repair, and component replacement
Transaxle Automatic:
Automatic transmission diagnosis, repair, fluid service, and rebuilds
Driveshaft Axle:
CV joints, drive axles, differential service, and related components
Suspension System:
Struts, shocks, control arms, bushings, alignment procedures
Steering System:
Power steering pump, rack and pinion, tie rods, steering column service
Restraint System:
Airbag system diagnosis, replacement, and seat belt service
Brake System:
Brake pads, rotors, calipers, ABS system diagnosis, hydraulic lines
Body Interior Exterior:
Panel replacement, trim, glass, seals, interior components
Body Electrical:
Lighting, power windows, locks, mirrors, interior electronics, body control modules
HVAC:
Air conditioning, heating, ventilation system diagnosis and repair, refrigerant service
Maintenance:
Oil changes, filter replacements, fluid checks and top-offs, tire rotation
Repair:
Engine component repair/replacement, transmission rebuilds, brake service, suspension work
Troubleshooting:
Diagnostic flowcharts, symptom-based troubleshooting for all systems
Diagnostics:
On-Board Diagnostics (OBD-II) information, DTC code interpretation, sensor testing
Electrical Diagnostics:
Component testing, continuity checks, voltage readings, wiring harness repair
Depth:
Comprehensive, covering basic to advanced repairs and diagnostics
Documentation Level:
Factory-level detail, intended for dealership technicians and advanced DIYers
Engine Options:
2.3L I4, 2.5L I4, 3.0L V6
2.3L Duratec Performance:
Approx. 143-153 hp, 150-156 lb-ft torque
2.5L Duratec Performance:
Approx. 171 hp, 171 lb-ft torque
3.0L Vulcan V6 Performance:
Approx. 240 hp, 223 lb-ft torque
Hybrid Powertrain:
2.3L Atkinson Cycle I4 paired with an electric motor (eCVT)
Fuel Delivery:
Electronic Fuel Injection (EFI)
Recommended Fuel:
87 Octane Unleaded Gasoline (V6 may benefit from Premium for optimal performance)
Transmission Options:
5-Speed Manual (less common on V6), 6-Speed Automatic
Hybrid Transmission:
Electronically Controlled Continuously Variable Transmission (eCVT)
Automatic Transmission Features:
SelectShift capability, Tow/Haul Mode
Automatic Transmission Fluid Type:
Mercon LV (e.g., Motorcraft XT-6-QSP)
Manual Transmission Fluid Type:
75W-85 Synthetic Gear Lubricant (e.g., Motorcraft XYZ-75W85-QL)
NHTSA Rollover Rating:
4 out of 5 stars (generally)
IIHS Top Safety Pick:
Awarded 'Top Safety Pick' status in some model years.
ABS:
Standard Anti-lock Braking System
Traction Control:
Standard Traction Control System (TCS)
Electronic Stability Control:
Standard Electronic Stability Control (AdvanceTrac with Roll Stability Control)
Airbags:
Front airbags, front side-impact airbags, available Safety Canopy system with side-curtain airbags
Seatbelts:
3-point safety belts with pretensioners and load limiters
Oil Change Interval:
Every 7,500 miles or 6 months (synthetic blend recommended)
Tire Rotation Interval:
Every 7,500 miles
Engine Coolant Flush:
Approximately every 100,000 miles or 5 years
Engine Oil Spec 2.3L/2.5L:
SAE 5W-20, API SN or higher (e.g., Motorcraft SAE 5W-20)
Engine Oil Spec 3.0L V6:
SAE 5W-20, API SN or higher (e.g., Motorcraft SAE 5W-20)
Engine Coolant Type:
Ford Gold Coolant (G)_ (e.g., Motorcraft Premium Engine Coolant)
Common Issue 1:
Transmission shudder or harsh shifting (especially in early models)
Common Issue 2:
Power steering system issues (leaks, pump failure)
Common Issue 3:
Rear liftgate struts failure
Common Issue 4:
Catalytic converter failure (less common, but possible)
